Emerson EPT427 Owner's Manual

L1522EN.QX33 01.7.19 6:30 PM Page 1
EMERSON VIDEO HOME ENTERTAINMENT WARRANTY
We appreciate your purchase of a Emerson Home Entertainment product. We take pride in the quality of our prod-
ucts and have manufactured your new Home Entertainment unit to exacting quality standards. We feel confident
that in normal use, it will provide you with satisfactory performance. However, should you experience difficulty,
you are protected under the provisions of this warranty.
Emerson Home Entertainment products are warranted against manufacturing defects in materials and workmanship
in normal use for the following periods from the date of purchase by the original user, and is conditional upon the
unit being installed and used as directed in the instruction manual.
Product Labour
Colour Televisions 1 Year
Remote Control 90 Days
Emerson's obligation under this warranty shall be limited to the repair, including all necessary parts and the cost of
the labour connected therewith, or at our option the exchange of any Home Entertainment product which shows
evidence of a manufacturing defect within the warranty period.
Replacement parts, furnished in connection with this warranty shall be warranted for a period equal to the unex-
pired portion of the original equipment warranty.
CUSTOMER OBLIGATIONS
This warranty applies to the product from the original date of purchase at retail. Therefore, the owner must pro-
vide a copy of the original, dated bill of sale. No warranty service will be performed without a bill of sale.
Transportation to and from the service depot is the responsibility of the owner.
WARRANTY EXCLUSIONS
This warranty is extended to Emerson Home Entertainment products purchased and used in Canada. This warran-
ty shall not apply to appearance or accessory items including but not limited to: antenna, cabinet, cabinet parts,
knobs, batteries, connecting cables. This warranty shall, in addition, not apply to damages due to handling, trans-
portation, unpacking, set-up, installation, customer adjustments that are covered in the instruction book, repair or
replacement of parts supplied by other than the Emerson authorized service depot, any malfunction or failure
caused by or resulting from abnormal environmental conditions, improper unauthorized service, improper mainte-
nance, modifications or repair by the consumer, abuse, misuse, neglect, accident, fire, flood, or other Acts of God,
and incorrect line voltage.
This Home Entertainment product is only warranted to the original retail purchaser. This warranty becomes void
in the event of commercial or rental use. This warranty becomes void in the event serial numbers are altered,
defaced or removed.
Emerson reserves the right to make changes in design or to make additions to or improvements upon this product
without incurring any obligation to install the same on products previously manufactured. The foregoing is in lieu
of all other warranties expressed or implied and Emerson neither assumes nor authorizes any person to assume for
it any other obligation or liability in connection with the sale or service of this product. In no event shall Emerson
or its Emerson dealers be liable for special or consequential damage arising from the use of this product, or for any
delay in the performance of this warranty due to cause beyond our control.
The purchaser may have other rights under existing provincial or federal laws, and where any terms of this war-
ranty are prohibited by such laws, they are deemed null and void, but the remainder of the warranty shall remain in
effect.
HOW TO OBTAIN SERVICE
Should this product require service, you may obtain specific information on how to obtain service by contacting the
Emerson Dealer from whom this product was purchased, or by contacting us directly:
SONIGEM SERVICE
PHONE: (905) 940-5089
0EMN01872
ANTENNA/CABLE CONNECTIONS
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
VHF
Antenna
(Not supplied)
UHF
Antenna
(Not supplied)
VHF/UHF Combiner
(Not supplied)
VHF/UHF
Combination Antenna
(Not supplied)

CLOSED CAPTION

This TV can receive C1 and C2 Caption and Text.
Caption Mode
(1) Closed Caption Characters can be displayed on the TV screen only when the received broad-
cast signal contains Caption Signals.
(2) Paint-on mode: Displays input characters on the screen immediately.
Pop-on mode: Once characters are stored in memory, they are displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)
Note: If CAPTION C1 or C2 is selected but a Closed Caption signal is not included, characters
will not be displayed.
Text Mode
(1) Displays the text on the screen by scrolling (max. 7 lines)
(2) If the received broadcast signal does not contain caption or text signals, no change will occur.
Parts PictureTube
1 year 3 Years
90 Days ---
300 Alden Road
Markham, Ontario
L3R 4C1
FAX: (905) 940-2303
1 - 800 - 287- 4871
Printed in Malaysia
L1522CC * * * * *
ANT.IN
VIDEO1 INPUT
VIDEO
R L S-VIDEO
ANT. IN
OR
AV input/output (stereo)
Owner's
Manual
FEATURES
Flat Screen Tube and Comb Filter
MTS/SAP Tuner
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic
tuning system provides free and easy channel selection, and lets you tune directly to any chan-
nel using the channel number buttons (0~9 and +100-key) on the remote control.
On-Screen Function Display.
Full-Function Remote Control
Sleep Timer
Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.
Auto Shut Off Function- If there is no air signal input from the antenna terminal and no
user operation for 15 minutes, the TV will turn itself off automatically.
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.
S-VIDEO Input- allows you to get better picture detail and clarity for the playback of S-VHS
VCR tapes or Video Discs.
PRECAUTIONS
Place your TV in a room with adequate ventilation.
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
Do not place your TV on soft surfaces, such as rugs or blankets.
Leave enough room for air to circulate around the bottom, top and back of the set.
NOTE: CHANNEL SET UP MUST BE COMPLETED BEFORE THE SET WILL
FUNCTION PROPERLY. SEE INSIDE FOR PROCEDURE.
The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.
Date of Purchase
Dealer Purchase from
Dealer Address
This Owner's Manual is made of recycled paper.
IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING
AFTER READING OWNER'S MANUAL, PLEASE CALL TOLL FREE
1-800-287-4871.
* Some cable TV systems use scrambled
signals and require a special converter
to receive these channels. Consult your
local cable company.
*
CATV Box
or Satellite Box
(Not supplied)
IN
OUT
From Cable System
or Satellite Antenna
75-ohm
Coaxial Cable
75-ohm
Coaxial Cable
OR
From Cable System
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building as close to the point
of cable entry as practical.
Notes:
(1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a
VCR's video output channel (CH3 or CH4), your TV may not display the correct caption or
text.
(2) Captions and texts may not match the TV voice exactly.
(3) Interference may cause the closed caption system not to function properly.
(4) The caption or text characters will not be displayed while the menu display or functions dis-
play is shown.
(5) If you see this screen:
If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].
27 INCH COLOR TELEVISION
EPT427
"EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS
OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A."
Dealer Phone No.
Model No.
Serial No.
DEGAUSSING :
Magnetism from nearby appliances might affect the
color of the TV picture.
If this happens, move this unit away from the appliance.
If the color is still not correct, press the POWER button
on the set or the remote control to turn off the power
first and then press this button again 30 minutes or so
later to turn on the power.
FCC WARNING- This equipment may generate or
use radio frequency energy. Changes or modifi
cations to this equipment may cause harmful
interference unless the modifications are expressly
approved in the instruction manual. The user could
lose the authority to operate this equipment if an
unauthorized change or modification is made.
