Please refer to the original service manual for:
1) SA-AKX14P is base on SA-AKX14PN-K, Order No. PSG1201003CE.
2) CD Mechanism Unit (BRS1C), Order No. PSG1102001CE.
3) Speaker system SB-AKX14P-K, Order No. PSG1203033AE.

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 3
1.3. Protection Circuitry ---------------------------------------- 3
1.4. Caution For Fuse Replacement------------------------ 4
1.5. Safety Parts Information -------------------------------- 4
2 Warning -------------------------------------------------------------- 5
Model No.
Product Color: (K)...Black Type
PAGE
2.2. Precaution of Laser Diode -------------------------------6
3 Service Navigation --------------------------------------------- 10
3.1. Service Information -------------------------------------- 10
3.2. Differences Table ---------------------------------------- 11
© Panasonic Corporation 2012. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
CD Stereo System
SA-AKX14P
PSG1203032AE
A6
PAGE

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic SA-AKX14P

  • Page 1: Table Of Contents

    Model No. Product Color: (K)...Black Type Please refer to the original service manual for: 1) SA-AKX14P is base on SA-AKX14PN-K, Order No. PSG1201003CE. 2) CD Mechanism Unit (BRS1C), Order No. PSG1102001CE. 3) Speaker system SB-AKX14P-K, Order No. PSG1203033AE. TABLE OF CONTENTS...
  • Page 2 4 Specifications ---------------------------------------------------- 12 5 Block Diagram --------------------------------------------------- 13 5.1. Power Supply --------------------------------------------- 13 6 Schematic Diagram--------------------------------------------- 15 6.1. Main Circuit ------------------------------------------------ 15 6.2. SMPS Circuit ---------------------------------------------- 19 7 Printed Circuit Board ------------------------------------------ 21 7.1. Main P.C.B. & Tuner P.C.B. --------------------------- 21 7.2.
  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
  • Page 4: Caution For Fuse Replacement

    The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used. If this occurs, follow the procedure outlines below: 1.
  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor “chip”...
  • Page 6: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 W/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.
  • Page 7: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).
  • Page 8: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.
  • Page 9 Grounding for electrostatic breakdown prevention 2.4.2. Some devices such as the DVD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electric- ity in the working environment. Proceed servicing works under the working environment where grounding works is completed. 2.4.2.1.
  • Page 10: Service Navigation

    1) The following components are supplied as an assembled part. - Micro-processor IC, IC2003 (RFKWMAKX14M0) • Speaker system: 1) This model uses Speaker System, SA-AKX14P-K. • Base model: 1) The base is SA-AKX14PN-K. As such this service manual does not contain the following information as below:- •...
  • Page 11: Differences Table

    3.2. Differences Table Ref No. Part No. Part Name & Description Remarks SA-AKX14PN-K SA-AKX14P-K RFKGAKX14PHK RFKGAKX14P-K FRONT PANEL ASS'YL RGRX1008K-A RGRX1008K-F REAR PANEL RQT9609-1M RQT9691-1P O/I BOOK (En) RPG9738 RPG0A44 PACKING CASE PCB2 REP4743AA REP4743EA MAIN P.C.B. PCB3 REP4743AB REP4743EB PANEL P.C.BL...
  • Page 12: Specifications

    4 Specifications 2. Total harmonic distortion is measured by the digital spectrum analyzer.  System: SC-AKX14P-K Main Unit: SA-AKX14P-K  AMPLIFIER SECTION Front Speakers: SB-AKX14P-K RMS output power stereo mode Front Ch(both ch driven) 125 W per channel (4 ), 1 kHz, 10% THD...
  • Page 13: Block Diagram

    D5728 D5801 +9V VOLTAGE Q5722 DC16V REGULATOR CURRENT LIMITING SWITCH PC5720 D2004 FEEDBACK IC5801 Q2022 C0DAZYY00039 FEEDBACK D5725 SHUNT +7.5V VOLTAGE CIRCUIT DC16V +7.5V CD+7.5V REGULATOR REGULATOR Q2000 D2000 VOLTAGE CONTROL D2017 PRIMARY SECONDARY SA-AKX14P POWER SUPPLY (1/2) BLOCK DIAGRAM...
  • Page 14 15,16 D2018,D2019 D2020,D2021 CN2706 CN7002 CD+7.5V CD+7.5V +7.5V +7.5V 7.5V CN2706 CN7002 CD 3.3V 3.3V 3.3V 3.3V CN2706 CN7002 LD SW LD SW LD SW LDSW TUNER P.C.B. 3.3V CN2010 CN51 3.3V 3.3V 3.3V SA-AKX14P POWER SUPPLY (2/2) BLOCK DIAGRAM...
  • Page 15: Schematic Diagram

