4. Refrigeration cycle diagram
Cooling & heating
Indoor unit
outdoor unit
Auxiliary accumulator for 12K
Valve
Sensor of room temp
.
4 way valve
Heat exchanger
Heat exchanger
Sensor of heat exchanger temp
Accumulator
.
Compressor
Valve
Capillary
8
