- Page 1 Joybee 720 (DA720) Digital Audio Player User’s Manual Welcome...
-
Page 2: Important Information
BenQ Corporation. Disclaimer No warranty or representation, either expressed or implied, shall BenQ Corporation make with respect to the quality, accuracy or fitness for any particular purpose of this document. The information in this document is subject to change without notice. - Page 3 determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following mea- sures: !Reorient or relocate the receiving antenna. !Increase the separation between the equipment and receiver. !Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Page 4 !Avoid high volume which may damage hearing. !BenQ Corporation assumes no responsibility for the loss of data due to damage of device, repair of device and/or battery replacement. Users are advised to back up all data on other storage device. Use of device not in accordance with the instructions (such the cautions) will void the warranty.
-
Page 5: Table Of Contents
Launching to Main Menu..........16 Playing a MP3/WMA File........... 17 Playing an Audio File............17 Operating the Joybee 720 When a File is Being Played.. 17 Pause a Playing File ............17 Fast Forward ..............17 Next File ................ 18... - Page 6 Creating the Playlist ............18 Using Hot Keys .............19 Locking Buttons ............20 Listening to FM Radio............20 Operating the Joybee 720 When Listening to FM Radio20 FM Tuner ..............20 FM Preset ..............21 Viewing Pictures with the Joybee 720 ........22 Operating the Joybee 720 When Viewing Pictures..22 Viewing JPEG Files ............22...
- Page 7 Overview of QMusic ............33 Adding Music to the Joybee 720 Using QMusic ....37 Adding Music from an Audio CD to the Joybee 720 ..38 Adding Files from a PC to the Joybee 720 ...... 42 Updating the Joybee 720 Automatically with QMusic ..45 Deleting Files Using QMusic..........
- Page 8 Table of Contents...
-
Page 9: Thank You For Using Benq Joybee 720 Digital Audio Player
Player! In this manual, you will find detailed descriptions and instruc- tions of every function on the Joybee 720 and on QMusic as well. Please read carefully in order to use these convenient functions and enjoy high quality music with the Joybee 720. -
Page 10: Package Contents
Digital Audio Player Power Adapter USB Cable Earphones Quick Start Carrying Bag Guide CD-ROM Warranty (emanual/ Card QMusic) *Appearance of product shall be subject to the product inside package 2 Thank you for Using BenQ Joybee 720 Digital Audio Player! -
Page 11: Minimum System Requirements
If you want to install QMusic on a PC to convert music on an audio CD into MP3 files for use on the Joybee 720 or use the Joybee 720 as a hard drive disk, your PC must comply with the following requirements: •... -
Page 12: Description And Functions Of Different Parts
LCD display USB cable port with cover SD card slot Left Side View DC In jack Top View Strap Lock slider for power Earphone jack hole On/ Off and lock 4 Thank you for Using BenQ Joybee 720 Digital Audio Player! - Page 13 …For connection with earphones Strap Hole …To attach a carrying strap Lock Slider …Slide to power on/off the Joybee 720 or to lock the buttons. The Front Panel LCD Display Thank you for Using BenQ Joybee 720 Digital Audio Player! 5...
- Page 14 …Press to select different modes while playing audio files. …To fast-forward the playing track. To scroll down the menu. …Press to select different modes while playing audio files. 6 Thank you for Using BenQ Joybee 720 Digital Audio Player!
-
Page 15: Main Screen And Status Bar
Indicates single track repeat mode. Indicates random mode. Indicates random repeat mode. Indicates battery status as half full. Indicates battery status as charging. Indicates photos in normal mode Thank you for Using BenQ Joybee 720 Digital Audio Player! 7... - Page 16 Icon Description Indicates to rotate the photo Indicates to zoom in or our the photo Indicates keys are locked. 8 Thank you for Using BenQ Joybee 720 Digital Audio Player!
