MAINTENANCE
Steering System

Ski Skags

WARNING! Worn skis and/or skags will adversely affect handling. Loss of
vehicle control may result, causing serious injury or death. See your dealer's
studding chart for recommended skags. If you install longer or more aggressive
carbide skags than the original equipment, it may also be necessary to add track
studs to maintain proper vehicle control while turning on hard-packed snow or
ice.
Check skags before each use of the snowmobile to ensure positive
steering characteristics. Skags must be replaced when worn to half their
original diameter.
TIP: Carbide skags must be replaced if any abnormal wear or chipping is found.
Skag Replacement
1. Raise and support the front of the snowmobile so the skis are
approximately 6 inches (15.2 cm) from the ground.
2. Remove the attaching nuts and pry the skag downward.
3. Remove the front end of the skag.
4. Remove the rear end of the skag.
5. Reverse the steps to install a skag.

Rail Slide Wear

For ease of inspection, all
POLARIS rail slides have
a wear limit indicator
Minimum
groove to indicate the
Thickness
minimum permissible slide
thickness. Replace the rail
slides if they are worn to
the top of the groove at any
point along their length.
Failure to do so may result
Replace when
in permanent damage to
worn to top of
the track or rails.
groove
