- Page 1 Fujitsu Semiconductor Europe FMEMCU-UG-960031-13 User Guide F²MC-16FX FAMILY MB96650/6A0/6C0/380 SERIES EVALUATION BOARD SK-96650_6A0_380-120PMC USER GUIDE...
-
Page 2: Revision History
V1.0, SWi: First Release 06.06.2011 V1.1, Swi: JP47 added in description Chapter 2.3: title changed 02.03.2011 V1.2, SWi: name convention 24.04.2012 V1.3, SWi: new chapter about CE conformity declaration This document contains 39 pages. FMEMCU-UG-960031-13 - 2 - © Fujitsu Semiconductor Europe GmbH... -
Page 3: Warranty And Disclaimer
The use of the deliverables (e.g. software, application examples, target boards, evaluation boards, starter kits, schematics, engineering samples of IC‟s etc.) is subject to the conditions of Fujitsu Semiconductor Europe GmbH (“FSEU”) as set out in (i) the terms of the License Agreement and/or the Sale and Purchase Agreement under which agreements the Product has been delivered, (ii) the technical descriptions and (iii) all accompanying written materials. -
Page 4: Table Of Contents
Reset Generation (JP: 33, 41, 46, 48) ..............21 User Buttons SW1, SW2, SW3, SW4, SW5, SW6 (JP: 3, 4, 5, 6, 7) ...... 22 C pull-up resistor (JP: 9, 10) ................22 3.10 LIN / UART ......................23 FMEMCU-UG-960031-13 - 4 - © Fujitsu Semiconductor Europe GmbH... - Page 5 7 APPENDIX ........................35 Related Products ....................35 8 INFORMATION IN THE WWW..................36 9 EU-KONFORMITÄTSERKLÄRUNG / EU DECLARATION OF CONFORMITY ..... 37 10 CHINA-ROHS REGULATION ..................38 11 RECYCLING ........................39 © Fujitsu Semiconductor Europe GmbH - 5 - FMEMCU-UG-960031-13...
-
Page 6: Overview
Chapter 1 Overview 1 Overview 1.1 Abstract The SK-96650_6A0_380-120PMC is a multifunctional evaluation board for the Fujitsu MB96600 Flash microcontroller MB96650, MB966A0 and MB966C0 Series as well as for the MB96300 Flash microcontroller MB96380 Series. It can be used stand-alone for software development and testing or as a simple target board to work with the emulator system. -
Page 7: Features
Change odd page title here Chapter 1 Overview 1.2 Features Supports following Fujitsu products: MB96600 series Microcontroller MB96650, MB966A0 and MB966C0 series with 120 pin PMC / M21 package Embedded Emulator MB2100-01-E MB96300 Microcontroller MB96380 Series with 120 pin PMC / M21 package ... -
Page 8: General Description
Change even page title here Chapter 1 Overview 1.3 General Description The SK-96650_6A0_380-120PMC supports the F MC-16FX MB96600 Flash microcontroller MB96650, MB966A0 and MB966C0 Series as well as the F MC-16FX Flash microcontroller MB96380 Series with LQFP120-M21 (PMC) package. It can be used as a stand-alone evaluation board or as a target board for the emulator debugger. -
Page 9: I2C Bus
1.3.10 On-Chip Debug System (OCDS) If the On-Chip debugging on the MB96600 microcontroller is applied, then the embedded emulator MB2100-01-E must be connected to the target board via SMA jack on the PCB. © Fujitsu Semiconductor Europe GmbH - 9 - FMEMCU-UG-960031-13... -
Page 10: Installation
1. Power up the Emulator Main Unit (MB2198-01) 2. Power up the Adapter Board (MB2198-500), if needed 3. Power up the target Board (SK-96650_6A0_380-120PMC) To turn off the system, switch off the components in reverse order, beginning with the target Board. -
Page 11: Default Jumper Settings
Direct Reset / Delayed Solder JP 3 pin JP47 Voltage Monitor Solder JP 4 pin JP48 MCU Reset Jumper 2 pin Closed Closed Closed JP51 P17_0 Jumper 2 pin open open Closed © Fujitsu Semiconductor Europe GmbH - 11 - FMEMCU-UG-960031-13... - Page 12 DVCC Pin 41 Jumper 2 pin Open Open Closed JP64 DVSS Pin 42 Jumper 2 pin Open Closed Closed JP78 ALARM0 Jumper 2 pin Closed Closed Closed L 13 Table 2-1: Jumper Settings FMEMCU-UG-960031-13 - 12 - © Fujitsu Semiconductor Europe GmbH...