-
Page 17: The Joybee 720 Menu Tree
Repeat-Shuffle Normal/Track/All/ Play Option Random On/Off Intro Equalizer EQ Off/Pop/Jazz/Clas- sical/Rock/My Own Slide-Show No Repeat/Repeat All Repeat Date-Time Contrast Always/10s/30s/60s/120s Backlight English/Simplfied Chinese/Tradi- Multiple Language System tional Chinese Info. Refresh Thank you for Using BenQ Joybee 720 Digital Audio Player! 9... -
Page 18: Getting Started
Getting Started... Charging the Battery When the battery is fully charged, the Joybee 720 offers about 10 hours of continuous replay time for MP3 music. Of course, the exact replay time is subject to the condition of battery, operation frequency and the format of files being played. -
Page 19: Charging With A Usb Cable
Joybee 720 completely. Charging with a USB Cable Connect the Joybee 720 to a computer with the provided USB cable. When charging by PC through a USB cable, please have your PC on rather than in idle mode or off. -
Page 20: Installing Drivers And Software
The software CD provides QMusic and the relevant software for running QMusic. 1. Put the software CD that comes with the Joybee 720 in the CD-ROM drive on your PC. The installation menu will dis- play on the PC screen in a few seconds. -
Page 21: Operation Of Hdd Upgrade
Please do not rename, remove or delete the file named as “system\pp5020.mi4” and the folder “system\font” in your Joybee 720. Any intention to rename, remove or delete the two files will cause irreversible damage to the Joybee 720 and lead to system crash. -
Page 22: Using Sd Card
Joy- bee 720 can be reconstructed. Using SD Card The Joybee 720 supports reading data on a SD card. Please fol- low the steps to use a SD card. 1. Eject the dummy card in the player’s SD card slot. -
Page 23: Using Benq Joybee 720 As Digital Audio Player
The second way allows you to transfer audio files and play them even when the PC you are using doesn’t have QMusic on it. The third way to transfer files to the Joybee 720 is using SD cards. Transferring Files with QMusic Turn on your Joybee 720 and connect it to your PC using the USB cable provided as described in "Connecting the Joybee... -
Page 24: Transferring Files By Sd Card
Launching to Main Menu 1. Slide the power switch into on and turn the Joybee 720 on. 2. In standby mode, you can see the main function menu list. -
Page 25: Playing A Mp3/Wma File
• The player starts playing from the first track of Show Title if you press Operating the Joybee 720 When a File is Being Played Pause a Playing File When a file is being played, press to pause and to play the file again. -
Page 26: Next File
Audio files can be listed according to different titles, album names, artists, genres or folder names; a new playlist can be created or edited according to these information, too. 1. Select Music from Main Menu and press 18 Using BenQ Joybee 720 as Digital Audio Player... -
Page 27: Using Hot Keys
EQ mode and enter the selection of Intro mode and Repeat-Shuffle mode. 3. Use to switch between Intro On and Off. Press to confirm the setting and exit the selection, Using BenQ Joybee 720 as Digital Audio Player 19... -
Page 28: Locking Buttons
Shuffle modes of Normal, Track, All and Random. Press to confirm the selected setting and exit. All the operations of the Joybee 720 but FM radio are not restricted to the function of playing audio files. In other words, you can play music or other audio files as back- ground music while operating other functions like viewing photos. -
Page 29: Fm Preset
Press nd a message shows the Joybee 720 is scanning. After the auto-scan is done, it will show an valid channel. 8. You can always adjust the volume while listening to FM radio by pressing 9. -
Page 30: Viewing Pictures With The Joybee 720
4. To exit the present menu, press and hold Viewing Pictures with the Joybee 720 The colored LCD monitor allows the Joybee 720 for showing pictures and slides in JPEG format. Operating the Joybee 720 When Viewing Pictures Please refer to "Transferring Data with Windows File Man- ager"... -
Page 31: Showing Slides
7. Press and hold to exit the Create Slide mode. Using BenQ Joybee 720 as Digital Audio Player 23... -
Page 32: Deleting Slides
5. Whether you want to replace, insert or delete a picture, a dialog box will popup and confirm next action. Use to select the next step and press confirm. 24 Using BenQ Joybee 720 as Digital Audio Player... -
Page 33: Adding Background Music Into Slides
