- Page 1 RBL30MVA 30cc Mulching Blower / Vac OPERATOR'S MANUAL Important! It is essential that you read the instructions in this manual before mounting and operating this machine. Subject to technical modifications.
-
Page 2: General Safety Rules
GeNeRAL sAfety RuLes can be thrown or become entangled in the machine. WARNING: n Keep firm footing and balance. Do not overreach. Over- reaching can result in loss of balance or exposure to hot ReAd ANd uNdeRstANd ALL INstRuctIoNs. Fail- surfaces. - Page 3 syMBoLs Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. syMBoL NAMe desIGNAtIoN/eXpLANAtIoN Safety Alert Precautions that involve your safety. To reduce the risk of injury, user must read and understand Read The Operator’s Manual operator’s manual before using this product.
-
Page 4: Product Specifications
feAtuRes pRoduct specIfIcAtIoNs Weight ..................................7.5 kg Engine displacement ..............................0 cc Air velocity ................................50 km/h Air volume ................................1 m /min Sound power level ..............................110 dB(A) Sound pressure level at operator position ......................95 dB(A) Maximum engine performance ..........................0.75 kW Maximum rotational frequency of the engine ......................8500 /min Engine speed at idling ..........................800 ~ 500 /min Fuel consumption at max. - Page 5 feAtuRes on/off swiTch cRuise ReaR ThRoTTle conTRol handle fRonT handle handle knob bloweR Tube bloweR /Vac mode swiTch Vacuum sTaRTeR gRip fuel cap choke dial pRimeR bulb shouldeR sTRap Fig. 1...
-
Page 6: Packing List
AsseMBLy uNpAcKING WARNING: This product requires assembly. Beware of the revolving parts when open the zipper of n Carefully remove the tool and any accessories from the bag. the box. Make sure that all items listed in the packing list are included. See Figure 2 –... -
Page 7: Operation
opeRAtIoN MIXING the fueL WARNING: n This product is powered by a -stroke engine and Always hold the blower away from your body, keeping requires pre-mixed petrol and -stroke lubricant. Pre- clearance between your body and the product. Any mix unleaded petrol and -stroke engine lubricant in a contact with the housing can result in burns and/or clean container approved for petrol. -
Page 8: Starting And Stopping
opeRAtIoN stARtING ANd stoppING WARNING Never start or run the engine inside a closed or poorly ventilated area; breathing exhaust fumes can kill. to stARt A coLd eNGINe (Fig. 5): n Move ignition switch () to “ I ” run position. n Make sure cruise control () is locked in idle position. - Page 9 opeRAtIoN to stARt A WARM eNGINe (Fig. 6): n Move ignition switch () to “ I ” run position. n Make sure cruise control () is locked in idle position. Do not engage the throttle trigger () or cruise control during the start-up process.
-
Page 10: Operating The Blower
opeRAtIoN opeRAtING the BLoWeR See Figure 7. Rotate Blower / Vac mode switch anti-clockwise until hear a “click” sound. n Wear the shoulder harness and adjust it to a comfortable position. Hold the blower with both hands (Proper operating position is shown in figure 7) To keep from scattering debris, blow around the outer edges of a debris pile. - Page 11 opeRAtIoN VAcuuM opeRAtIoN See Figure 9. WARNING: Never run the unit without the vacuum tubes and vac- uum bag installed. Failure to heed this warning could result in serious personal injury. n Install the vacuum tubes and bag. Refer to the ASSEMBLY section earlier in this manual.
-
Page 12: General Maintenance
MAINteNANce WARNING: When servicing, use only identical Ryobi replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. -
Page 13: Spark Plug
MAINteNANce cLeANING the eXhAust poRt ANd MuffLeR use only fuel and oil mix described in fig 2 Depending on the type of fuel used, the type and amount of oil used, and/or your operating conditions, the exhaust port and muffler may become blocked with carbon deposits. If you notice low power from the blower, have a qualified service technician check the exhaust port and muffler for carbon deposits. -
Page 14: Troubleshooting
tRouBLeshootING problem possible cause solution Engine will not start. No spark. Check spark. Remove spark plug. Reattach the spark plug cap and lay spark plug on metal cylinder. Pull the starter rope and watch for spark at spark plug tip. If there is no spark, repeat test with a new spark plug. -
Page 15: Limited Warranty
