Control Panel Drawing No. 0H3635-C
ITEM PART NO.
QTY.
1
045757
1
2
0F5458
2
3
023484S
1
4
0G9081*
1
5
049813
1
6
022473
2
7
0A1658
1
8
0G3380
1
9
0F9176
28.75"
10
0G3662A
1
11
028414
1
12
0D3700
5
13
0G5225
1
14
028916
1
15
087769
1
16
025965
1
17
022097
2
18
0G5318
1
0H3634
1
19
0G4602
1
20
0C7968
3
21
022237
2
22
0A4456
1
23
0C7423
1
24
022259
2
25
022129
2
26
022145
1
27
0E0593
1
28
0D8502
1
29
0G5233
2
30
0G3825
1
31
0G3689
1
32
092036
4
33
0A9611
1
34
032300
1
35
0G4215
1
DESCRIPTION
SCREW HHC M6-1.0 X 25 G8.8
SCREW PLASTITE HI-LOW #10X3/8
BUSHING SNAP SB-1093-937
WIRE HARNESS C/PNL FRAME
NUT HEX M6 X 1.0 G8 YEL CHR
WASHER FLAT 1/4-M6 ZINC
WASHER LOCK SPECIAL 1/4"
FUEL PUMP MOUNTING BRACKET
HOSE,1/4" SAE30R7
CLAMP HOSE BAND .50
BARBED STR 1/8NPT X 1/4
NUT FLANGE M6-1.0 NYLOK
FUEL PUMP
ELBOW 90D STREET 1/8 BRASS
FILTER FUEL 1/8P-1/4H
SCREW HHC 1/4-20 X 2-1/4" G5
WASHER LOCK M6-1/4
AC HARNESS 530RV (5500 + 6500W)
AC HARNESS 530RV EVAP (4500W)
GROMMET, DOUBLE SLIT
NUT HEX JAM 3/8-16 BRASS
WASHER LOCK 3/8
WASHER LOCK SPECIAL 3/8
STUD 3/8-16 X 2-1/4 BRASS
NUT HEX 5/16-18 STEEL
WASHER LOCK M8-5/16
WASHER FLAT 5/16-M8 ZINC
STUD, 1/4-20 TO 5/16-18
NEUTRAL CONNECTOR UL
SCREW PPHTF #8-18 X 1/2 AB
CONTROL PANEL COVER
C/PNL FACE
SCREW PPHM #6-32 X 1/4 SEMS
FUSE 7.5AXBK/AGC7.5NX
HOLDER FUSE
SWITCH RKRSPDT(ON)OFF(ON)ILLUM
Exploded Views & Parts Lists
ITEM PART NO.
QTY.
36
082025
4
37
0F9719
1
38
0G3977
1
39
0G3530
1
40
075476
2
41
090987
2
42
0C2174
1
43
031879
2
44
0D9784
2
45
075235
4
46
074908
4
47
075210A
1
48
0E6480
2
49
090144 (5500W) 1
090145 (6500W) 1
50
090145
1
51
0C2417A
1
52
0G5986
1
53
061669
1
54
059502
1
55
069598
1
56
035579
1
57
035483
1
58
0G0247
1
59
028740
1
*HARNESS NOT SHOWN
DESCRIPTION
NUT HEX LOCK M5-0.8 NYINS ZINC
ASSY PCB VREG AIR COOLED 2006
ASSY PCB RV CONTROLLER
C/PNL FRAME RV
SCREW PPHM M4-0.7 X 16
SCREW PPHM M3-0.5 X 12
RELAY 12V 25A SPST
WASHER FLAT #4 ZINC
NUT HEX LOCK M3-0.5 NY INS
SCREW HHC M5-0.8 X 30 G8.8
SCREW HHTT M5-0.8 X 10 BP
BLOCK 1 POSITION, 4 TAB
NUT HEX LOCK M4-0.7 NY INS
CIRCT BRK 20X1 MAG 10-32 CARL
CIRCT BRK 30X1 MAG 10-32 CARL
CIRCT BRK 30X1 MAG 10-32 CARL
(4500W, 5500W, 6500W)
EARTH STRAP
NYLON SPACER .26 X 1.00 X 1.73
PLUG, PLASTIC .75 (5410-1/5412-
1/5414-1 ONLY)
BARBED EL 90 ¼ NPT X 5/16
(5751/5752/5753 ONLY)
BULKHEAD ADAPTER
(5751/5752/5753 ONLY)
BUSHING REDUCER HEX ¼ TO 1/8 NPT
(5751/5752/5753 ONLY)
NIPPLE PIPE 1/8 NPT X 1 ½
(5751/5752/5753 ONLY)
SOLENOID 12 VDC (5751/5752/5753
ONLY)
BARBED EL 90 1/8 NPT X ¼
(5751/5752/5753 ONLY)
43
