- Page 1 Betriebsanleitung / Operating Manual CELSIUS R / CELSIUS V Deutsch / English...
- Page 2 Ihre Verkaufsstelle Weitere Informationen finden Sie in den Handbüchern "Sicherheit und Ergonomie" und "Garantie". Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com Are there ..any technical problems or other questions you need clarified? Please contact: •...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von / Published by Fujitsu Siemens Computers GmbH A26361-K680-Z101-1-7419 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany...
-
Page 5: Operating Manual
Introduction Important notes CELSIUS R / CELSIUS V Preparing for use Operation Troubleshooting and tips Operating manual System expansions Technical data Index November 2003 edition... - Page 6 CELSIUS is a registered trademark of Fujitsu Siemens Computers GmbH. Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. VESA and DPMS are trademarks of Video Electronics Standards Association. PS/2 is a registered trademark of International Business Machines, Inc.
-
Page 7: Table Of Contents
Contents Your CELSIUS R/CELSIUS V......................1 Notational conventions ........................2 Important notes ..........................3 Safety notes ............................3 Energy saving, disposal and recycling ..................3 CE marking..........................3 FCC Class B Compliance Statement....................4 Transporting the workstation......................4 Cleaning the workstation........................4 Preparing for use..........................5 Unpacking and checking the delivery....................5 Steps for initial setup .........................5... - Page 8 Contents System expansions........................27 Information about boards ......................27 Opening the casing ......................... 28 Closing the casing........................... 29 Installing and removing a board ...................... 30 Installing board with screw ...................... 30 Removing board with screw ....................32 Installing board with clip ......................33 Removing board with clips.......................
-
Page 9: Your Celsius R/Celsius V
Your CELSIUS R/CELSIUS V..is available with various configuration levels with different hardware and software. In addition, you can install accessible drives (e.g. DVD drive), hard disks and other boards. This operating manual tells you how to put your workstation into operation and how to operate it in daily use. -
Page 10: Notational Conventions
Your CELSIUS R/CELSIUS V... Notational conventions The meanings of the symbols and fonts used in this manual are as follows: indicates information which is important for your health or for preventing physical damage. indicates important information which is required to use the system properly. -
Page 11: Important Notes
Important notes In this chapter you will find information regarding safety which it is essential to take note of when working with your workstation. Safety notes Pay attention to the information provided in the "Safety and Ergonomics" manual and in the following safety notes. -
Page 12: Fcc Class B Compliance Statement
• Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused by unauthorised modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The correction of interferences caused by such unauthorised modification, substitution or attachment will be the responsibility of the user. -
Page 13: Preparing For Use
Preparing for use Please take note of the safety information in the "Important notes" chapter. Unpacking and checking the delivery It is recommended not to throw away the original packaging material! It may be required for reshipment at some later date. ►... -
Page 14: Setting Up The Workstation
Preparing for use Setting up the workstation When installing your workstation, give consideration to the recommendations and safety notes in the "Safety and Ergonomics" booklet. Set up the workstation only in its correct orientation. The points to observe are illustrated on the following pages. -
Page 15: Connecting The Mouse
Preparing for use Connecting the mouse Depending on the equipment level selected, your workstation will be supplied with a PS/2 mouse or a USB mouse. Connecting a PS/2 mouse ► Connect the PS/2 mouse to the PS/2 mouse port on the workstation. Connecting USB mouse ►... -
Page 16: Connecting The Workstation To The Mains Voltage
Preparing for use Connecting the workstation to the mains voltage Your workstation sets itself automatically to the local rated voltage. ► Plug the power cable into the workstation (1). ► Plug the power plug into the grounded mains outlet (2). Initial switch-on: Software will be installed If the workstation is integrated into a network, the user and server details as well as the network protocol are required. -
Page 17: Switching On Monitor And Workstation
Switch on the workstation. To do this, follow the instructions below. Celsius V Celsius R 1 = ON/OFF switch 3 = Power-on indicator (Celsius R only) 2 = LCD display (Celsius V only) ► Press the ON/OFF switch on the front of the workstation. -
Page 18: Installing The Software
Preparing for use Installing the software ► During installation, follow the instructions on screen. Consult the operating system manual if there is anything unclear about the requested input data. You will find further information about the system, drivers, utilities, updates, manuals etc. on the "Drivers &... -
Page 19: Connections On The Workstation
Preparing for use Connections on the workstation The ports for external devices are on the rear and on the front of the workstation. The ports available on your workstation depend on the configuration level you have selected. The standard ports are marked with the symbols shown below (or similar). -
Page 20: Connecting External Devices To The Serial Port
Preparing for use Connecting external devices to the serial port External devices can be connected to the serial port (e.g. a modem). ► Connect the data cable to the external device. ► Connect the data cable to the serial port For an exact description of how to connect external devices to the serial port, please refer to the device documentation. -
Page 21: Connecting External Devices To The Usb Ports
Preparing for use Connecting external devices to the USB ports You can connect a wide range of external devices to the USB port (e.g. printer, scanner, modem or keyboard). USB devices are hot-pluggable. This allows cables from USB devices to be connected and disconnected with the system switched on. -
Page 23: Operation
Operation Switching the workstation on ► If necessary, switch the monitor on (see the operating manual for the monitor). ► Press the ON/OFF switch on the front of the workstation. The corresponding indication appears on the LCD (see chapter "Indicators on the workstation") or the operating indicator lights, the workstation starts up. -
Page 24: Indicators On The Workstation
Indicators on the workstation The indicators are on the front of the workstation. Which indicators are available on your workstation depends on the configuration level you have selected. Celsius V Celsius R Celsius V Celsius R 1 = LCD / status indicator panel... - Page 25 The indicator lights up when the floppy disk drive of the workstation is accessed. You may only remove the floppy disk when the indicator is unlit. 5 - Hard disk indicator (Celsius R only) The indicator lights up when the hard disk drive of the workstation is accessed.
