Specifications - Echo PB-403H Operator's Manual

26
S
PECIFICATIONS
MODEL ----------------------------------------------------- PB-403H, PB-403T
Length ------------------------------------------------------- 325 mm (12.8 in.)
Width PB-403H --------------------------------------------- 515 mm (20.3 in.)
Width PB-403T --------------------------------------------- 520 mm (20.5 in.)
Height PB-403H -------------------------------------------- 440 mm (17.3 in.)
Height PB-403T -------------------------------------------- 490 mm (19.3 in.)
Weight (dry) PB-403H ------------------------------------ 9.76 kg (21.5 lb.)
Weight (dry) PB-403T ------------------------------------ 9.4 kg (20.7 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Displacement ----------------------------------------------- 44.0 cc (2.69 cu. in.)
Bore ---------------------------------------------------------- 40.0 mm (1.574 in.)
Stroke -------------------------------------------------------- 35.0 mm (1.378 in.)
Carburetor -------------------------------------------------- Zama w/primer bulb
Ignition System -------------------------------------------- Flywheel Magneto, capacitor discharge ignition type
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Exhaust System -------------------------------------------- Spark Arrestor Muffler w/catalyst
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50:1 two-stroke air cooled engine oil
Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
TM
Oil ------------------------------------------------------------ Power Blend Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 1.75 lit. (64.3 US fl. oz.)
Recoil Starter System -------------------------------------- Automatic Recoil Starter Centrifugal Type
Idle Speed --------------------------------------------------- 2300 - 3200 (RPM)
Wide Open Throttle Speed ------------------------------- 6200 - 8200 (RPM)
Maximum Air Speed (Measured at pipe end) ---------- 282 KM/H (175 mph)
Average Air Volume (Measured at pipe end) ---------- 10.8 cu. m/min. (380 cu. ft./min.)
Sound level at 50 ft. dB(A) scale per ANSI B175.2 ----- 71 dB(A)
