- Page 1 REPAIR PARTS MANUAL MODEL NO. MC19538LT (96048002300) LAWN TRACTOR 02.13.12 BD 532 44 85-28 Printed in the U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “TRACTOR” • MODEL NUMBER - “MC19538LT (96048002300)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK... -
Page 4: Electrical
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 ELECTRICAL T02K With 12V Outlet Option With Service Minder Option... - Page 5 TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 12 Volt 25 Amp 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38...
-
Page 6: Chassis
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 CHASSIS Chassis-tex_ALPHA_4... -
Page 7: Chassis
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 CHASSIS PART DESCRIPTION 532 41 17-64 Dash 532 40 61-79 Hood 532 42 67-41 Grille 532 19 54-02 Lens Bar 532 44 72-53 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4... -
Page 8: Drive
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 DRIVE drive-tex_peerless_fender_47... - Page 9 TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transaxle, Peerless 206-565 876 02 04-12 Pin Cotter 1/8 x 3/4 (197941)(Order parts from transaxle 532 16 94-84 Retainer Clip manufacturer.)
-
Page 10: Engine
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tex_BS_62... -
Page 11: Engine
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 ENGINE KEY PART DESCRIPTION – – – – – – Engine Briggs Model No. 31P677-1517-G5 (442254)(Order parts from engine manufacturer.) 532 13 73-52 Muffler 532 19 43-19 Keeper Belt Engine... -
Page 12: Steering
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 STEERING steering-tex_STDHRS_14... -
Page 13: Steering
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 STEERING PART DESCRIPTION 532 42 45-43 Wheel, Steering 532 41 81-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23... -
Page 14: Mower Deck
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 MOWER DECK 38-7_Tex-LT_8_r1... - Page 15 TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 14 10-43 Guard, Tuv Idler 532 19 42-51 Mower Housing 532 19 94-71 Arm Brake Mower 532 19 51-86 Arm Suspension 532 19 94-70...
-
Page 16: Mower Lift
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 MOWER LIFT lift-tex_29 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm.,Cross Lift 817 00 06-12 Screw 3/8-16 x .75 Smgml Tap/R.Z 532 19 52-31 Lever Asm., Lift RH... -
Page 17: Seat
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 SEAT seat-tex_knob_1 PART PART DESCRIPTION DESCRIPTION 532 40 30-17 Seat 532 13 43-00 Spacer Split 532 18 01-66 Bracket Pivot Fender 532 12 37-40 Spring CPRSN Plate SW 1.310 Ga. -
Page 18: Decals
TRACTOR - MODEL NO. MC19538LT (96048002300), PRODUCT NO. 960 48 00-23 PART PART DESCRIPTION DESCRIPTION 532 44 82-55 Decal, Replacement 532 43 79-66 Decal, Wheel Strg. 532 43 52-86 Decal, Warn. Spark 532 17 05-63 Decal, Defl. Warning 532 44 84-65... - Page 19 SERVICE NOTES...
-
Page 20: Warranty
This Warranty gives you specific legal rights, and you may have other rights which vary from locale to locale. This is a limited Warranty within the meaning of that term as defined in the Magnuson-Moss Act of 1975. www.mcculloch.biz...
