- Page 1 Joybee 110 (DA-110) Digital Audio Player User Manual Welcome...
-
Page 2: Copyright
Copyright Copyright 2003 by BENQ Corporation. All rights reserved. No part of this publication may be repro- duced, transmitted, transcribed, stored in a retrieval system or translated into any language or com- puter language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. -
Page 3: Table Of Contents
System Requirements 1 Touring the Joybee 110 Digital Audio Player 2 Buttons/Ports/Parts 2 The LCD Display 4 Getting the Joybee 110 Digital Audio Player Ready 5 Connecting Earphone 5 Charging the Battery 5 Installing Joybee 110 Digital Audio Player Software 6... - Page 4 Setting language 10 SW Upgrade 10 Buttons Lock 10 Using the Joybee 110 Digital Audio Player as a USB Flash Drive 11 Using QMusic 12 The Main Screen 12 Adding songs to the Joybee 110 Digital Audio Player using QMusic 14...
-
Page 5: Your Joybee 110 Digital Audio Player
Joybee 110 also features audio files segment repeating and options for play speed, making it an ideal tool for language learning. Besides, you can use the Joybee 110 Digital Audio Player as a flash drive, so you can not only make your music mobile, but also move your important data with you. -
Page 6: Touring The Joybee 110 Digital Audio Player
Touring the Joybee 110 Digital Audio Player Buttons/Ports/Parts (1) LCD Dipslay (2) Earphone Jack (3) Necklet Hole (4) Scroll Up/ Next/ Fast Forward (5) Play/ Pause/ Stop/ Power (6) Scroll Down/ Previous/ Fasr Rewind (7) Menu/ Function (1) LCD display Displays the status of the player. - Page 7 As a USB port, you can connect the USB cable to this port and the USB port on your computer to establish connection between both. For connecting Joybee 110 to computer when charging. button to start playing. will appear on the dis-...
-
Page 8: The Lcd Display
The player will turn off automatically, and any recording in progress will be saved. Your Joybee 110 Digital Audio Player indicate that the battery power is sufficient. Only one bar in the icon , the battery is near empty and... -
Page 9: Getting The Joybee 110 Digital Audio Player Ready
Getting the Joybee 110 Digital Audio Player Ready Connecting Earphone As illustrated, plug the earphone into the earphone jack on the Joybee 110 Digital Audio Player. Charging the Battery Connect Joybee 110 Digital Audio Player to PC USB port with the USB cable. When charging completes, “Charging Completes”... -
Page 10: Installing Joybee 110 Digital Audio Player Software
Installing Joybee 110 Digital Audio Player Software Insert the Joybee 110 Digital Audio Player CD-ROM into your CD-ROM drive. A few seconds later, a software installation menu will appear on your computer screen. Click on an item to select it and start installing the selected software. -
Page 11: Installing The Usb Driver
Found message will appear and installation will be completed automatically. Installing in Windows 98 In addition to clicking Install Joybee 110 Driver on the software installation screen, you can also install the USB driver following the steps below: 1. Turn on the power of the Joybee 110 Digital Audio Player by pressing the then connect it to the USB port of your computer using the USB cable. -
Page 12: Using The Joybee 110 Digital Audio Player
Using the Joybee 110 Digital Audio Player Turning the Player On and Off In power off status, long press the In playback and recording modes, long press the enter standby mode. In standby status, press and hold the Playing Music 1. -
Page 13: Equalizer
One: Repeat current one. Joybee 110 will play current audio repeatedly. The icon appear on the display in this mode. Normal: No repeat. The Joybee 110 Digital Audio Player will just play all audio files once in this mode. Equalizer You can select from the following equalizer modes: Speech, Bass, Rock, Pop, Jazz, Classic, and Normal. -
Page 14: Recording Setups
Complete: Executes complete format. Exit: Scroll here and press Setting Joybee 110 Auto-Off time You can set your Joybee 110 to turn off automatically when in idle mode for different peri- ods of time: Never, 1Min, 3Min, 5Min, 10Min. Scroll to confirm. -
Page 15: Using The Joybee 110 Digital Audio Player As A Usb Flash Drive
2. Now you can manage files by using the cut/copy/paste commands between your PC and the player. If the files are not in .mp3, .wma or .tvf formats, they will not be recognized by the Joybee 110 Digital Audio Player as music files, and will not effect normal functions. -
Page 16: Using Qmusic
CDs and compile your own music album. When used with the Joybee 110 Digital Audio Player, you can easily convert CD music into .mp3 format and transfer it to the player. You can also let QMusic update the music files in the player automatically. - Page 17 Music Playing Buttons You can use these buttons to play music. The detailed information of playlist will appear here, including total Status Bar number of songs and total playback time. Feature Buttons When playing music, you can use these buttons to change play mode. Right Panel Shows songs in the selected playlist/media on the left panel.
-
Page 18: Adding Songs To The Joybee 110 Digital Audio Player Using Qmusic
Adding songs to the Joybee 110 Digital Audio Player using QMusic After QMusic is opened, connect the Joybee 110 Digital Audio Player to your computer using the USB cable. The icon will appear on the left panel of QMusic and default folders MP3 and MicIn will appear below Adding CD music to the Joybee 110 Digital Audio Player 1. - Page 19 2. Check the checkboxes next to the songs you want to transfer to the player. When finished, click the button. QMusic will convert selected songs into MP3 format. 3. When QMusic has done with the conversion process, it will place all converted files in a New Album playlist on the left panel.
- Page 20 4. Click and drag the selected songs on the right panel to the MP3 directory under the icon. Before dragging the selected songs to the Joybee 110 Digital Audio Player, make sure that there is enough mem- ory space. Adding new songs to the Joybee 110 Digital Audio Player from your computer 1.
- Page 21 .mp3, .wav or .wma song files you want to transfer to the Joybee 110 Digital Audio Player. Click Open and the selected song files will be added to the My Joybee playlist.
- Page 22 If you want to keep these songs, please back them up in your computer before continuing. Before dragging the selected songs to the Joybee 110 Digital Audio Player, make sure that there is enough mem- ory space. Let QMusic automatically update the songs upon getting connected to the Joybee 110 Digital Audio Player 1.
- Page 23 .mp3, .wav or .wma song files you want to transfer to the Joybee 110 Digital Audio Player. Click Open and the selected song files will be added to the My Joybee playlist.
- Page 24 Every time you connect the Joybee 110 Digital Audio Player to your computer, the update action will be carried out automatically. Before dragging the selected songs to the Joybee 110 Digital Audio Player, make sure that there is enough memory space.
-
Page 25: Notes, Faq And Troubleshooting Tips
When transferring files to the Joybee 110 Digital Audio Player, do not remove the USB cable when the transfer is in progress. The Joybee 110 Digital Audio Player only plays the files in default folder MP3 and MicIn in the memory. -
Page 26: Faq And Troubleshooting Tips
4. Select Copy in the Windows Media Player File menu, and then select Copy to portable devices. 5. A file list will appear. Check to select the songs you want to copy to the Joybee 110 Digital Audio Player and then click the Copy button located at the upper right corner of the screen. - Page 27 The file size is smaller than the free memory available in my player, but I still cannot transfer it to my player The Joybee 110 Digital Audio Player allocates memory in cluster of 16KB or 32KB. A file of 1 Byte also occupies one cluster, so a file of a size smaller than the free memory available might not be transferred to the player.