Photo directly. Erasing Files in the Joybee 720 A good way to make the Joybee 720 to work better is to remove the unnecessary files. There are three modes of erasing files. Erase Single Audio File 1. -
Page 34: Erase All Audio Files
3. A dialog box will appear on the OSD and ask if you want to preceed the deletion. Use to select your answer as yes or no, and press to confirm. 26 Using BenQ Joybee 720 as Digital Audio Player... -
Page 35: Other Setups
4. While the system if off automatically, press any key to power on the Joybee 720 again. Play Options Four play options of the Joybee 720 refer to the use of playing audio files and pictures/slides. Repeat-Shuffle About the setting of the repeat mode of playing audio files, please refer to "Using Hot Keys"... -
Page 36: Intro Off/On
5. To go back to the previous menu, please press hold it for a second. Intro Off/On The Joybee 720 provides the function to preview the playing music. 1. Enter the submenu of Setup from Main Menu by pressing 2. Choose Play Option and press to confirm. -
Page 37: Slide-Show Repeat
3. In the menu of Play Option, use to select Equalizer and press to make sure. There are 6 built-in EQ modes in the Joybee 720 (Normal, Pop, Jazz, Classical, Rock, and My Own), but you can always create a mode you like. 4. Once decided, press to confirm. -
Page 38: Contrast
2. Choose Multiple Language and press to confirm. 3. Use to select from options of English, Simplfied Chinese and Traditional Chinese. Then press to confirm. 4. Press and hold to exit. 30 Using BenQ Joybee 720 as Digital Audio Player... -
Page 39: System Info
Refresh DB This function allows you to refresh your database every time after transferring files from PC. The Joybee 720 cannot classify the new audio and vedio files and add them into the playlists until the database is refreshed. If the database is not refreshed... -
Page 40: Using Qmusic
You can use it to play audio CDs or MP3s on your PC, convert audio CD tracks into MP3 format, create playlists, transfer music to your the Joybee 720, burn music CDs and create your own music album. -
Page 41: Overview Of Qmusic
Overview of QMusic The user interface of the QMusic program is shown in the illustration below. Action System Display buttons buttons Playback Status buttons Feature Right buttons Left panel panel Search window Using QMusic 33... - Page 42 Left button: Convert CD audio tracks to MP3 formats. Right button: Add audio files saved in your PC to either Music Library or MP3 folder under the Joybee 720. Left Displays all files supported by QMusic. panel There are two default folders in your hard disk: Music Library and My Joybee.
- Page 43 When you set the Joybee 720 MP3 player automatically synchronizing every time the Joybee 720 MP3 player is connected to your PC, the audio files in the Joybee 720 will be replaced by the files here. Joybee720(F:4595 Mb Available\Capacity...): This appears when your Joybee 720 MP3 player is connected to your PC.
- Page 44 Feature Sets repeat or random playing of files in buttons playback mode and provide additional options. Setting butting: Click to have general settings dialogue box. Repeat button: Click to repeat playback all tracks. Random button: Click to random play all tracks.
-
Page 45: Adding Music To The Joybee 720 Using Qmusic
Connect the the Joybee 720 to the PC using the procedure described in "Connecting the Joybee 720 to a PC" on page 51. The icon of the Joybee 720 appears in the left panel of the QMusic interface, and the directories on the Joybee 720 are displayed under the icon. -
Page 46: Adding Music From An Audio Cd To The Joybee 720
QMusic, and the files on the CD appear in the right panel. 2. Select the files to be added to the Joybee 720 by clicking the check boxes in front of the files. - Page 47 3. Click the icon, and QMusic starts converting the selected files into MP3 files. 4. After the conversion is completed, a New Album is added to the left panel. All the converted files are placed in this album. Click the New Album to display the details of files in the right panel.
- Page 48 5. Select the files to be added to the Joybee 720. To select more than one file, press and hold the Ctrl key on the keyboard while selecting the files. To select all files, click the first file, press and hold the Shift key on the keyboard, and then click the last file.
- Page 49 6. Drag to copy the selected files from the right panel to the MP3 directory under the icon indicates as the Joybee 720. Check if there is enough HDD space on the Joybee 720 before transferring files to the Joybee 720.
