Configuration Mode; Ir Transmit Mode; Timeout Adjustment - AMX Mio Modero R-2 Operation/Reference Manual

IR/RF Code Matrix (Cont.)
Button
41
42
43
44
45

Configuration Mode

The configuration mode allows you to set the following device features:
To enter configuration Mode:
1. Press and hold the STOP button and the INPUT button. The two buttons must be pressed within 0.1
seconds of each other and held down for 2 seconds. The device indicates you are now in
configuration mode. See below for available modes.
2. Press the EXIT key when you are finished.
Your settings will not be lost in the event your batteries die or are removed.

IR Transmit Mode

Pressing button "1" on the remote toggles the IR transmission mode between 38KHz, 455KHz, RF, and
both 38KHz IR and RF. The display indicates the current mode.

Timeout Adjustment

Press button "2" on the remote to change the sleep timeout from the default. Each time "2" is pressed, the
sleep timeout raises incrementally. The pre-determined sleep timeouts are:
The display indicates the selected sleep timeout.
Mio Modero R-2
Label Mode Mode
1 2
S. REV Z
7 47
PLAY A
1 41
S. FWD Y
6 46
REW E 5 45
FWD D 4 44
IR Transmit Mode (38 KHz, 455 KHz or both 38 KHz IR and RF)
Timeout Adjustment
Download Mode
Debug Mode
Battery Type
LED Awake Brightness
LED Sleep Brightness
3 seconds
6 seconds
9 seconds
12 seconds
Mode Mode Mode Mode
3 4 5 6
87 127 167 207
81 121 161 201
86 126 166 206
85 125 165 205
84 124 164 204
Programming The Mio R-2
9
