Panasonic SA-AKX54LM-K Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Please refer to the original service manual for:
CD Mechanism Unit (BRS11C), Order No. PSG1201019AE
Speaker system SB-AKX54LM-K, Order No. PMX1207006CE
CD Stereo System
SA-AKX54LM-K
Model No.
Product Color: (K)...Black Type
© Panasonic Corporation 2012. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
PMX1207005CE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-AKX54LM-K

Summary of Contents for Panasonic SA-AKX54LM-K

  • Page 1 Product Color: (K)...Black Type Please refer to the original service manual for: CD Mechanism Unit (BRS11C), Order No. PSG1201019AE Speaker system SB-AKX54LM-K, Order No. PMX1207006CE © Panasonic Corporation 2012. All rights reserved. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    Please refer to the original service manual for: CD Mechanism Unit (BRS11C), Order No. PSG1201019AE Speaker system SB-AKX54LM-K, Order No. PMX1207006CE Nota: El idioma original de este Manual de Servicio es en idioma inglés, sin embargo algunas notas aquí mencionadas serán escritas en español para mejor descripción para Centros de Servicio de México. TABLE OF CONTENTS 1 Safety Precautions 3 Service Navigation...
  • Page 3 8.3. Reliability Test Mode (CD Mechanism Unit 16.1. Schematic Diagram Notes (BRS11C)) 16.2. CD Servo Circuit 8.4. Self-Diagnostic Mode 16.3. Main(MICON) Circuit 8.5. Self-Diagnostic Error Code Table 16.4. Main(D-Amp) Circuit 8.6. Sales Demonstration Lock Function 16.5. Panel Circuit 9 Troubleshooting Guide 16.6.

  • Page 4: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 5: Protection Circuitry

    1.4. Protection Circuitry The protection circuitry may have operated if either of the following conditions are noticed: No sound is heard when the power is turned on. Sound stops during a performance. The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.

  • Page 6: Safety Parts Information

    1.6. Safety Parts Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.

  • Page 7: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...

  • Page 8: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 W/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 9: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 10: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.

  • Page 11: Grounding For Electrostatic Breakdown Prevention

    Grounding for electrostatic breakdown prevention 2.4.2. Some devices such as the DVD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electric- ity in the working environment. Proceed servicing works under the working environment where grounding works is completed. 2.4.2.1.

  • Page 12: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 13: Specifications

    4 Specifications ó i ó i ñ é t i b i d i l o t l Ω ó Ω s t i ó i Ω Ω ó i l a t é t ó i ó i ó i á...

  • Page 14: General/Introduction

    5 General/Introduction 5.1. Media Information...

  • Page 15: Location Of Controls And Components

    6 Location of Controls and Components 6.1. Remote Control Key Button Operation...

  • Page 16: Main Unit Key Button Operation

    6.2. Main Unit Key Button Operation...

  • Page 17: Installation Instructions

    7 Installation Instructions 7.1. Speaker and A/C Connection ó los bafles. ó i c i t Bafles frontales ó a í . c i á t i l a ó i á r á r Corriente alterna = ó i Para México: ca ó...

  • Page 18: Service Mode

    8 Service Mode 8.1. Cold-Start Here is the procedure to carry out cold-start or initialize to shipping mode. 1. Unplug AC power cord 2. Press & hold [POWER] button 3. Plug AC power cord while [POWER] button being pressed FL Display will show “_ _ _ _ _ _ _ _” 4.

  • Page 19: Doctor Mode Table

    8.2. Doctor Mode Table 8.2.1. Doctor Mode Table 1...

  • Page 20: Doctor Mode Table

    8.2.2. Doctor Mode Table 2 Item Key Operation FL Display Mode Name Description Front Key Volume Setting To check the volume setting of a main In Doctor Mode : Check unit. 1. Press [7], [8], [9] button on remote control. Press [7]: VOL50 Vo lume Press [8]: VOL35...
  • Page 21 8.2.3. Doctor Mode Table 3 Item Key Operation FL Display Mode Name Description Front Key i. Function: To display result of In Doctor Mode: Self- Adjustment self-adjustment for CD . 1. Press [10] [1] [4] button on remote control . (AJST) This is used for servicing Result Display...

