SERVICE MANUAL
DVD DIGITAL THEATER SYSTEM
SP-PWA10
Area Suffix
B
EN
EE
XV-THA10R (DVD player)/XV-TH-A10
TH-A10R
SP-THA10
TH-A10
(Speaker section)
Contents
Safety Precautions
Important for laser products
Preventing static electricity
Disassembly method
Adjustment method
COPYRIGHT
TH-A10R
TH-A10
SP-XSA10
SP-XCA10
XV-THA10R
TH-A10R
U.K.
E
Northern Europe
Russia
SP-PWA10 (Powered subwoofer)
SP-XCA10 (Center speaker)
SP-XSA10 (Satellite speaker) x 4
1-2
1-3
1-4
1-5
1-21
2000 VICTOR COMPANY OF JAPAN, LTD.
RM-STHA10R
SP-XSA10
Area Suffix
TH-A10
Continental Europe
Flow of functional operation
until TOC read
Maintenance of laser pickup
Replacement of laser pickup
Description of major ICs
TH-A10R/TH-A10
RM-STHA10EC
1-24
1-25
1-25
1-26
No.20872
Sep. 2000