-
Page 13: Jumper Location
2.3 Jumper Location The following figures show the silk plot of the starter-kit with marked default jumper settings depending on the microcontroller series. 2.3.1 MB96650 Figure 2-1: Default Jumper Setting with MB96650 © Fujitsu Semiconductor Europe GmbH - 13 - FMEMCU-UG-960031-13... -
Page 14: Mb966A0/6C0
Change even page title here Chapter 2 Installation 2.3.2 MB966A0/6C0 Figure 2-2: Default Jumper Setting with MB966A0/6C0 FMEMCU-UG-960031-13 - 14 - © Fujitsu Semiconductor Europe GmbH... -
Page 15: Mb96380
Change odd page title here Chapter 2 Installation 2.3.3 MB96380 Figure 2-3: Default Jumper Setting with MB96380 © Fujitsu Semiconductor Europe GmbH - 15 - FMEMCU-UG-960031-13... -
Page 16: Jumpers And Switches
MB96300: MD1) S1-3 ON (closed) 0 (low) (MB96600: MOD, OFF (open) 1 (high) MB96300: MD2) S1-4 ON (closed) Not connected (Not used) OFF (open) Not connected Table 3-2: MCU Operating Mode FMEMCU-UG-960031-13 - 16 - © Fujitsu Semiconductor Europe GmbH... -
Page 17: Power Supply (S2, Jp: 8, 15, 16, 17, 22, 61, 62, 63, 64)
JP61 Connects DVCC power supply with Pin 53 JP62 Connects DVSS power supply with Pin 54 JP63 Connects DVCC power supply with Pin 41 JP64 Connects DVSS power supply with Pin 42 © Fujitsu Semiconductor Europe GmbH - 17 - FMEMCU-UG-960031-13... - Page 18 Closed Closed voltage JP64 (DVSS_42) Pin 43 is disconnected to SMC (DVSS) Open Open Open supply voltage Table 3-3: Power Supply Configuration By default, all Board supplies are set to 5V. FMEMCU-UG-960031-13 - 18 - © Fujitsu Semiconductor Europe GmbH...
-
Page 19: Subclock (Jp: 1, 2)
Pin 69 is connected to the 32 kHz sub-clock (X1A) (X1A) Pin 69 is used as port pin P04_1 Table 3-4: Subclock Default: JP1: 1-2, JP2: 1-4 By default, the 32 kHz sub-clock-crystal is connected to the microcontroller. © Fujitsu Semiconductor Europe GmbH - 19 - FMEMCU-UG-960031-13... -
Page 20: Analog Power Supply Voltage (Jp: 11, 12, 13, 14)
JP78 One potentiometer can be connected to the ALARM0/AN8 Jumper Setting Description Closed Pin 26 (ALRAM0/AN8) of the MCU is connected to RP2 JP78 (ALARM0) Open Pin 26 (ALRAM0/AN8) of the MCU is not connected Table 3-6: Alarm Comparator FMEMCU-UG-960031-13 - 20 - © Fujitsu Semiconductor Europe GmbH... -
Page 21: Reset Generation (Jp: 33, 41, 46, 48)
(JP23 and JP38) jumper have to be set, too (see 5.1.1). If the reset LED is steadily on, check the power supply input voltage and the settings for the reset-generation by UART. © Fujitsu Semiconductor Europe GmbH - 21 - FMEMCU-UG-960031-13... -
Page 22: User Buttons Sw1, Sw2, Sw3, Sw4, Sw5, Sw6 (Jp: 3, 4, 5, 6, 7)
A 10k pull-up resistor is connected to SDA0 (SDA0) Open No pull-up resistor is connected to SDA0 Closed A 10k pull-up resistor is connected to SCL0 JP10 (SCL0) Open No pull-up resistor is connected to SCL0 FMEMCU-UG-960031-13 - 22 - © Fujitsu Semiconductor Europe GmbH... -
Page 23: Lin / Uart
LIN-UART0 is LIN Slave Closed LIN bus (X5 pin 1) is powered by the board JP28 (LIN Vbat) Open LIN bus (X5 pin 1) is not powered by the board Table 3-9: UART0 Settings © Fujitsu Semiconductor Europe GmbH - 23 - FMEMCU-UG-960031-13... -
Page 24: Lin-Uart 2 (Jp: 36, 37, 38, 39, 40, 42, 43, 45)
JP34 (CAN1 RX) Open RX1 is disconnected to CAN1 (X8) Closed TX1 is connected to CAN1 (X8) JP35 (CAN1 TX) Open TX1 is disconnected to CAN1 (X8) Table 3-11: CAN Settings FMEMCU-UG-960031-13 - 24 - © Fujitsu Semiconductor Europe GmbH... -
Page 25: Rd Monitor Voltage (Jp24)
3.3V. Jumper Setting Description iC monitor input connected to 1.8V (forbidden) JP24 iC monitor input connected to 2.5V (Monitor) iC monitor input connected to 3.3V © Fujitsu Semiconductor Europe GmbH - 25 - FMEMCU-UG-960031-13... -
Page 26: Connectors
Connected to DTR (pin 4) Can be connected with CTS by jumper Can be connected with RTS by jumper LGND Ground normally used for LIN connection Shield Ground Table 4-1: UART Connector Signals FMEMCU-UG-960031-13 - 26 - © Fujitsu Semiconductor Europe GmbH... -