  • Page 22: Reliability Test Mode (Cd Mechanism Unit (Brs11C))

    8.3. Reliability Test Mode (CD Mechanism Unit (BRS11C)) Below is the process flow chart of the aging test for the CD Mechanism Unit (BRS11C). OPEN First Track Operation Access OPEN wait First Track for 1 s Play 5 s CLOSE Count up Last Track Operation...

  • Page 23: Self-Diagnostic Mode

    8.4. Self-Diagnostic Mode Item Key Operation FL Display Mode Name Description Front Key Self Diagnostic To enter into self diagnostic checking Step 1: Select CD mode Mode (Ensure no disc is inserted). Step 2: Press & hold [ ] follow by ] on main unit for 2 seconds.

  • Page 24: Sales Demonstration Lock Function

    8.5.2. CD Mechanism Error Code Table (CD Mechanism Unit (BRS11C)) Error Code Diagnostic Contents Description of error Automatic FL Display Remarks CD H15 CD Open Abnormal During operation Press [ ] on main unit for POS_SW_R On fail to be next error.

  • Page 25: Troubleshooting Guide

    9 Troubleshooting Guide 9.1. Part Location 9.1.1. SMPS P.C.B. AC Inlet : P5701 Fuse : SMPS Control IC : Photocoupler : IC5799 PC5702, PC5799 Switching Regulator IC : Thermistor : IC5701 Sub Transformer : TH5861 D5798 Sub Transformer : T5751 Rectifier Diode : D5801, D5802 Photocoupler :...
  • Page 26 9.1.2. Main P.C.B. (Front side) Fig. 2 Main P.C.B.
  • Page 27 9.1.3. Main P.C.B. (Back Side) Resistor Defective Resistor Defective Resistor Defective R5702 R5804 R5805 Resistor Defective Resistor Defective R5705 R5802 Resistor Defective Resistor Defective R5803 R5704 Resistor Defective R5703 Audio Digital Amp IC Audio Digital Amp IC IC5800 IC5700 D2004 Regulator Circuit L2000 Voltage Regulator IC...

  • Page 28: Troubleshooting Guide For F61 And/Or F76

    9.2. Troubleshooting Guide for F61 and/or F76 This section illustrates the checking procedures when upon detecting the error of “F61” and/or “F76” after power up of the unit. It is for purpose of troubleshooting and checking in SMPS & Main P.C.B. Symptom Checking Items Possible Fault(s)

  • Page 29: D-Amp Ic Operation & Control

    9.3. D-Amp IC Operation & Control...
  • Page 30 1170 ~ 1250 1260 ~ 1450 1460 ~ 1540 1550 ~ 1710 Table 4: F_HOP Control during 10 kHz Step Note: During activating, the 3 control pins namely MUTE_F, MUTE_A and MODE_DA must be used to cover the “Pop” sound cause by F-HOP switching.

  • Page 31: Service Fixture & Tools

    10 Service Fixture & Tools Prepare service tools before process service position. Ref. No Service Tools Remarks SFT1 Main P.C.B. (CN2007) - SMPS P.C.B. (CN5802) REX1527(15P Cable Wire)

  • Page 32: Disassembly And Assembly Instructions

    11 Disassembly and Assembly Instructions • Illustration is based on SA-AKX54LM-K. Caution Note: • This section describes the disassembly and/or assembly procedures for all major printed circuit boards & main compo- nents for the unit. (You may refer to the section of “Main components and P.C.B Locations” as described in the service manual) •...

  • Page 33: Disassembly Flow Chart

    11.1. Disassembly Flow Chart 11.3 . Top Cabinet 11.23. CD Mechanism Unit 11.4 . Front panel Unit 11.12. Main P. C.B. (BRS11C ) 11.13. Voltage Regulator 11.24. CD Interface P.C.B. 11.5 . MIC P.C.B. IC (IC2010) 11.25 CD Servo P. C.B. 11.14.

