NOTE : Specifications and others are subject to change without notice for improvement.
1. Application range
This specification is applied all of the DLP Projector FM12A chassis.
2. Requirement for Test
* Each part is tested as below without special appointment.
(1) Temperature : 25 ºC ± 5 ºC, CST : 40 ºC ± 2 ºC
(2) Relative Humidity : 65 % ± 10 %
(3) Power Voltage : Standard input voltage (100 V - 240 V @ 50 Hz / 60 Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with
BOM.
(5) The receiver must be operated for about 30 minutes prior to the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Required other specification
- Safety : UL, CSA, IEC, CE specification(EN55022 Class B)
- EMC : FCC, ICES, IEC, CE specification(EN60950-1)
4. General Specification
No. Item
1. Video input applicable system
2. Power
3. Input Voltage
4. Market
5. Picture size
6. Aspect ratio
7. Operating Temperature
8. Operating Humidity
9. Storage Temperature
10. Storage Humidity
Copyright © 2011 LG Electronics. Inc. All right reserved.
Only for training and service purposes

SPECIFICATION

Specification
Min Max
1) NTSC M
Adapter - DC 19.5 V @ 5.64 A (110 W)
AC 100 V ~ 240 ( ± 10 %) V, 50 Hz / 60 Hz
North America
WXGA (1280 x 800)
16:10
0 40
80
-20 60
85
- 4 -
Unit 3.579545 / 60 Hz
deg
%
deg
%
Remark