    CLIP SENSING C2128 R2350 B1ADCE000012 5600P SWITCH R2362 C2246 470K C2138 R2351 5600P Q2038 Q2051 R2364 R2360 C2244 R2357 B1ABCF000176 2.2K 100K 0.22 4.7M B1ADCE000012 SWITCH R2131 CLIP SENSING R2376 D2301 R2347 DA2J10100L 8.2K TO MAIN CIRCUIT (3/4) SA-AKX14P MAIN CIRCUIT...
  • Page 16 10V100 R5918 2.7K Q5901 R5914 B1ADCE000012 +5V VOLTAGE SUPPLY SWITCH R5917 R5920 Q5902 2.7K B1ABCF000231 R5915 MODE_DA MODE SWITCH R5919 Q5903 MUTE_F B1ABCF000231 SWITCH TO MAIN CIRCUIT (4/4) SA-AKX14P MAIN CIRCUIT NOTE: “ * ” REF IS FOR INDICATION ONLY...
  • Page 17 KEY2 KEY2 D2008 DA2J10100L DGND UP_DGND CN2002 MM0D0 R2096 X2001 MMOD H2B800400007 NRST R2095 MICORST R2000 OCD_SCK OCD_SDL DVREF+ R2093 3.9K FOR DEBUG OCD_SDA R2094 3.9K OCD_SDA SYS3.3V NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX14P MAIN CIRCUIT...
  • Page 18 SMPS_BP B1BABG000007 (CN7901) IC2009 BEATPROOF SWITCH IN SCHEMATIC VBUS CHASSIS AGND C0DBFYY00049 SCREW A USB_SEL DIAGRAM - 1 +3.3V VOLTAGE REGULATOR NC CE CD_3.3V VOUT C2195 C2201 C2249 NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX14P MAIN CIRCUIT...
  • Page 19: Smps Circuit

    SHUNT REGULATOR R5814 R5804 8.2K R5733 D5722 R5806 B0BC019A0007 C5721 C5722 R5805 220P 1000P C5818 D5723 2.2K B0ACCK000012 R5865 PC5701 C5727 R5726 D5725 B3PBA0000503 3300P 0.15 FEEDBACK B0BC6R100010 PW_SYS3.3V R5727 R5817 R5810 0.13 QR5810 B1GBCFLL0037 PCONT PCONT SWITCH SA-AKX14P SMPS CIRCUIT...
  • Page 20 B0BC9R000008 R5892 SWITCHING MODE POWER SUPPLY CONTROL C5899 C5712 10V220 200V330 IC5899 R5895 C0DAEYY00040 C5794 R5795 1000P 470K C5898 SHUNT REGULATOR R5797 R5891 C5708 C5795 C5796 F1BAF1020020 1000P NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX14P SMPS CIRCUIT...
  • Page 21: Printed Circuit Board

    Q5904 C5985 QR2402 R5910 W5024 K2006...P R5922 Q5900 Q5903 C5937 C5980 C5925 Q5902 R5928 HEATSINK R5909 C5952 R5936 R5917 QR5901 Q5901 W5001 C5978 QR5900 R5914 ZA5903* 3533AA 3533AA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX14P MAIN P.C.B.
  • Page 22: Panel, Lcd, Remote Sensor & Usb P.c.b

    USB PORT S6003 R1210 (MANUAL EQ) R1200 JK1111 ZJ6002* C1110 S6002 S6001 LB1210 (D. BASS) (POWER) ZJ6001* 3533AD 3533AD 3533AB 3533AB NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX14P PANEL / LCD / REMOTE SENSOR / USB P.C.B.
  • Page 23: Smps P.c.b