  • Page 34: Main Components And P.c.b. Locations

    11.2. Main Components and P.C.B. Locations...

  • Page 35: Disassembly Of Top Cabinet

    11.3. Disassembly of Top Cabinet Step 4 Slightly lift up both side of the Top Cabinet in an outward direction as shown. Step 1 Remove 2 screws on each side. Step 5 Remove the Top Cabinet. Step 2 Remove 5 screws. Step 3 Slightly pull both side of the Top Cabinet outwards as arrow shown.

  • Page 36: Disassembly Of Front Panel Unit

    11.4. Disassembly of Front Panel Step 4 Push inwards slightly at the Bottom Chassis as arrow shown and release tab at left side of the Front Panel Unit. Unit • Refer to “Disassembly of Top Cabinet”. Step 1 Detach 27P FFC at the connector (CN2003) on the Main P.C.B.

  • Page 37: Disassembly Of Mic P.c.b

    Step 6 Push inwards slightly at the Bottom Chassis and release 11.5. Disassembly of Mic P.C.B. tab at right side of the Front Panel Unit. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove the Mic knob.

  • Page 38: Disassembly Of Panel P.c.b

    11.6. Disassembly of Panel P.C.B. Step 5 Release catches by following the sequences (1-11). • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Mic P.C.B.”. Step 1 Remove the Volume Knob. Step 2 Remove the Skip Knob.

  • Page 39: Disassembly Of Memory Led P.c.b

    Step 7 Desolder 4P Cable Wire at the connector (ZJ6002) on 11.7. Disassembly of Memory LED the Panel P.C.B.. P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Panel P.C.B.”. Step 1 Release 2 catches.

  • Page 40: Disassembly Of Remote Sensor P.c.b

    11.8. Disassembly of Remote Sensor 11.9. Disassembly of USB P.C.B. P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Panel P.C.B.”. •...

  • Page 41: Disassembly Of Music Port P.c.b

    11.10. Disassembly of Music Port 11.11. Disassembly of CD Lid P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove the spring as arrow shown in order of sequence (1) to (3).

  • Page 42: Disassembly Of Main P.c.b

    11.12. Disassembly of Main P.C.B. Step 3 Remove 1 screw. Step 4 Slightly lift up the Main P.C.B. from the slots at the Bot- • Refer to “Disassembly of Top Cabinet”. tom Chassis according to arrow shown. • Refer to “Disassembly of Front Panel Unit”. Step 1 Detach 15P Cable Wire at the connector (CN5802) on the SMPS P.C.B..

  • Page 43: Replacement Of Voltage Regulator Ic (Ic2010)

    Step 5 Detach 2P Wire at the connector (CN2005) on the Main 11.13. Replacement of Voltage Regu- P.C.B.. lator IC (IC2010) • Refer to “Disassembly of Main P.C.B.”. 11.13.1. Disassembly of Voltage Regulator IC (IC2010) Step 1 Desolder pins of the Voltage Regulator IC (IC2010) on the solder side of the Main P.C.B..

  • Page 44: Replacement Of Voltage Regulator Ic (Ic2011)

    11.13.2. Assembly of Voltage Regulator IC 11.14. Replacement of Voltage Regu- (IC2010) lator IC (IC2011) Step 1 Fix the Voltage Regulator IC(IC2010) on Main P.C.B.. • Refer to “Disassembly of Main P.C.B.”. Caution: Ensure pins of the Voltage Regulator IC (IC2010) are properly inserted into the Main P.C.B..

  • Page 45: Replacement Of Audio Digital Amp Ic

    11.14.2. Assembly of Voltage Regulator IC 11.15. Replacement of Audio Digital (IC2011) Amp IC (IC5800) Step 1 Fix the Voltage Regulator IC(IC2011) on Main P.C.B.. • Refer to “Disassembly of Main P.C.B.”. Caution: Ensure pins of the Voltage Regulator IC (IC2011) are properly inserted into the Main P.C.B..

