- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS Installer: Leave this manual for homeowner. Homeowner: Read this manual and keep for future reference. © 2003 Jacuzzi Whirlpool Bath U961000G 2/05...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS CAUTION: TEST THE GROUND FAULT CIRCUIT INTERRUPTER PROTECTING THIS APPLIANCE PERIODI- CALLY IN ACCORDANCE WITH MANUFACTURER'S INSTRUCTIONS. WARNING: RISK OF ACCIDENTAL INJURY OR DROWNING; CHILDREN SHOULD NOT USE HYDROMAS- SAGE BATHTUB WITHOUT ADULT SUPERVISION. - Page 3 NOTE: This is a professional grade product. A knowledge of construction techniques, plumbing and electri- cal installation according to codes are required for proper installation and user satisfaction. We recommend that a licensed contractor perform the installation of all Jacuzzi Whirlpool Bath products. Our warranty does not cover improper installation related problems.
-
Page 4: Operating Instructions
HYPERTHERMIA INCLUDE AN INCREASE IN THE INTERNAL TEMPERATURE OF THE BODY, DIZZI- NESS, LETHARGY, DROWSINESS AND FAINTING. THE EFFECTS OF HYPERTHERMIA INCLUDE: A) FAILURE TO PERCEIVE HEAT B) FAILURE TO RECOGNIZE THE NEED TO EXIT THE SPA OR HOT TUB, C) UNAWARENESS OF IMPENDING HAZARD, D) FETAL DAMAGE IN PREGNANT WOMEN, E) PHYSICAL INABILITY TO EXIT THE SPA OR HOT TUB, AND F) UNCONSCIOUSNESS RESULTING IN DANGER OF DROWNING. -
Page 5: Installation Instructions
NOTE: This is a professional grade product. A knowledge of construction techniques, plumbing and electri- cal installation according to codes are required for proper installation and user satisfaction. We recommend that a licensed contractor perform the installation of all Jacuzzi Whirlpool Bath does not cover improper installation related problems. -
Page 6: Table Of Contents
NOTE: To obtain a referral for a service agent in your area call 800-288-4002. You may also visit our web site at http:// www.jacuzzi.com/. To find the service agent listing, click on For The Trade. Then click on Electrical/Mechanical Service Agents. -
Page 7: Specifications
Immediately upon receipt, inspect the shell before installing. Should inspection reveal any damage or defect in the finish, do not install the bath. Damage or defect to the finish claimed after the bath is installed is excluded from the warranty. Jacuzzi Whirlpool Bath's responsibility for shipping damage ceases upon delivery of the products in good order to the carrier. -
Page 8: Installation
958 Almond 815 Satin Nickel 969 Oyster 826 Brushed Nickel 827 Chrome 829 PVD Brass 898 Brushed Chrome 845 Oil Rubbed Bronze Jacuzzi Whirlpool Bath© U961000G 2/05 SPECIFICATIONS 2" (51 mm) SIDE VIEW ESPREE 6060 (25 mm) 1" SIDE VIEW... - Page 9 ESPREE 6042 WITH SKIRT 72" 18" 18" x 4" 36" 2" 15-5/8" (Left hand only as shown) ESPREE 7236 *72" 21" 18" x 4" 42" 2" 15-5/8" (Left hand only as shown) ESPREE 7242 Jacuzzi Whirlpool Bath© U961000G 2/05 60" 2"...
- Page 10 3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4. 6060 CUTOUT 57-7/8" 57-7/8" 90° 49-3/4" ESPREE 6060 WITHOUT SKIRT Jacuzzi Whirlpool Bath© U961000G 2/05 ROUGH-IN Junction Box (Right hand only as shown) ESPREE 6060 WITH INTEGRAL SKIRT 6032 CUTOUT 4"...