-
Page 26: Keyboard
Operation Keyboard 1 = Function keys 4 = Cursor keys 2 = Power button (optional) 5 = Numeric keypad (calculator keypad) 3 = Alphanumeric keypad The illustrated keyboard is an example and may differ from the model you use. A26361-K680-Z101-1-7419... -
Page 27: Important Keys And Key Combinations
Operation Important keys and key combinations The following description of keys and key combinations refers to MS Windows. Details of other keys and key combinations can be found in the documentation of the relevant application programme. ON/OFF switch (optional) Depending on the setting in the BIOS Setup, the system can be switched on, off, or on and off with this button. -
Page 28: Working With Floppy Disks
Operation Working with floppy disks Follow the instructions supplied by the vendor of the floppy disks. Never clean the floppy disk drives with cleaning disks. Any attempt would destroy the read/write head in the disk drive within 20 seconds. 1 = Insertion direction 2 = Label area 3 = Write protection tab for a 1.44 Mbyte floppy disk 4 = Identification of a 1.44 MB floppy disk or write protect switch on a 120 MB floppy disk... -
Page 29: Settings In Bios Setup
Operation Settings in BIOS Setup The BIOS Setup menu allows you to set your hardware configuration and system functions of the workstation. When the PC is delivered, the default entries are valid (see "BIOS Setup" manual and if necessary technical manual for the mainboard). You may customise these settings to your requirements in the BIOS Setup. -
Page 31: Troubleshooting And Tips
Troubleshooting and tips Take note of the safety notes in the "Safety and Ergonomics" manual and in the "Preparing for use" chapter, when you connect or disconnect cables. If a fault occurs, try to correct it as described in the following places: •... -
Page 32: The Screen Stays Blank
Troubleshooting and tips The screen stays blank If your screen remains blank this may be due to the following: Monitor is switched off ► Switch your monitor on. Power saving has been activated (screen is blank) ► Press any key on the keyboard. ►... -
Page 33: No Mouse Pointer Displayed On The Screen
Troubleshooting and tips Wrong monitor has been set under Window XP ► Restart the workstation. ► Press F8 while the system is booting. Either the Windows Advanced Start Options menu or the menu for selecting the operating system appears. ► If the menu for selecting the operating system appears, press F8 . -
Page 34: Time And/Or Date Is Not Correct
Troubleshooting and tips Time and/or date is not correct You can set the time and date in the BIOS Setup or in the operating system. ► Set the time and date. If the time and date are repeatedly wrong when you switch on your PC, the on-board battery is flat. -
Page 35: System Expansions
System expansions It may be necessary to update the BIOS when carrying out a system expansion or hardware upgrade. Additional information is contained in the "BIOS Setup" manual or possibly in the technical manual for the mainboard. When installing components that become very hot, make sure that the maximum permissible temperatures of the individual components are not exceeded. -
Page 36: Opening The Casing
System expansions Opening the casing ► Switch off the workstation. The workstation must not be in the energy-saving mode. Please take note of the safety information in the "Important notes" chapter. Pull the power plug out of the mains outlet. Only insert the power plug after you have closed the casing. -
Page 37: Closing The Casing
System expansions Closing the casing ► Hook the side cover into the lower guide trail in the casing (1). Make sure that the side cover is offset by approximately 2 cm (a). ► Engage the top edge of the side cover on the casing. ►... -
Page 38: Installing And Removing A Board
System expansions Installing and removing a board Please take note of the section "Information about boards". The number, position and arrangement of the board slots on the mainboard can be found in the technical manual for the mainboard. Boards may already be installed when the device is shipped. You can fix boards in two ways: •... - Page 39 System expansions ► Push the board up to its slot (1) as far as the stop. ► Press the board into the slot so that it engages. ► Fasten the board into place with the screw (2). ► If necessary, connect the cables. ►...