  • Page 46: (Ic5800)

    Step 3 Remove the Heatsink Clip. Step 4 Solder pins of the the Audio Digital Amp IC (IC5800) on Step 4 Remove the Audio Digital Amp IC (IC5800). the solder side of the Main P.C.B.. 11.15.2. Assembly of Audio Digital Amp IC (IC5800) Step 1 Apply grease to the Heatsink.

  • Page 47: Replacement Of Audio Digital Amp Ic

    11.16. Replacement of Audio Digital Step 3 Remove the Heatsink Clip. Step 4 Remove the Audio Digital Amp IC (IC5700). Amp IC (IC5700) • Refer to “Disassembly of Main P.C.B.”. 11.16.1. Disassembly of Audio Digital Amp IC (IC5700) Step 1 Desolder pins of the Audio Digital Amp IC (IC5700) on the solder side of the Main P.C.B..

  • Page 48: (Ic5700)

    11.16.2. Assembly of Audio Digital Amp IC 11.17. Disassembly of SMPS P.C.B. (IC5700) • Refer to “Disassembly of Top Cabinet”. Step 1 Apply grease to the Heatsink. • Refer to “Disassembly of Front Panel Unit”. Step 2 Fix the Audio Digital Amp IC (IC5700) on the Main P.C.B..

  • Page 49: Replacement Of Switching Regulator Ic (Ic5701)

    Step 4 Upset the SMPS P.C.B. and position it according to dia- 11.18. Replacement of Switching Reg- gram shown. ulator IC (IC5701) Step 5 Place the SMPS P.C.B. on an insulated material. Step 6 Desolder Black Wire (TL7) and Red Wire TL8 (Red). •...

  • Page 50: Replacement Of Rectifier Diode (D5702)

    11.18.2. Assembly of Switching Regulator 11.19. Replacement of Rectifier Diode IC (IC5701) (D5702) Step 1 Apply grease to the Heatsink A. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix the Switching Regulator IC (IC5701) to the SMPS 11.19.1. Disassembly of Rectifier Diode P.C.B..
  • Page 51 Step 3 Remove 1 screw at the Switching Regulator IC Step 5 Solder pins of the Rectifier Diode (D5702) on the solder (IC5701). side of the SMPS P.C.B.. Step 4 Remove the Heatsink A with Rectifier Diode (D5702). Step 6 Solder pins of the Heatsink A on the solder side of the Step 5 Remove 1 screw.

  • Page 52: Replacement Of Rectifier Diode (D5801)

    11.20. Replacement of Rectifier Diode Step 3 Remove 1 screw at Rectifier Diode (D5801). Step 4 Remove the Rectifier Diode (D5801) from the SMPS (D5801) P.C.B.. • Refer to “Disassembly of SMPS P.C.B.”. Caution: Avoid touching the Heatsink B due to its high temperature after prolonged use.

  • Page 53: Replacement Of Rectifier Diode (D5802)

    Step 4 Solder pins of the Rectifier Diode (D5801) on the solder 11.21. Replacement of Rectifier Diode side of the SMPS P.C.B.. (D5802) Step 5 Solder pins of the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. 11.21.1. Disassembly of Rectifier Diode (D5802) Step 1 Desolder pins of the Rectifier Diode (D5802) on the sol- der side of the SMPS P.C.B..
  • Page 54 Step 3 Remove 1 screw at Rectifier Diode (D5802). Step 4 Solder pins of the Rectifier Diode (D5802) on the solder Step 4 Remove the Rectifier Diode (D5802) from the SMPS side of the SMPS P.C.B.. P.C.B.. Step 5 Solder pins of the Heatsink B. Caution: Avoid touching the Heatsink B due to its high temperature after prolong use.

  • Page 55: Replacement Of Regulator Diode (D5803)

    11.22. Replacement of Regulator Step 3 Remove 1 screw at Rectifier Diode (D5803). Step 4 Remove the Rectifier Diode (D5803) from the SMPS Diode (D5803) P.C.B.. • Refer to “Disassembly of SMPS P.C.B.”. Caution: Avoid touching the Heatsink B due to its high temperature after prolonged use.