-
Page 11: Framing And Support
OPTIONAL TILE FLANGE KIT TILE STUD CEMENT CAULKING BOARD TILE ADHESIVE FLANGE ATTACH WITH SCREWS PROVIDED STUD 1/8" GAP FLANGE FINISHING MATERIAL MORTAR CEMENT BOARD BATH RIM SILICONE SEALANT STUD WALL 1" X 4" (NOT FOR SUPPORT) Jacuzzi Whirlpool Bath© U961000G 2/05... -
Page 12: Service Access
12" PREFERRED 18" ACCESS RELEASE VELCRO™ Jacuzzi Whirlpool Bath© U961000G 2/05 INSTALLATION Service Access with Skirt An optional skirt fits along the side of the bath for above-floor installations and is also an access panel for servicing. Allow a space of at least 8 inches away from the bath for skirt removal. -
Page 13: Electrical Connections
Magic Touch whirlpool ON/OFF switch on the bath itself, no remote switch or timer is necessary. If an optional timer is desired, one is available from Jacuzzi Whirlpool Bath for 120 VAC operation. DANGER: RISK OF ELECTRIC SHOCK. Connect only to a circuit protected by a Ground Fault Circuit Interrupter GFCI. - Page 14 After opening the carton, inspect for damage and verify that the kit is of the proper finish. In the Jacuzzi Whirlpool Bath drain/ overflow kit, note that the waste flange, strainer, over- flow cover and cover screws are packaged in a sepa- rate package within the kit to protect the trim finish.
-
Page 15: Operation
If you want a unit designed to continu- ously hold water, see your Jacuzzi Whirlpool Bath dealer for the complete line of whirlpool spas available. Once the bath is installed, remove any residue or for- eign materials left over from construction. -
Page 16: Operation
The whirlpool action in your bath is influenced by three factors – direction of flow, force of water, and force of air. All baths manufactured by Jacuzzi Whirlpool Bath are equipped with fully adjustable PowerPro are adjustable for all three factors. Some baths have additional directionally adjustable jets which can be ad- justed for direction and flow of air only. -
Page 17: Maintenance
Systems Clean as recommended. (For additional information about water content, contact us for a copy of the Jacuzzi Water Quality Primer.) Lamp An optional lamp kit is available from your Jacuzzi Whirlpool Bath dealer for installation on your bath. -
Page 18: Troubleshooting
NOTE: If unit is within the warranty period, contact Jacuzzi Whirlpool Bath Service Support at (866) 905-2289 with bath's serial number before work is started. The Serial Number is located on the Specification/Serial Number Plate. See page 13. - Page 19 Service Support Department at 1-866-905-2289. For service agent listing, visit our web site at http://www.jacuzzi.com/. To find the service agent listings, click on For The Trade. Then click on Electrical/ Mechanical Service Agents. Depending on the problem, click on Electrical/Mechanical Repairs or Finish, Surface or Shell-Related Problems.
-
Page 20: Authorized Service
If you need a referral for a service company near you, or need assistance with operation or maintenance related questions, please call our Service Support Department at 1-800-288-4002. Visit our web site at http://www.jacuzzi.com/ for products and services. To find service agent listings for: Electrical or Mechanical Repairs visit http://jacuzzi.com/pdf/ASA.PDF... -
Page 21: Repair Parts
NOZZLE BHM 8413XXX O RING 8488000 INTERNAL O RING SEAT 8487XXX JET BODY 8411XXX LOCK NUT 8415000 SCREWS (2) 7514000 Jacuzzi Whirlpool Bath© U961000G 2/05 REPAIR PARTS 1 POSITION AIR CONTROL KNOB 8267XXX GRAPHIC RING AIR 8263000 PANEL, 1 POSITION D851XXX... -
Page 22: Position Control (Air & Pump/Motor On/Off)
GRAPHIC RING AIR 8263000 PANEL 2 POSITION 8241XXX AIR CONTROL ASSEMBLY BP54000 or BP55000 REPAIR PARTS BEZEL 8247XXX BUTTON AIR ACTUATOR 8246XXX (MOTOR/PUMP ON/OFF) GRAPHIC RING ON/OFF 8262XXX BELLOWS C377000 CUP AIR 8263000 SCREWS (8) 9724000 Jacuzzi Whirlpool Bath© U961000G 2/05... - Page 23 HTC BODY A320XXX BACKUP RING 1836000 LOCKNUT 1835000 Jet Body BG15000 Nozzle (Part of Jet Body) Back Massage Jet Assy Jacuzzi Whirlpool Bath© U961000G 2/05 REPAIR PARTS SUCTION ASSEMBLY SCREW #10-24/2 3959000 SUCTION COVER/GASKET ASSEMBLY 6651XXX SUCTION FITTING 1958000 RING BACK-UP SUCTION 2136000...