-
Page 40: Removing Board With Screw
System expansions Removing board with screw ► Open the casing (see "Opening the casing" chapter). ► Disconnect the cables connected to the board. ► Loosen the screw (1). ► Remove the board from the casing (2). For cooling, protection against fire, and in order to comply with EMC (electromagnetic compatibility) regulations, you must refit the cover plate. -
Page 41: Installing Board With Clip
System expansions ► Push the rear slot cover plate into the slot (1). Ensure that the point of the cover engages on the outside of the casing. ► Fasten the rear slot cover plate with the screw (2). ► Close the casing (see "Closing the casing" chapter). If you have installed or removed a PCI board, please check the relevant PCI slot settings in the BIOS Setup. - Page 42 System expansions ► Remove the cover plate from the slot (2). Do not dispose of the cover plate. For cooling, protection against fire and in order to comply with EMC regulations, you must refit the cover plate if you remove the board. ►...
-
Page 43: Removing Board With Clips
System expansions Removing board with clips ► Open the casing (see "Opening the casing" chapter). ► Disconnect the cables connected to the board. ► Press the clip in the direction of the arrow (1) and unhook it. ► Pull off the clip (2). ►... - Page 44 System expansions ► Push the rear slot cover plate into the slot (1). Ensure that the point of the cover engages on the outside of the casing. ► Put the clip on. Make sure that the pin (a) is inserted into the screw hole. ►...
-
Page 45: Installing And Removing Drives
System expansions Installing and removing drives The PC casing can accommodate a total of eight drives: • four accessible drives (three 5¼" drives and one 3½" drive) • four non-accessible drives (3½" drives) "Accessible drives" are e.g. DVD or CD ROM drives, into which a data carrier can be inserted from outside. -
Page 46: Attaching The Front Panel
System expansions ► Pull the front panel off in the direction of the arrow. If you pull too firmly, the LCD cable may be pulled off the Celsius V or damaged. In a system with an LCD, the cable is long enough so that you can carefully place it to one side with the front panel. -
Page 47: Installing An Accessible Drive
System expansions Installing an accessible drive ► Open the casing (see "Opening the casing" chapter). ► Remove the front (see "Removing the front panel" chapter). ► Pull the empty slide-in module out of the casing. ► Loosen the screws (1). ►... - Page 48 System expansions ► Lay the rails onto the drive such that the holes in them align with the screw holes (1). ► Fasten the rails with the screws (2). ► Slide the accessible drive into the casing. ► Plug the data and the power supply connectors into the drive. Make sure the polarity is correct. ►...
-
Page 49: Removing An Accessible Drive
System expansions Removing an accessible drive ► Open the casing (see "Opening the casing" chapter). ► Remove the front (see "Removing the front panel" chapter). ► Pull the data and the power supply connectors from the desired drive. ► Pull the drive out of the casing. ►... - Page 50 System expansions ► Lay the rails onto the blanking plate such that the holes in them align with the screw holes (1). ► Fasten the rails with the screws (2). ► Slide the empty slide-in module into the casing. ► Attach the front panel (see "Attaching the front panel").
-
Page 51: Changing The Floppy Disk Drive
System expansions Changing the floppy disk drive ► Open the casing (see "Opening the casing" chapter). ► Remove the front (see "Removing the front panel" chapter). ► Disconnect the cables connected to the floppy disk drive. ► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see also the technical manual for the mainboard"). - Page 52 System expansions ► Remove the screws (1) on both sides of the drive. ► Pull the disk drive out of the slide-in module (2). Installing the floppy disk drive ► Take the new floppy disk drive out of its packaging. ►...
-
Page 53: Installing Or Removing The Hard Disk Drive
System expansions ► Slide the slide-in module into the casing (1). ► Secure the slide-in module with the screws (2). ► Fit the data and power supply connectors to the floppy disk drive. ► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see also the technical manual for the mainboard). - Page 54 System expansions Installing a hard disk drive ► Take the new hard disk drive out of its packaging. ► Make the required settings (e.g. master-slave settings) on the drive. ► Secure the EasyChange rails on the side of the hard disk by inserting the upper pins of the EasyChange rail in the corresponding holes of the hard disk.