  • Page 56: Disassembly Of Cd Mechanism Unit (Brs11C)

    Step 4 Solder pins of the Rectifier Diode (D5803) on the solder 11.23. Disassembly of CD Mecha- side of the SMPS P.C.B.. nism Unit (BRS11C) Step 5 Solder pins of the Heatsink B. • Refer to “Disassembly of Top Cabinet”. •...
  • Page 57 Step 3 Remove 2 screws. Step 4 Lift up and remove the SMPS Inner Chassis Unit. Step 4 Detach the --------------------from Rear Panel as arrow shown. Caution: During assembling, ensure that the SMPS Inner Chassis is catched onto the Rear Panel properly.

  • Page 58: Disassembly Of Cd Interface P.c.b

    Step 6 Remove 2 screws. 11.24. Disassembly of CD Interface P.C.B. • Refer “Disassembly Mechanism Unit (BRS11C)”. Step 1 Remove 3 screws. Step 2 Desolder pins of the motor (M7301). Step 3 Desolder pins of the motor (M7302). Step 7 Slightly lift up the CD Mechanism Unit (BRS11C) as shown.

  • Page 59: Disassembly Of Cd Servo P.c.b

    11.25. Disassembly Servo 11.26. Disassembly of Rear Panel P.C.B. • Refer to “Disassembly of Top Cabinet”. • Refer “Disassembly Mechanism Unit Step 1 Remove 7 screws. (BRS11C)”. Step 1 Remove 2 screws. Step 2 Detach 30P FFC at the connector (FP8101). Step 3 Remove the CD Servo P.C.B..
  • Page 60 Step 2 Lift up the SMPS Inner Chassis Unit to release the catch between the SMPS Inner Chassis Unit & the Rear Panel. Step 3 Release 2 tabs. Step 4 Remove the Rear Panel.

  • Page 61: Service Position

    12 Service Position 12.2. Checking and Repairing of Note: For description of the disassembly procedures, see the Section 11. Panel P.C.B. 12.1. Checking and Repairing of Step 1 Remove Top Cabinet. Main P.C.B. Step 2 Remove Front Panel Unit. Step 3 Attach 5P Cable Wire to the connector (CN2700) on Step 1 Remove Top Cabinet.
  • Page 62 12.3. Checking and Repairing of Step 8 Extend the Cable Wire with extension Cable Wire (REX1527 15P Cable Wire) from CN2007 on the Main P.C.B. to SMPS P.C.B. CN5802 on the SMPS P.C.B.. Step 1 Remove Top Cabinet. Step 9 SMPS P.C.B. can be checked and repaired as diagram Step 2 Remove Front Panel Unit.

  • Page 63: Checking And Repairing Of Cd Servo P.c.b. (Side A)

    12.4. Checking and Repairing of CD Servo P.C.B. (Side A) Step 1 Remove Top Cabinet. Step 2 Remove Front Panel Unit. Step 3 Remove SMPS Inner Chassis Unit. Step 4 Remove CD Mechanism Unit (BRS11C). Step 5 Remove Main P.C.B.. Step 6 Remove Rear Panel.
  • Page 64 12.5. Checking and Repairing of CD Servo P.C.B. (Side B) • Refer to “Checking and repairing of CD Servo P.C.B. (Side A)”. Step 1 Remove 2 screws. Step 2 Flip the Servo P.C.B. as illustration show.
  • Page 65 Step 3 Place the CD Servo P.C.B. on the insulated material. Step 4 CD Servo P.C.B. Side B can be checked and repaired as diagram shown.