Page 27: Can Connector (X6, X8)
Description Not used CANL LOW-level CAN voltage input/output Ground Not used Not used Not used CANH HIGH-level CAN voltage input/output Not used Not used Shield Ground Table 4-2: CAN Connector Signals © Fujitsu Semiconductor Europe GmbH - 27 - FMEMCU-UG-960031-13... -
Page 28: User-Leds & Optional Lc-Display (J1)
Figure 4-4: User LEDs/LCD 9 10 GND GND VCC DB4 DB5 DB6 DB7 Port 09_0 09_1 09_2 09_3 09_4 09_5 09_6 09_7 Table 4-3: User LEDs/LCD Pin 15: Vcc via 39Ω/0.5W for LCD backlight FMEMCU-UG-960031-13 - 28 - © Fujitsu Semiconductor Europe GmbH... -
Page 29: In-Circuit-Programming Connector (X4)
This voltage is used for the alarm comparator ALARM0 or analogue input AN8 on pin 26. 4.9 External Supply Voltage Vin (J3) This connector is connected to the external supply voltage (Vin). © Fujitsu Semiconductor Europe GmbH - 29 - FMEMCU-UG-960031-13... -
Page 30: Vcc 5 Volts (J4)
To this connector the INH pin of the LIN1 transceiver is connected. 4.14 VCC Connector (J7) On this connector the VCC supply (see chapter 3.3) can be measured. 4.15 GND Connector (J8) Ground reference terminal GND. FMEMCU-UG-960031-13 - 30 - © Fujitsu Semiconductor Europe GmbH... -
Page 31: Programming The Internal Flash Memory
(SOT2) JP40 UART2 RS232 transceiver is selected for X9 (RS232/LIN) JP42 UART2 Open X9-1 is disconnected from the power supply (Vbat) Table 5-2: Jumper Settings for Programming via UART 2 (X9) © Fujitsu Semiconductor Europe GmbH - 31 - FMEMCU-UG-960031-13... -
Page 32: Reset (Optional)
Connect the configured UART (see above) to your serial PC communication port. A straight 1:1 cable connection has to be used. 2) Start the tool “Fujitsu Flash MCU Programmer” software and make the settings: Select COM Port Select your Device... -
Page 33: Synchronous Mode
10 GND Figure 5-1: Flash Programming Socket Note: Please open the jumpers JP37 (SIN2) and JP39 (SOT2), in order to avoid that the synchronous programming tool drives against the on-board RS232 transceiver! © Fujitsu Semiconductor Europe GmbH - 33 - FMEMCU-UG-960031-13... -
Page 34: On-Chip Debug Hardware Configuration
JP51: don‟t care Set DIP switch (X12) into run mode DEBUG I/F MB96600 P17_0 MB96300 DIP Switch: RUN Mode 1 2 3 4 1 2 3 4 FMEMCU-UG-960031-13 - 34 - © Fujitsu Semiconductor Europe GmbH... -
Page 35: Appendix
MB96F65x/6Ax/6CxR Flash MCU (CAN: yes; PLVR: no) MB96F65x/6Ax/6CxY Flash MCU (CAN: yes; PLVR: yes) MB96F65xA Flash MCU (CAN: no; PLVR: no) MB96F65xB Flash MCU (CAN: no; PLVR: yes) © Fujitsu Semiconductor Europe GmbH - 35 - FMEMCU-UG-960031-13... -
Page 36: Information In The Www
Internet pages: Microcontrollers (8-, 16- and 32bit), Graphics Controllers Datasheets and Hardware Manuals, Support Tools (Hard- and Software) http://mcu.emea.fujitsu.com/ Power Management Products http://www.fujitsu.com/emea/services/microelectronics/powerman/index.html For more information about FUJITSU SEMICONDUCTOR http://emea.fujitsu.com/semiconductor FMEMCU-UG-960031-13 - 36 - © Fujitsu Semiconductor Europe GmbH... -
Page 37: Eu-Konformitätserklärung / Eu Declaration Of Conformity
9 EU-Konformitätserklärung / EU declaration of conformity Hiermit erklären wir, Fujitsu Semiconductor Europe GmbH, Pittlerstrasse 47, 63225 Langen, Germany dass dieses Board aufgrund seiner Konzipierung und Bauart sowie in den von uns in Verkehr gebrachten Ausführung(en) den grundlegenden Anforderungen der EU-Richtlinie 2004/108/EC „Elektromagnetische Verträglichkeit“... -
Page 38: China-Rohs Regulation
Change even page title here Chapter 10 China-RoHS regulation 10 China-RoHS regulation This board is compliant with China RoHS FMEMCU-UG-960031-13 - 38 - © Fujitsu Semiconductor Europe GmbH... -
Page 39: Recycling
According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Fujitsu SEMICONDUCTOR Europe GmbH Warehouse/Disposal Monzastraße 4a D-63225 Langen GERMANY -- END -- © Fujitsu Semiconductor Europe GmbH - 39 - FMEMCU-UG-960031-13...