-
Page 50: Adding Files From A Pc To The Joybee 720
Adding Files from a PC to the Joybee 720 Follow these steps to add files from a PC to your Joybee 720. 1. Click the My Joybee folder in the left panel. 42 Using QMusic... - Page 51 2. Press to open a dialogue box for selecting files. Browse and select MP3 or WMA files to be add to the Joybee 720 from the PC. Press Open to add the selected files to My Joy- bee. 3. Click the Joybee 720 icon on the QMusic interface.
- Page 52 QMusic starts transferring the files in the My Joybee folder to the Joybee 720. Before transferring the selected files to the Joybee 720, QMusic shows a dialog box to ask if you want to delete the existing files in the My Joy- bee folder.
-
Page 53: Updating The Joybee 720 Automatically With Qmusic
Updati Automatically with QMusic You can set up the Joybee 720 to be updated with the music from the My Joybee folder automatically when it is connected to the PC. 1. Click the My Joybee folder in the left panel. - Page 54 2. Press to open a dialogue box for selecting files. Browse and select MP3 or WMA files to be added to the Joybee 720 from the PC. Press Open to add the selected files to My Joybee. 3. Press on the right panel of QMusic in the function but- ton area.
- Page 55 4. In the Option dialog box shown, click the Joybee tab. 5. Select Automatically launch QMusic when Joybee added under Launch Settings and Automatically transfer MP3 files Using QMusic 47...
- Page 56 6. Connect the Joybee 720 to the PC and QMusic automati- cally updates the files on the Joybee 720 with the files in My Joybee folder. From now on, if you want to automatically update files on the Joybee 720, you only need to save files in the My Joybee folder and connect the Joybee 720 to your PC.
-
Page 57: Deleting Files Using Qmusic
Use the following procedure to delete files on your Joybee 720 using QMusic. 1. Start QMusic. 2. Turn on the Joybee 720 and connect it to the PC using the USB cable. 3. Locate the files to be deleted by clicking on the MP3 subdi- rectory under the Joybee 720 icon in the left panel of QMu- sic. - Page 58 To select all files, click the first file, press and hold the Shift key on the keyboard, and then click the last file. 5. Press the Delete key on the keyboard to delete all selected files from the Joybee 720. 50 Using QMusic...
-
Page 59: Using The Joybee 720 As Usb Hard Disk
PC to the Joybee 720. Transferring a File from the Joybee 720 to a PC 1. Refer to the steps in "Connecting the Joybee 720 to a PC" on page 51 and make the connection. 2. Click My Computer or Windows Explorer on your PC. The Joybee 720 will appear as a removable drive. -
Page 60: Transferring A File From A Pc To The Joybee 720
1. Connect the Joybee 720 to your computer with the USB cable which comes with the package. For more information, refer to "Connecting the Joybee 720 to a PC" on page 51. 2. Click My Computer or Windows Explorer on the computer, then locate the file you want to copy to the Joybee 720. -
Page 61: Disconnecting The Joybee 720 From A Pc
Select USB Mass Storage Device in the dialog box and press Stop. 3. Another dialog box as shown bellow will appear on the screen. Select BenQ Joybee 720 USB Device and press OK. Using the Joybee 720 as USB Hard Disk 53... - Page 62 4. Close the dialog box appears on the bottom of the screen and disconnect the Joybee 720 from the PC. Operation procedure may differ from one OS to another. 54 Using the Joybee 720 as USB Hard Disk...
-
Page 63: Troubleshooting
When power supply is unstable while the Joybee 720 is con- nected to a PC, it may cause data loss. Hence, we strongly rec- ommend you to back up all data stored in the Joybee 720. BenQ Corporation shall make no representation on damage or indemnification arising out of loss of data. -
Page 64: Service
Service If you cannot solve the problems found on the Joybee 720 with the troubleshooting guide, please contact our worldwide ser- vice locations to obtain the latest drivers and online services. Area Country Telephone Number E-mail Address or Website Asia... - Page 65 Internet. For users in Europe, to avoid any unnecessary inconve- nience with your BenQ product, we suggest that you read the instruction manual carefully and must visit our website, www.benq-eu.com for the details of warranty terms and conditions before contact our service agent.