  • Page 75: Schematic Diagram

    16 Schematic Diagram 16.1. Schematic Diagram Notes This schematic diagram may be modified at any time with the development of new technology. Notes: S6000: Radio/EXT-IN switch. S6001: Stop ( ) switch. S6002: Power ( ) switch. S6003: Memory switch. S6004: Play/Pause ( ) switch.
  • Page 100 COMPONENTES DE PISTA MAIN/DAMP/TUNER PSG Ref.No. Part Number Part Name & Description F1H1H102A219 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) F1H1A474A107 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) F1H1H120A230 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) F1H1H120A230 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) F1H1A105A025...
  • Page 101 C2066 F2A1H1R0A213 Aluminum non-solid electrolytic capacitors , lead type C2067 F1H0J105A051 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C2068 F1H0J105A051 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C2070 F1H1A474A107 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C2071 F1H1A474A107 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE)
  • Page 102 C2148 F1H1H223A219 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C2150 F2A1H3R3A213 Aluminum non-solid electrolytic capacitors , lead type C2153 F1J1A106A043 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (2125 TYPE) C2163 F1H1H331A013 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C2165 F1H1C104A042 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type)
  • Page 103 C2280 F1H1C104A042 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) C2281 F1H1C104A042 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) C2282 F1H1C104A042 Surface mounting multilayer ceramic capacitors , rectangular type (1608 type) C5600 F1H1H103A219 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C5601 F1H1H103A219 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE)
  • Page 104 C5735 ECQV1H474JL3 METALLIZED PLASTIC FILM CAPACITORS , LEAD TYPE C5736 F1H1H104B047 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C5737 F1H1H104B047 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C5738 F1H1H103A219 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE) C5740 F1H1H103A219 SURFACE MOUNTING MULTILAYER CERAMIC CAPACITORS , RECTANGULAR TYPE (1608 TYPE)
  • Page 105 D2020 B0EAKM000117 Small capacity silicon rectifier diodes (less than 5 A) D2022 B0EAKM000117 Small capacity silicon rectifier diodes (less than 5 A) D2028 DA2J10100L SWITCHING DIODES D2032 DA2J10100L SWITCHING DIODES D2300 DA2J10100L SWITCHING DIODES D5600 B0ACCK000012 SWITCHING DIODES D5601 B0ACCK000012 SWITCHING DIODES D5602 DZ2J051M0L...
  • Page 106 LB2007 D0GBR00JA008 SURFACE MOUNTING FIXED METAL GLAZE FILM ( THICK FILM ) RESISTORS , RECTANGULAR TYPE Q2001 B1ABCF000231 SILICON TRANSISTORS Q2006 B1GDCFJJ0047 RESISTOR BUILT-IN TYPE TRANSISTORS Q2011 B1GBCFLL0037 RESISTOR BUILT-IN TYPE TRANSISTORS Q2018 B1GBCFJJ0051 RESISTOR BUILT-IN TYPE TRANSISTORS Q2019 B1ADCE000012 SMALL SIGNAL SILICON TRANSISTORS (ALLOWABLE LOSS: LESS THAN 1 W) Q2022 B1AAJC000019...
  • Page 107 R2010 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1 R2011 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1 R2012 ERJ3GEYJ681V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2013 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1...
  • Page 108 R2087 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1 R2093 ERJ3GEYJ392V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2094 ERJ3GEYJ392V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2095 ERJ3GEYJ473V SURFACE MOUNTING FIXED METAL GLAZE FILM (THICK FILM) RESISTORS, RECTANGULAR TYPE...
  • Page 109 R2205 ERJ3GEYJ472V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2206 ERJ3GEYJ472V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2218 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1 R2224 D0GB471JA008 SURFACE MOUNTING FIXED METAL GLAZE FILM ( THICK FILM ) RESISTORS , RECTANGULAR TYPE...
  • Page 110 R2332 ERJ3GEYJ103V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2333 ERG2SJ471E Fixed metal oxide film resistors , lead type R2334 ERG2SJ471E Fixed metal oxide film resistors , lead type R2335 ERJ3GEYJ102V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2336 ERG2SJ471E Fixed metal oxide film resistors , lead type...
  • Page 111 R2413 D0GBR00JA008 SURFACE MOUNTING FIXED METAL GLAZE FILM ( THICK FILM ) RESISTORS , RECTANGULAR TYPE R2415 D0GBR00JA008 SURFACE MOUNTING FIXED METAL GLAZE FILM ( THICK FILM ) RESISTORS , RECTANGULAR TYPE R2421 ERJ3GEYJ153V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R2422 ERJ3GEY0R00V SURFACE MOUNTING OTHER FIXED RESISTORS , RECTANGULAR TYPE ( JUMPER WIRE RESISTOR INCLUDED )1...
  • Page 112 R5708 ERJ3GEYJ101V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R5709 D0GZ220JA012 SURFACE MOUNTING FIXED RESISTORS , RECTANGULAR TYPE R5710 D0GZ220JA012 SURFACE MOUNTING FIXED RESISTORS , RECTANGULAR TYPE R5711 ERJ3GEYJ562V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type R5712 ERJ3GEYJ562V Surface mounting fixed metal glaze film ( thick film ) resistors , rectangular type...
  • Page 113 L6000...