-
Page 24: Repair Parts
GRAPHIC RING AIR (2) 8263XXX AIR CONTROL ASSEMBLY BP54000 (2) OR BP55000 (2) REPAIR PARTS 3 POSITION PANEL SCREWS (10) 9724000 Jacuzzi Whirlpool Bath© U961000G 2/05 BUTTON AIR ACTUATOR 8246XXX KNOB 8267XXX (2) BEZEL 8247XXX GRAPHIC RING ON/OFF 8262XXX 3 POSITION PANEL 9224XXX... -
Page 25: Warranty
USE INSTALLATION INSTRUCTIONS SUPPLIED WITH PRODUCT. Jacuzzi Whirlpool Bath has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of the product. -
Page 26: Warranty
The attached Warranty Registration Card MUST be filled out by the purchaser within thirty (30) days from purchase and mailed to Jacuzzi Whirlpool Bath in order for this warranty to become effective. - Page 27 In order to obtain warranty service, consult your local telephone book for the location of the nearest Jacuzzi Whirlpool Bath Authorized Service Agent.
- Page 28 2/05 U961000G Bath Whirlpool Jacuzzi 2003 © aceptar cliente negación reparaciones. reemplazo. partes para garantía fallan. accesorios será Usted compra. prueba problema fabricados accesorios Compañía suministradas escriba llame Agent, servicio. garantía requerimiento Bath. Whirlpool Jacuzzi cercano más autorizado después razonable...
- Page 29 Series Espree LIMITADA GARANTIA 75370-2168 Dallas, 702168 P.O. Whirlpool Jacuzzi garantía. efectiva hacer poder para dentro comprador llenada GARANTIA CARTA RETORNO pueden descritas exclusiones limitaciones final garantía extenso cuanto...
- Page 30 T180000 G947000 UNION EMPAQUETADORAS S749000 Y670000 Y671000 UNION (MOSTRADO) U394000 DESCARGA RAPIDHEAT CALENTADOR cada para apropiado color código U961000G Bath Whirlpool Jacuzzi (866) cliente: atención Servicio Dallas, 702168, BATH WHIRLPOOL JACUZZI instalación. representa, Bath Whirlpool Jacuzzi producto, instalar Antes país.
- Page 31 2/05 U961000G Bath© Whirlpool Jacuzzi C841000 COPA 8399000 VALVULA TORICO ANILLO REPARACION MONTAJE C377000 FUELLES 9224XXX POSICIONES PANEL 8262XXX ON/OFF GRAFICO ANILLO 8247XXX ENMARCADORA PLACA 8267XXX MANIJA 8246XXX AIRE ACCIONAMIENTO BOTON cada para apropiado color código 9724000 (10) TORNILLOS POSICIONES...
- Page 32 Manija BG00XXX Accesorio eyector) (Parte Parada 1835000 CONTRAMARCHA 1840000 B788XXX B788XXX SUCCION MONTAJE sustituya tiene repuesto REPUESTO PIEZAS 2/05 U961000G Bath© Whirlpool Jacuzzi Assy masaje chorro Apoye eyector) (Parte Boquilla BG15000 eyector Cuerpo CONTRATUERCA 1836000 ANILLO A320XXX CUERPO EMPAQUETADURA...
- Page 33 2/05 U961000G Bath© Whirlpool Jacuzzi 9724000 TORNILLOS C841000 COPA C377000 FUELLES 8262000 APAGADO PRENDIDO GRAFICO ANILLO 8246XXX ON/OFF) (MOTOR/BOMBA AIRE ACCIONAMIENTO BOTON 8247XXX ENMARCADORA PLACA cada para apropiado color código ON/OFF) BOMBA/MOTOR & (AIRE CONTROL PANEL POSICION sustituya tiene repuesto...
