Infinity Beta Ten 10" Subwoofer Instructions

LIMITED WARRANTY

THREE YEARS
Beta Series Automotive Speakers, Electronics
HOW LONG IS THIS WARRANTY?
This warranty remains in effect for three years from date of purchase.
WHO IS PROTECTED BY THIS WARRANTY?
This warranty protects the original owner and is not transferable, providing that the product has been pur-
chased in the United States. The original dated bill of sale from an authorized Infinity dealer must be present-
ed whenever warranty service is required. For warranty service outside the United States, contact the Infinity
distributor in the country where the product was purchased.
WHAT IS COVERED BY THIS WARRANTY?
Except as specified below, this warranty covers all defects in materials and workmanship. The following are
not covered: damage caused by accident, misuse, abuse, product modification or neglect, damage occurring
during shipment, damage from failure to follow instructions contained in the instruction manual, damage
resulting from the performance of repairs by someone not authorized by Infinity, or any claims based on mis-
representations by the seller. This warranty does not cover incidental or consequential damages. It does not
cover the cost of removing or reinstalling the unit.
You are responsible for transporting your product for repair. However, Infinity will pay return charges if the
repair is covered under warranty. Outside the United States, please contact your local distributor.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on
how long an implied warranty lasts, so the above may not apply to you.
PLEASE MAKE NOTE OF THE FOLLOWING
INFORMATION AND RETAIN FOR YOUR RECORDS:
Product Name: __________________________________ Model Number:_____________________________________
Store Name And Phone: _______________________________________________________________________________
Date of Purchase: _____________________________________________________________________________________
Infinity Systems, Inc. • 20630 Nordhoff Street
Chatsworth, CA 91311, USA • VOICE (818) 407- 0228 • FAX (818) 709 -9486
®
CAR AUDIO
Thank you for purchasing an Infinity Beta Ten
10" Subwoofer. You've selected a premium product
that offers superior performance and advanced
materials, resulting from over 25 years of loud-
speaker design. This Infinity product is made with
our ongoing dedication to create the best consumer
audio products possible. As a result, you can expect
your new Beta Subwoofer to provide you with many
years of listening enjoyment.
We have included three enclosure types — sealed,
vented, and single-reflex bandpass —with three dif-
ferent alignments (i.e., tuning preferences) for each
box. Please refer to the discussion in Subwoofer
Enclosure Trade-Offs and associated performance
graphs (on the inside pages) to select a desired
enclosure type and alignment.
Each Infinity Beta Ten 10" Subwoofer is covered by
our full three-year parts and labor warranty (see
back page). Keep your original dated bill of sale in
case warranty service is required.
IMPORTANT: Installation of automotive stereo
components can require extensive experience in
dealing with a variety of electrical, and
mechanical procedures, including subwoofer
box building. Although these instructions
explain how to install a Beta Subwoofer in a
general sense, they do not show the exact instal-
lation methods for your particular vehicle. If
you do not have the experience, do not attempt
the installation yourself; instead ask your
Authorized Infinity Car Audio Dealer about
professional installation options.
P
RECAUTIONS
• Always wear protective eyewear when using tools.
• Turn off all audio systems and other electrical
devices before starting the installation.
• Disconnect the (–) negative lead from your vehi-
cle's battery.
®
Printed In Japan
Te n 1 0 " S u b w o o f e r
I N S T R U C T I O N S
• Locate and note all fuel lines, hydraulic brake
lines, and electrical wiring. Use extreme caution
when cutting or drilling in and around these areas.
• Check clearances on both sides of a planned
mounting surface before drilling any holes or
installing any screws.
T -S
HIELE MALL
F -A R
REE IR ESONANCE
C V
OMPLIANCE OLUME
M Q:
ECHANICAL
E Q:
LECTRICAL
T Q:
OTAL
M E
AXIMUM XCURSION
V C D R
OICE OIL C ESISTANCE
S
PECIFICATIONS
D :
IAMETER
S (2.83 V @ 1
ENSITIVITY
P H
OWER ANDLING
F R
REQUENCY ESPONSE
N I
OMINAL MPEDANCE
D :
IMENSIONS
mounting depth
4.75" (120.65 mm)
Infinity Systems, Inc. • 20630 Nordhoff Street
Chatsworth, CA 91311, USA • VOICE (818) 407- 0228 • FAX (818) 709 -9486
P
ARAMETERS
: F (H ) 24.00
Z
S
FT 3
: V ( ) 2.70
AS
V ( ) 77.00
LITERS
AS
Q 8.08
MS
Q 0.20
ES
Q 0.20
TS
: X ( ) 0.39
IN
MAX
X ( ) 10.00
MM
MAX
: R ( ) 2.80
OHMS
E
10" (254.0 )
MM
): 93 dB
M
: 250 W
RMS
: 20 ~ 500 H
Z
: 4
OHMS
cutout diameter
9.37" (238.00 mm)
outer diameter
10.70" (271.78 mm)