- Page 55 System expansions Removing a hard disk drive ► Disconnect all cables connected to the drive (data cable, power supply cable). ► Press the EasyChange rails in the direction of the arrows (1). ► Pull the hard disk drive out of the carrier (2). ►...
-
Page 56: Installing And Removing Smartcard Reader (Celsius V Only)
System expansions Installing and removing SmartCard reader (Celsius V only) In systems equipped with a SmartCard reader, access can be restricted to those users who have a corresponding SmartCard. Installing a SmartCard reader for the first time ► Open the casing (see "Opening the casing" chapter). ►... - Page 57 System expansions ► Break off the plastic (a) tag. Installing a SmartCard reader ► Open the casing (see "Opening the casing" chapter). ► Remove the front (see "Removing the front panel" chapter). ► Pull the slide-in module out of the casing. ►...
- Page 58 System expansions ► Push the SmartCard reader as far as possible into the casing in the direction of the arrow. ► Attach the SmartCard reader cable to the mainboard connector (see the technical manual for the mainboard). ► Attach the front panel (see "Attaching the front panel"). ►...
-
Page 59: Installing And Removing Front Usb Or Usb Audio Ports
System expansions Installing and removing front USB or USB audio ports In the gap beside the floppy disk drive, two USB ports or one USB port combined with two audio ports can be installed (headphone out, microphone in). Installing front USB or USB audio ports ►... - Page 60 System expansions ► First engage the tab (1). ► Fasten the USB or USB audio ports with the screw (2). ► Feed the cables for the USB or USB audio ports through the slide-in module slot into the inside of the unit. ►...
- Page 61 System expansions ► Remove the blanking plate for the USB or USB audio ports from the front panel. ► Insert the appropriate ports frame for the USB or USB audio ports into the front panel. The USB interface and the USB-audio interface each have a separate interface frame. ►...
- Page 62 System expansions ► Remove the screw (1) and then remove the USB or USB-audio interface (2). ► Slide the floppy disk drive into the slide-in module (1). ► Fasten the floppy disk drive with the screws (2) on both sides of the drive. ►...
-
Page 63: Extensions To The Mainboard
System expansions Extensions to the mainboard Details on whether you can upgrade the main memory or the processor are provided in the technical manual for the mainboard. ► Open the casing (see "Opening the casing" chapter). Upgrading main memory ► Upgrade the memory according to the description in the technical manual for the mainboard. -
Page 64: Replacing Lithium Battery
System expansions Replacing lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced. Incorrect replacement of the lithium battery may lead to a risk of explosion! The lithium battery may be replaced only with an identical battery or with a type recommended by the manufacturer. -
Page 65: Technical Data
Technical data Electrical data Regulations complied with: EN60950/VDE0805, UL 1950, CSA 22.2 No. 950 Protection class: Rated voltage range 100 V -240 V Frequency: 50 - 60 Hz 100 V -127 V: 6 A Max. rated current 200 V - 240 V: 3 A Dimensions Width/depth/height: 205 mm x 560 mm x 445 mm... -
Page 67: Index
Index 3 1/2-inch drive 37 5 1/4-inch drive 37 Data dimensions 57 environmental 57 weight 57 Access permission, SmartCard 21 Data protection 21 Alt Gr key 19 Date Anti-theft protection 21 not correct 26 Audio input 11 Device drivers Audio output 11 parallel port 12 serial port 12 USB 13... - Page 68 Index FCC statement 4 FireWire 11 Alt Gr 19 Floppy disk Control key 19 cannot read 25 Ctrl 19 cannot write 25 Ctrl key 19 indicator 17 Ctrl+Alt+Del 19 inserting 20 Enter key 19 removing 20 Menu key 19 working with 20 Num Lock 19 write-protection 20, 25 Return key 19...
- Page 69 Index Monitor screen Preparing for first use, overview 5 no screen display 24 Preparing for use 5 Mouse overview 5 connecting 7 Printer 11 error 25 Processor 55 port 11 replacing 55 Mouse pointer 25 Property protection 21 Mouse port 6 Protection property and data 21 PS/2 mouse...
- Page 70 Index Technical data 57 Ventilation area 6, 57 Time Video workstation 6 not correct 26 Time, daylight savings 26 Tips 23, 26 Warm boot 19 Transport 4 Weight 57 Trouble Workstation floppy disk 25 anti-theft protection 21 mouse 25 cabling 10 screen 24 cannot boot 23 workstation 23...