- Page 34 7514000 8415000 8411XXX 8487XXX INTERNA 8488000 8413XXX 8412XXX RETENCION POSICION EYECTOR código sustituya tiene repuesto REPUESTO PIEZAS 2/05 U961000G Bath© Whirlpool Jacuzzi TORNILLOS CONTRATUERCA EYECTOR CUERPO TORICA JUNTA TORICO ANILLO BOQUILLA BOQUILLA 8489XXX MONTAJE EYECTOR (969) Ostra (914)
- Page 35 Para http://www.jacuzzi.com/. lista obtener Para 1-800-288-4002. llame favor producto, necesita cercanía, servicios ducha manual. este...
- Page 36 2/05 U961000G Bath© Whirlpool Jacuzzi serie rebose. válvula bomba/motor. cerca continuación). gráfico especificaciones/ etiqueta obtener junto proporcionada producto, serie número como modelo, tanto, Acabado, relacionados Problemas problema, Dependiendo Agents). entre Luego Trade”. “For busque sitio nuestro visite servicios, atención Departamento...
- Page 37 Touch– Magic Interruptor bomba/motor. conectada está bomba/motor. corriente llega CAUSAS PROBABLES averías reparación 2/05 U961000G Bath© Whirlpool Jacuzzi placa especificaciones localiza número verifique 288-4002, (800) plazo dentro está unidad NOTA: fijado. tiempo antes cronómetro,...
- Page 38 2/05 U961000G Bath© Whirlpool Jacuzzi CASCO LAPARA TAPA BOMBILLA BOMBILLA SUJECION TUERCA FOCO Bath. Whirlpool Jacuzzi distribuidor disponi- están (12V, repuesto bombillas debajo encuentra casquillo, separándola posterior parte retírela bombilla, bañera. instalarse pueden lámparas muestre Bath Whirlpool Jacuzzi distribuidor EMPAQUETADURA...
- Page 39 Cómo FUNCIONAMIENTO 2/05 U961000G Bath© Whirlpool AIRE FLUJO FLUJO DISMINUIR PARA PARA DERECHA GIRE GIRE INDUCCIÓN PARA CONTROLES RESET PUSH PROTECTION HEAT OVER...
- Page 40 2/05 U961000G Bath© Whirlpool Jacuzzi ON/OFF CENTRO ON/OFF TOUCH MAGIC Touch. Magic interruptor necesario será cronómetro, correctamente progra- sido habiendo activa, sistema deseado. número número pasar hasta derecha cro- girar haga minutos, sólo funcione Cuando Nota: hidromasaje. sistema tiempo prográmelo...
- Page 41 Jacuzzi tes. acabado llenado embalaje, colocar sani- sistema IMPORTANTE: verificar requisitos desagüe/rebosadero Consulte Suministro INSTALACION 2/05 U961000G Bath© Whirlpool Jacuzzi Bath. Whirlpool Jacuzzi nario consulte fugas, detecta fugas. tengan correctamente funcionen embarcarse antes fábrica Whirlpool Jacuzzi...
- Page 42 2/05 U961000G Bath© Whirlpool Jacuzzi RESET PUSH PROTECTION HEAT OVER HEATER RAPIDHEAT EMPALME INTEGRADO FALDON MOTOR ELÉCTRICA CONEXION MOTOR/BOMBA FIJANDO CONEXCIONES CAJA INTEGRADO FALDON corregida. identificada causa hasta bañera Desconecte eléctrica. descarga indicando dispositivo, defectuoso fun- fluye falla corriente esta...
- Page 43 "Ac- nombre bañera espacio instalaciones. reco- mínimas espacio dejar usarlo piso, para bañera ser- conexiones puede totalmente Acceso INSTALACION 2/05 U961000G Bath© Whirlpool Jacuzzi 18" ALTERNO ACCESO 12" FRENTE FALDON) (SIN SERVICIO PARA ACCESO imagen opuesto lado coloca izquierdas unidades...
- Page 44 2/05 U961000G Bath© Whirlpool Jacuzzi PESTAÑA MURO PROVEIDOS TORNILLOS PEGAZULEJOS CEMENTO PESTAÑA OPCIONAL PAQUETE CARGA) PARA 4" 1" MURO SILICONA SELLADOR TORNILLO CLAVO TINA BAÑERA PESTAÑA CEMENTO PANEL YESO MORTERO RELLENO FINAL RECUBRIMIENTO instale instalación, toda completado unidad. instalando esté...