    Q5860 Q5861 R5803 R5804 C5810 R5891 Q5862 C5831 C5832 PC5799 PC5702 T5751 W5511 R5894 R5800 (MAIN TRANSFORMER) W5603 W5521 D5804 D5896 W5522 W5523 CN5802 R5893 R5890 15 14 13 12 11 10 Q5898 C5812 W5512 R5701 3568AA 3568AA SA-AKX14P SMPS P.C.B.
  • Page 24: Exploded View And Replacement Parts List

    VR6002 Z900 *ZJ6002 CN6005 JK1111 (USB P.C.B.) CN6000 (LCD P.C.B.) CN6001 VR6001 CN6006 IR6000 (REMOTE SENSOR P.C.B.) 18-1 18-3 18-2 18-3 18-5 18-4 SA-AKX14P-K NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. CABINET DRAWINGS...
  • Page 25 CN2001 P5701 ZJ2000 T5751 JK52 JK51 ZJ2001 (TUNER P.C.B.) CN5802 CN51 (SMPS P.C.B.) (BRS1C) CN7901 CN7001 CN7002 *CN7801 (CD SERVO P.C.B.) CN7003 S7201 SA-AKX14P-K CABINET DRAWINGS NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY.
  • Page 26 8.1.2. Packaging ACCESSORIES BAG OI BOOK A1-1 AM LOOP ANTENNA FM INDOOR ANTENNA SA-AKX14P SB-AKX14P F R O N T POLYFOAM (TOP) SC-AKX14P-K POLYFOAM (BOTTOM) PACKAGING DRAWINGS...
  • Page 27 8.1.3. Mechanical Replacement Parts List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks 18-5 RMB0930 CD LID SPRING Description RKAX0042-K LEG CUSHION RKMX1011-K1 TOP CABINET CABINET RGRX1008K-F REAR PANEL CHASSIS RMAX1007 CHASSIS SUPPORT...
  • Page 28 Safety Ref. Part No. Part Name & Qty Remarks Description RPG0A44 PACKING CASE RPN2348 POLYFOAM RPFX0198 MIRAMAT SHEET ACCESSORIES N2QAYB000636 REMOTE CONTROL A1-1 RKK-PM500EBK BATTERY COVER K2CB2YY00059 AC CORD RQT9691-1P O/I BOOK (En) N1DYYYY00011 AM LOOP ANTENNA RSAX0002 INDOOR ANTENNA...
  • Page 29: Electrical Replacement Parts List

    8.2. Electrical Replacement Parts List Safety Ref. Part No. Part Name & Qty Remarks Description Q2039 B1ADCE000012 TRANSISTOR Safety Ref. Part No. Part Name & Qty Remarks Description Q2040 B1ABCF000176 TRANSISTOR PRINTED CIRCUIT Q2041 B1ABCF000176 TRANSISTOR BOARDS Q2050 B1ADCE000012 TRANSISTOR Q2051 B1ADCE000012 TRANSISTOR...
  • Page 30 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description D2015 B0ADDJ000032 DIODE EARTH PLATES D2017 DZ2J07500L DIODE D2018 B0EAMM000057 DIODE ZJ2000 K9ZZ00001279 EARTH PLATE D2019 B0EAMM000057 DIODE ZJ2001 K9ZZ00001279 EARTH PLATE D2020 B0EAMM000057...
  • Page 31 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R2076 D0GB102JA008 1/10W R2240 D0GB220JA008 1/10W R2084 D0GB104JA008 100K 1/10W R2271 D0GB101JA008 1/10W R2085 D0GB154JA008 150K 1/10W R2278 D0GB681JA008 1/10W R2093 D0GB392JA008 3.9K...
  • Page 32 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R5808 D0GD222JA017 2.2K 1/8W C2109 F1H0J1050012 6.3V R5809 D0GD331JA017 1/8W C2110 F1H1H102A219 1000pF R5810 D0GB331JA008 1/10W C2112 F1H1H2210001 220pF R5814 D0GB822JA008 8.2K 1/10W...
  • Page 33 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C2248 F1H0J1050012 6.3V C5939 F1H1H104A013 0.1uF C2249 F1H0J1050012 6.3V C5942 F1H1H330A230 33pF C2301 F1J1A106A043 10uF C5943 F1K2A1040007 0.1uF 100V C2302 F1J1A106A043 10uF C5946...
  • Page 34 MMH1203...
