Page 1: Instruction Manual
2 IN 1 18GA. NAILER/STAPLER KIT performance performance plus plus MODEL: 8210NS INSTRUCTION MANUAL COPYRIGHT © 2005 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC. -
Page 2: Proof Of Purchase
Warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations and lack of maintenance. KING CANADA shall in no event be liable for death, injuries to persons or property or for incidental, special or consequential damages arising from the use of our products. -
Page 3: Specifications
Nail/Staple view finder Nail/Staple loading area Safety release SPECIFICATIONS Model ......................................8210NS Air inlet ......................................1/4” NPT Compressed air: Maximum permissible operating pressure ........................120 PSIG (8.3 bar) Recommended operating pressure range ..........................60-100 PSI Nail range ............................3/4” to 2” 18ga. brad head finish nails Staple range ........................3/8”... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Read and understand this manual and all the safety instructions before operating this nailer/stapler. If you have any questions, please contact our authorized service centres or retailers for help. • Never allow the use of flammable gases as a power source for this tool. Use filtered, lubricated and regulated compressed air only. -
Page 5: Lubrication And Maintenance
LUBRICATION AIR SUPPLY AND CONNECTIONS LUBRICATION AND MAINTENANCE • Your nailer/stapler needs to be lubicated before and after the first time you use it. • Disconnect the air supply from the nailer/stapler before lubricating. • Turn the nailer/stapler so that the inlet is facing up and put ONE DROP of high speed spindle oil or oil without detergent into the air inlet. - Page 6 CONTACT SAFETY TRIP MECHANISM OPERATING A CONTACT SAFETY TRIP TOOL: • The operator is required to have the finger off the trigger and the nose of the nailer/stapler to be placed on the workpiece. • The contact safety trip mechanism is then depressed against the workpiece and the trigger is pulled to drive the nail or staple.
-
Page 7: Clearing Jams
LOADING NAILER/STAPLER & CLEARING JAMS LOADING NAILER/STAPLER MAGAZINE • Disconnect the air hose from the nailer/stapler air inlet. • Depress the magazine latch, pull back on the magazine cover. • Place nails or staples into the magazine. If you insert a stick of nails, make sure the pointed ends are as close to the bottom edge of the magazine as possible, ensuring the head of the nail is aligned with the appropriate machined groove in the magazine. - Page 8 OPERATING YOUR NAILER/STAPLER OPERATING YOUR NAILER/STAPLER WARNING! protect your eyes and ears. Wear Z87 safety glasses with side shields. Wear hearing protection. Employers are responsible for ensuring the user or anyone near the nailer/stapler wears the above mentioned safety protection. WARNING! Check and replace any damaged or worn components.
-
Page 9: Maintenance And Troubleshooting
Accessory Kit is available for your Nailer/stapler (model: KW-080). Contact your local King Canada distributor for more information. PARTS DIAGRAM & PARTS LISTS Refer to the Parts section of the King Canada web site for the most updated parts diagram and parts list. KW-080...