- Page 45 FALDON proyectada) imagen producidas unidades contrario, PLANTA 2/05 U961000G Bath© Whirlpool Jacuzzi 6060 ESPREE 49-3/4" 90° 57-7/8" CORTE vienen medidas Todas desagüe/rebosadero ción aparecen medidas (6.3 pulg. *Añada...
- Page 46 2/05 U961000G Bath© Whirlpool Jacuzzi 25.4. desagüe/ instalación para piso mm). -6.3 7242 ESPREE representa) como sólo izquierda 2" 4" 18" *72" 7236 ESPREE representa) como sólo izquierda (Unidad 2" 4" 18" 72" FALDON 6042 ESPREE representada) izquierda (Unidad 10-13/16"...
- Page 47 Página U.S. PISO CORTE CAPACIDAD SOBRE TOTAL CARGA FALDÓN 6060 LATERAL VISTA 1" 6060 ESPREE LATERAL VISTA 2" ESPECIFICACIONES 2/05 U961000G Bath© Whirlpool Jacuzzi Bronce Cromo cobre Cromo Níquel Ostra Níquel Almendra Blanco Platino X163XXX 7701XXX agua lámparas Paquete Juego...
- Page 48 2/05 U961000G Bath© Whirlpool Jacuzzi GFCI. tipo independiente GFCI tipo independiente circuito protector mm). -6.3 calentador) para juego (U395000 Disponible calentador) para juego (U395000 Disponible calentador) para juego (S750000 Integrado calentador) para juego (S750000 Disponible calentador) para juego (U395000 Disponible...
- Page 49 __________________________________________________________ ___________________________________________________________ ___________________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________________ CONTENIDO autorizados, agentes lista obtener Finish, Repairs, Electrical/Mechanical Agents. Service agente lista encontrar Para http://www.jacuzzi.com/. llame área servicio agente propietario Registro para instrucciones estas descarga equipo RapidHeat calentador Masajes para agua salida succión encendido/apagado)
- Page 50 U.S.A. Printed 06/05 DISPOSITIVOS. TALES USUARIO-OPERADOS MUCHO AUMENTAR PUEDEN MEDICINA AHOGAR. PELIGRO JACUZZI, BALNEARIO EFECTOS DESMAYAR. TEMPERATURA NORMAL CORPORAL TEMPERATURA CUERPO INTERNA TEMPERATURA INDUCIR PUEDE CALIENTE INSTRUCCIONES EQUIPO. ESTE SUMINISTRAN MISMO CONDUCTOR TIERRA TERMINAL CONECTOR RIESGO REDUCIR PARA TERMINALES. "GROUND"...
- Page 51 Printed 06/05 cumplimiento respecto garantías específicas locales normas cumplimiento para nacional nivel disponibles estar PRODUCTO. AVISO. CAMBIOS relacionados problemas cubre Jacuzzi productos todos instalación lograr para normas técnicas conocimientos (60°C). 140°F superficie. pulga supere agua nivel LOCALES. METALES ELÉCTRICOS COBRE SÓLIDO...
- Page 52 Whirlpool Jacuzzi productos electricidad. plomería requiere usuario, producto Este NOTA: miento. parte como instaladas unidades Para instalada debe unidad Esta cumplir...
- Page 53 ESTE SUMINISTRAN CIRCUITO ELECTRICO, PANEL DEBE TERMINAL ESTE CAMPO. TERMINAL EQUIPO PROPORCIONA USAR ANTES MEDICO TIENEN MEDICAMENTOS TOMAN AGUA TEMPERATURA AJUSTE AGUA TEMPERATURA EJER- EFECTUADO HABER DESPUES BAÑERA AHOGAMIENTO; EQUIPA- HIDROMASAJE BAÑERA EMBA- POSIBILIDAD EMBARAZADAS DURANTE ANTES ALCOHOL QUEDAR EVITAR PARA ACCIDENTALMENTE;...
- Page 54 2/05 U961000G Bath Whirlpool Jacuzzi 2003 © futuro. referencia para guárdelo manual este Propietario: propietario. manual este Deje Instalador: OPERACION INSTALACION MANUAL...
