Icom IC-A22 Service Manual page 16

[MAIN UNIT]
REF ORDER
NO. NO.
D5006 1790001280 S.DIO MA111 (TX)
D5007 1790001280 S.DIO MA111 (TX)
D5008 1790001280 S.DIO MA111 (TX)
D5009 1790000860 S.DIO MA133 (TX)
D5010 1790001280 S.DIO MA111 (TX)
D5011 1790001330 S.ZEN MA8036-L (TX)
D5013 1790001280 S.DIO MA111 (TX)
D5014 1790001280 S.DIO MA111 (TX)
D5015 1790000860 S.DIO MA133 (TX)
FI5001 2020001070 CER CFWLA455KDFA-B0 (CFWS455D)
X5001 6050009110 XTL CR-485 (35.345 MHz)
X5002 6070000130 DCR CDBLB455KCAY24-B0
R5001 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R5008 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5009 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R5010 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R5011 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5012 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R5013 7030003730 S.RES ERJ3GEYJ 274 V (270 kΩ)
R5014 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R5015 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R5016 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5017 7030003740 S.RES ERJ3GEYJ 334 V (330 kΩ)
R5018 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5020 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R5021 7030003630 S.RES ERJ3GEYJ 393 V (39 kΩ)
7030003310 S.RES ERJ3GEYJ 820 V (82 Ω)
R5023
7030003200 S.RES ERJ3GEYJ 100 V (10 Ω)
R5024
7030003420 S.RES ERJ3GEYJ 681 V (680 Ω)
R5025
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R5026
R5027 7030003590 S.RES ERJ3GEYJ 183 V (18 kΩ)
R5029 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5030 7030003650 S.RES ERJ3GEYJ 563 V (56 kΩ) [AUS], [UK], [USA-1] only
R5031 7030003650 S.RES ERJ3GEYJ 563 V (56 kΩ)
R5035 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R5036
R5037 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5043 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5044 7030003510 S.RES ERJ3GEYJ 392 V (3.9 kΩ)
R5045 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R5047 7310004530 S.TRI EVM-2WSX80 B14 (103)
7030003270 S.RES ERJ3GEYJ 390 V (39 Ω)
R5049
R5050 7030003580 S.RES ERJ3GEYJ 153 V (15 kΩ)
R5051 7030003800 S.RES ERJ3GEYJ 105 V (1 MΩ)
R5052 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ) [AUS], [UK], [USA-1] only
R5053 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5054 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5055 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5058 7030003630 S.RES ERJ3GEYJ 393 V (39 kΩ)
R5059 7030003630 S.RES ERJ3GEYJ 393 V (39 kΩ)
R5060 7030003630 S.RES ERJ3GEYJ 393 V (39 kΩ)
7030003400 S.RES ERJ3GEYJ 471 V (470 Ω)
R5061
R5062 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5063 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5064 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5065 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5066 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5070 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R5071 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R5072 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5074 7030003650 S.RES ERJ3GEYJ 563 V (56 kΩ)
R5075 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R5076 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R5077 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R5078 7030003630 S.RES ERJ3GEYJ 393 V (39 kΩ)
R5082 7210002670 VAR RV-298 (TP96D00N15F10KB10KA)
R5083 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5084 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R5085 7030003600 S.RES ERJ3GEYJ 223 V (22 kΩ)
R5086 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5087 7310004590 S.TRI EVM-2WSX80 B13 (102)
R5088 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R5089 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5090 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R5091 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
7030000170 S.RES MCR10EZHJ 18 Ω (180)
R5092
R5093 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R5097 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R5098 7310004670 S.TRI EVM-2WSX80 B55 (504)
R5099 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ)
R5100 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ)
R5101 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
7030003320 S.RES ERJ3GEYJ 101 V (100 Ω)
R5102
R5103 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
DESCRIPTION
[AUS], [UK], [USA-1] only
[MAIN UNIT]
REF ORDER
NO. NO.