  • Page 116: Cd Servo P.c.b

    18 Appendix Information of Schematic Diagram Voltage & Waveform Chart 18.1. Note: • Indication Voltage Values are in standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in voltage values, depending on the internal impedance of the DC circuit tester. •...
  • Page 117 CD Servo P.C.B. (2/3) 18.1.2. IC8251 REF NO. MODE CD PLAY IC8301 REF NO. MODE CD PLAY IC8401 REF NO. MODE CD PLAY IC8501 REF NO. MODE CD PLAY IC8501 REF NO. MODE CD PLAY IC8501 REF NO. MODE CD PLAY IC8501 REF NO.
  • Page 118 Main P.C.B. (1/4) 18.1.4. REF NO. IC52 MODE TUNER IC2000 REF NO. MODE POWER ON STANDBY REF NO. IC2000 MODE POWER ON STANDBY IC2000 REF NO. MODE POWER ON STANDBY IC2001 REF NO. MODE POWER ON 16.0 STANDBY 16.0 IC2002 REF NO.
  • Page 119 Main P.C.B. (2/4) 18.1.5. IC2003 REF NO. MODE POWER ON STANDBY REF NO. IC2005 MODE CD PLAY 17.8 STANDBY 17.8 IC2006 REF NO. MODE POWER ON STANDBY REF NO. IC2008 MODE POWER ON STANDBY IC2010 REF NO. MODE POWER ON 18.2 STANDBY 18.2 IC2011...
  • Page 120 Main P.C.B. (3/4) 18.1.6. IC5700 REF NO. MODE CD PLAY STANDBY REF NO. IC5800 MODE CD PLAY -11.0 34.5 -32.9 -24.6 35.6 -34.0 -31.0 -34.0 34.6 -34.0 -34.0 34.0 STANDBY -11.0 34.5 -32.9 -24.6 35.6 -34.0 -31.0 -34.0 34.6 -34.0 -34.0 34.0 IC5800 REF NO.
  • Page 121 Main P.C.B. (4/4) 18.1.7. QR2000 QR2003 QR2005 QR2006 REF NO. MODE POWER ON STANDBY REF NO. Q2019 QR2004 MODE STANDBY SA-AKX54 MAIN P.C.B. Panel P.C.B. 18.1.8. IC6000 REF NO. MODE POWER ON -16.2 -16.2 -19.9 -21.9 -20.0 -21.9 -19.9 STANDBY -16.2 -16.2 -19.9 -21.9 -20.0 -21.9 -19.9 REF NO.
  • Page 122 SMPS P.C.B. 18.1.9. IC5701 REF NO. MODE POWER ON 164.8 19.1 STANDBY 164.8 19.1 REF NO. IC5799 MODE POWER ON 11.0 164.2 STANDBY 11.0 164.2 IC5801 REF NO. MODE POWER ON -30.0 STANDBY -30.0 REF NO. IC5899 MODE POWER ON STANDBY Q5720 Q5721...
  • Page 123 18.1.11. Waveform Table 0.1Vp-p(200usec/div) 0.48Vp-p(1usec/div) 2Vp-p(200usec/div) 0.48Vp-p(1usec/div) 1.1Vp-p(50usec/div) 4Vp-p(50nsec/div) 3Vp-p(10usec/div) 0.52Vp-p(1usec/div) 44Vp-p(1usec/div) 2Vp-p(1usec/div) 44Vp-p(1usec/div) 2Vp-p(1usec/div) 0.5Vp-p(2usec/div) 2.5Vp-p(200usec/div) 0.4Vp-p(5usec/div) 2Vp-p(200usec/div) 0.4Vp-p(1usec/div)

