Panasonic NA-F78B2 Service Manual

Service Manual

The service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt within this service information by anyone
else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that
these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire or other hazards. Do
not modify the original design without permission of manufacturer.
Fully Automatic Washing Machine
WARNING
IMPORTANT SAFETY NOTICE
© Panasonic Home Appliances (Thailand) Co., Ltd. 2010.
All rights reserved. Unauthorized copying and distribution
is a violation of law.
Order No. PHAT100601CE
(Revision : Oct. 2011)
Thailand, Indonesia, Vietnam, Malaysia, India
Singapore (Local), Singapore (Export)
Philippines, UAE (Local), Kuwait
Qatar, Oman, Bahrain, Lebanon
NA-F78B2
NA-F80B2
NA-F80H2
NA-F90B2
NA-F90H2
NA-F1002B
Product Colour
Silver (A)
White (D)
Grey (J)
Destination
UAE (PGF), Libya