R5104 7030003540 S.RES ERJ3GEYJ 682 V (6.8 kΩ)
R5105 7030003700 S.RES ERJ3GEYJ 154 V (150 kΩ)
R5106 7030003880 S.RES ERJ3GEYJ 244 V (240 kΩ) [AUS], [UK], [USA-1] only
R5107 7030003700 S.RES ERJ3GEYJ 154 V (150 kΩ)
R5108 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R5112 7030003700 S.RES ERJ3GEYJ 154 V (150 kΩ)
R5113 7030003600 S.RES ERJ3GEYJ 223 V (22 kΩ) [AUS], [UK], [USA-1] only
R5114 7310004540 S.TRI EVM-2WSX80 BQ4 (473)
R5115 7030003590 S.RES ERJ3GEYJ 183 V (18 kΩ) [AUS], [UK], [USA-1] only
R5116 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
7030003340 S.RES ERJ3GEYJ 151 V (150 Ω)
R5117
R5118 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ)
R5120 7510001000 S.TMR TBPS1R154K475H5Q
R5121 7030003760 S.RES ERJ3GEYJ 474 V (470 kΩ) [AUS], [UK], [USA-1] only
R5123 7510000990 S.TMR TBPS1R682K440H5Q
R5124 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R5125 7030003710 S.RES ERJ3GEYJ 184 V (180 kΩ)
R5126 7030003710 S.RES ERJ3GEYJ 184 V (180 kΩ)
R5127 7030003800 S.RES ERJ3GEYJ 105 V (1 MΩ) [AUS], [UK], [USA-1] only
R5128 7030003660 S.RES ERJ3GEYJ 683 V (68 kΩ)
R5129 7030003650 S.RES ERJ3GEYJ 563 V (56 kΩ) [AUS], [UK], [USA-1] only
R5130 7030003770 S.RES ERJ3GEYJ 564 V (560 kΩ) [AUS], [UK], [USA-1] only
C5001 4030007030 S.CER C1608 CH 1H 150J-T
C5002 4030007030 S.CER C1608 CH 1H 150J-T
C5004 4030006900 S.CER C1608 JB 1H 103K-T
C5005 4030006860 S.CER C1608 JB 1H 102K-T
C5006 4030006900 S.CER C1608 JB 1H 103K-T
C5007 4030006900 S.CER C1608 JB 1H 103K-T
C5008 4030006900 S.CER C1608 JB 1H 103K-T
C5010 4030006870 S.CER C1608 JB 1H 222K-T
C5011 4030006900 S.CER C1608 JB 1H 103K-T
C5012 4030006860 S.CER C1608 JB 1H 102K-T
C5013 4510004440 S.ELE ECEV1HA010SR
C5014 4510005810 S.ELE ECEV1HAR47R
C5015 4030006850 S.CER C1608 JB 1H 471K-T
C5016 4510005870 S.ELE ECEV1HA3R3SR
C5017 4510005320 S.ELE ECEV0JA101SP
C5018 4030008920 S.CER C1608 JB 1H 473K-T
C5020 4510005370 S.ELE ECEV1AA221P
C5021 4510005860 S.ELE ECEV1HA2R2SR
C5024 4510005740 S.ELE ECEV1HAR22SR
C5025 4510004630 S.ELE ECEV1CA100SR
C5026 4510005810 S.ELE ECEV1HAR47R
C5030 4030007130 S.CER C1608 CH 1H 101J-T
C5031 4030006860 S.CER C1608 JB 1H 102K-T
C5032 4030006860 S.CER C1608 JB 1H 102K-T
C5033 4030006900 S.CER C1608 JB 1H 103K-T
C5034 4030006900 S.CER C1608 JB 1H 103K-T
C5040 4030008920 S.CER C1608 JB 1H 473K-T
C5043 4550006220 S.TAN TEESVA 0J 156M8L
C5045 4510005860 S.ELE ECEV1HA2R2SR
C5046 4510004630 S.ELE ECEV1CA100SR
C5048 4030008650 S.CER C1608 JB 1H 332K-T
C5049 4030006900 S.CER C1608 JB 1H 103K-T
C5050 4030007160 S.CER C1608 CH 1H 181J-T
C5051 4550006150 S.TAN ECST1CY105R
C5052 4510005630 S.ELE ECEV1EA330SP
C5053 4030006860 S.CER C1608 JB 1H 102K-T
C5054 4030006860 S.CER C1608 JB 1H 102K-T
C5055 4510005430 S.ELE ECEV0JA220SR
C5056 4510005430 S.ELE ECEV0JA220SR
C5057 4510005430 S.ELE ECEV0JA220SR
C5058 4510005430 S.ELE ECEV0JA220SR
C5059 4510005430 S.ELE ECEV0JA220SR
C5060 4030006900 S.CER C1608 JB 1H 103K-T
C5062 4510004630 S.ELE ECEV1CA100SR
C5063 4030006900 S.CER C1608 JB 1H 103K-T
C5064 4030006860 S.CER C1608 JB 1H 102K-T
C5066 4030006900 S.CER C1608 JB 1H 103K-T
C5067 4030006900 S.CER C1608 JB 1H 103K-T
C5068 4030006860 S.CER C1608 JB 1H 102K-T
C5069 4030006860 S.CER C1608 JB 1H 102K-T
C5070 4030006860 S.CER C1608 JB 1H 102K-T
C5071 4030006860 S.CER C1608 JB 1H 102K-T
C5072 4550006370 S.TAN ECST0JX226R
C5073 4030006860 S.CER C1608 JB 1H 102K-T
C5074 4030006860 S.CER C1608 JB 1H 102K-T
C5076 4030006880 S.CER C1608 JB 1H 472K-T
C5077 4510004630 S.ELE ECEV1CA100SR
C5079 4030006850 S.CER C1608 JB 1H 471K-T
C5080 4030010070 S.CER C1608 JB 1H 471K-T
C5081 4030006900 S.CER C1608 JB 1H 103K-T
C5082 4550006220 S.TAN TEESVA 0J 156M8L
C5083 4550006360 S.TAN ECST1VY104R
C5084 4030010070 S.ELE ECEV1CA101P
C5085 4510005820 S.ELE ECEV1CA101P
C5086 4510004440 S.ELE ECEV1HA010SR
C5088 4030006860 S.CER C1608 JB 1H 102K-T
5 - 3
DESCRIPTION
[AUS], [UK], [USA-1] only
[AUS], [UK], [USA-1] only
[AUS], [UK], [USA-1] only
S.=Surface mount