  • Page 124: Illustration Of Ics, Transistor And Diode

    Illustration of ICs, Transistor and Diode 18.2. *Este material se encuentra sin programar, debe ser programado. C0ABBB000067 (8P) C0FBAK000026(16P) C0HBB0000057 (44P) C0DBEYY00123 (8P) C1BA00000497 (23P) C1AB00003566 (20P) C1AB00003130 (14P) C0JBAB000902 (14P) C3FBXY000039 C3FBMY000303 (8P) C3ABPG000163 (54P) (169P) No.1 No.1 No.1 No.1 No.1 C0GBY0000117...

  • Page 125: Terminal Function Of Ics

    Terminal Function of ICs 18.3. IC2003 (*MN101EF16KXW): IC 18.3.1. Terminal Name Function MICRO-PROCESSOR CLOSE_SW CD Close Switch Detection *Este material se encuentra sin programar, debe ser programado. CD_OPEN_SW CD Open Switch Detection Terminal Name Function CD_RESET_SW CD Reset Detection LOAD_CCW Loading Motor Turning...
  • Page 129 19.1.3. Mechanical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description RYPM0309 FRONT PANEL ASS'Y CABINET CHASSIS 18-1 RMGX0033A-K CD LID CUSHION 18-2 RGK2307B-KL CD LID REE1708 30P FFC (PANEL- 18-3...
  • Page 130 Safety Ref. Part No. Part Name & Qty Remarks Description REE1671 SERVO-CD INTER- FACE) RMNV0079-1 FL HOLDER RGL0764-Q LIGHT PIECE REX1522 GROUND WIRE (MIC-MUSIC PORT) RGWX0056-1K1 MIC VOLUME KNOB RGQ0672-R FL FILTER SHEET TRAVERSE DECK RD-DDL100-PX BRS1C CD UNIT RAE1034Z-V TRAVERSE ASS'Y XTN2+6GFJ SCREW...

  • Page 131: Electrical Replacement Part List

    19.2. Electrical Replacement Part List...
  • Page 132 SafetyRef. no Part No. Part Name & Description SafetyRef. no. Part No. Part Name & Description K5D802APA008 FUSIBLE ERJ3GEY0R00V CHIP JUMPER REPM12X543A CONJUNTO MANUAL PANEL AKX54 pista par CS ERJ3GEY0R00V CHIP JUMPER CN6000 K1MY27AA0124 CONECTOR 27 PIN ERJ8GEY0R00V CHIP JUMPER CN6001 K1KA04A00553 CONECTOR...
  • Page 133 ERJ3GEY0R00V CHIP JUMPER S6001 EVQ21405RJ TACK SWITCH ERJ3GEY0R00V CHIP JUMPER S6002 EVQ21405RJ TACK SWITCH S6003 EVQ21405RJ TACK SWITCH R5890 D0GB222JA008 RESISTENCIA CHIP S6004 EVQ21405RJ TACK SWITCH R5868 D0GB223JA008 CHIP RESISTOR S6005 EVQ21405RJ TACK SWITCH R5810 D0GB331JA008 CHIP RESISTOR S6006 EVQ21405RJ TACK SWITCH R5817 D0GB331JA008...
  • Page 134 R5797 D0GB153JA008 CHIP RESISTENCIA D5725 B0BC6R100010 DIODO R5806 D0GB153JA008 CHIP RESISTENCIA D5795 B0BC9R000008 DIODO R5895 D0GB153JA008 CHIP RESISTENCIA Q5722 B1ABCF000176 TRANSISTOR R5798 D0GB220JA008 CHIP RESISTENCIA Q5861 B1ABCF000176 TRANSISTOR Q5898 B1ABCF000176 TRANSISTOR Q5899 B1ABGC000001 TRANSISTOR Q5721 B1ADCF000001 TRANSISTOR Q5860 B1ADCF000001 TRANSISTOR Q5862 B1GBCFJJ0051 TRANSISTOR...
