Page 1: Instruction Manual
Instruction Manual Precis SD Distribution Matrix M a t r i x S w i t c h e r s R e l e a s e : 1 0 / 2 0 / 2 0 0 8 ( F i r m w a r e v 1 . 4 . 1 ) - Page 2 Products repaired under this policy will carry a ninety (90) day warranty on material and labor. • AMX will notify the AMX Authorized Partner with the cost of repair, if cost is greater than the Standard Repair Fee, within five (5) days of receipt.
- Page 3 LICENSE GRANT. AMX grants to Licensee the non-exclusive right to use the AMX Software in the manner described in this License. The AMX Software is licensed, not sold. This license does not grant Licensee the right to create derivative works of the AMX Software.
-
Page 4: Table Of Contents
Contents ESD Warning ...1 Important Safety Information & Instructions ...2 Information et directives de sécurité importantes...3 Notices ...4 Overview & General Specifications ...7 Applicability Notice ... 7 Product Notes ... 7 Front View ... 8 Rear View ... 9 Precis SD General Specifications ... 11 Configuration Information &... - Page 5 Contents Appendix A – Managing Configuration Files ... 45 Overview ... 45 Installing & Launching XNConnect... 46 Discovering a System... 47 Opening an .xcl Configuration File ... 48 Navigating the Interface ... 49 Modifying an .xcl Configuration File... 50 Loading an .xcl Configuration File ... 54 Device Discovery Support ...
-
Page 6: Esd Warning
Grounding straps, conductive smocks, and conductive work mats are specifically designed for this purpose. Anyone performing field maintenance on AMX AutoPatch equipment should use an appropriate ESD field service kit complete with at least a dissipative work mat with a ground cord and a UL listed adjustable wrist strap with another ground cord. -
Page 7: Important Safety Information & Instructions
There are no user serviceable parts inside an AMX AutoPatch product; service should only be done by qualified personnel. If you see smoke or smell a strange odor coming from your AMX AutoPatch product, turn it off immediately and call technical support. -
Page 8: Information Et Directives De Sécurité Importantes
Placez uniquement des fusibles de calibre exact dans les boîtiers. Veillez à ce que la prise de courant soit proche de l’appareil et facile d’accès. Veillez à ce que votre appareil AMX AutoPatch soit installé sur une surface stable ou qu’il y soit fermement maintenu. -
Page 9: Notices
AMX. Copyright protection claimed extends to AMX hardware and software and includes all forms and matters copyrightable material and information now allowed by statutory or judicial law or herein after granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks, etc. - Page 10 Lithium Batteries Notice Switzerland requires the following notice for products equipped with lithium batteries. This notice is not applicable for all AMX equipment. Upon shipment of the products to Switzerland, the requirements of the most up-to-date Swiss Ordinance Annex 4.10 of SR 814.013 will be met by providing the necessary documents and annual reports relative to the disposal of the batteries to the Swiss Authorities.
- Page 11 Notices Precis SD Instruction Manual...
-
Page 12: Overview & General Specifications
Supports full Device Discovery through AMX’s AutoPatch Duet module (firmware v1.4.1 required) Optional TCP/IP control available Backed by AMX Warranty (see warranty at www.amx.com or on the AMX AutoPatch CD) 24-hour technical support * Although primarily designed as a pre-engineered, standalone system, the Precis SD can be linked to other AMX AutoPatch Matrix Switchers. -
Page 13: Front View
* BCS is sent as ASCII characters through the CONTROL (RS-232) port. For information on BCS commands, see the BCS Protocol Instruction Manual on the AMX AutoPatch CD or at www.amx.com. Note: Features and specifications described in this document are subject to change without notice. -
Page 14: Rear View
CPU/Control hardware Although primarily designed as a pre-engineered, standalone system, the Precis SD can be linked to other AMX AutoPatch Matrix Switchers. For information on linking between systems, see the instruction manual for the specific product. Note: The Comm light on the front panel indicates Ethernet traffic on the system. - Page 15 Overview & General Specifications Power Receptacle & Specifications The universal power receptacle is in the lower left hand corner on the rear of the enclosure (FIG. 4). Maximum power specifications are on the power receptacle. The power receptacle will accept all major international standard power sources.
-
Page 16: Precis Sd General Specifications
Ultra-Wideband (500 MHz) Signals – on page 33 Hi-Z Sync Signals – on page 33 Standard Audio Signals – on page 34 AMX reserves the right to modify its products and their specifications without notice. Precis SD Instruction Manual Value... -
Page 17: Configuration Information & Control Options
For more information, see the “Control Panel Operation” chapter on page 35. AMX Control Devices The Precis SD is compatible with a number of AMX control devices. For specific control programming information, contact your AMX representative. AMX Control Software Precis SD enclosures can be controlled using AMX AutoPatch software: APControl 3.0 –... - Page 18 The Precis SD can be controlled with an external serial controller that sends and receives ASCII characters via the CONTROL port. AMX AutoPatch has developed a command language, BCS (Basic Control Structure) protocol, for programming control operations and for diagnostic purposes.
- Page 19 Overview & General Specifications Precis SD Instruction Manual...
-
Page 20: Installation & Setup
Installation & Setup Site Recommendations When placing the enclosure, follow the recommendations and precautions in this chapter to reduce potential installation and operation hazards. Environment Choose a clean, dust free, (preferably) air-conditioned location. Avoid areas with direct sunlight, heat sources, or high levels of EMI (Electromagnetic Interference). -
Page 21: Unpacking
(e.g., plugging into a power strip), pay particular attention to supply connections. Caution: For proper start up, turn on all power switches for the AMX AutoPatch equipment at the same time before applying power to the source and destination devices. We recommend attaching all power cords to a single surge protector and/or an AC line conditioner. -
Page 22: Rack Installation & System Setup
Rack Installation & System Setup The Precis SD Distribution Matrix enclosure can be mounted in a standard EIA 19 in. (48.26 cm) rack. Rack installation ears are included, and directions for attaching the rack ears are included in the rack installation instructions (page 18). - Page 23 Installation & Setup Installation Procedure A flow chart showing the installation sequence is in FIG. 5. The procedure following provides general steps with references to detailed information found later in this manual. FIG. 5 Installation procedure Caution: To prevent overheating and airflow restriction, avoid placing high heat producing equipment directly above or below the enclosure.
- Page 24 Creating / Defining local presets for macros – See page 52 in “Appendix A – Managing Configuration Files.” Creating global presets – See the BCS Protocol Instruction Manual on the AMX AutoPatch CD or at www.amx.com. Precis SD Instruction Manual...
-
Page 25: Attaching External Controllers
The communication protocols listed above are used for these control options: AMX Control Devices The Precis SD is compatible with a number of AMX control devices. For specific control programming information, contact your AMX representative. AMX AutoPatch Remote Control Panels & SBCs AMX AutoPatch remote control panels and other AMX AutoPatch control devices (SBCs, and Preset SBCs) usually connect to the REMOTE port on the CPU. - Page 26 Once a PC is attached to the Precis SD, the system can be controlled by running APControl software on the attached PC (see the AMX AutoPatch CD). The system can also be controlled by entering BCS commands into a terminal emulation program (e.g., HyperTerminal). For information on BCS commands, see the BCS Protocol Instruction Manual on the AMX Autopatch CD or at www.amx.com.
- Page 27 Execute a test switch to ensure the Precis SD is working properly (see “Executing a Test Switch” on page 29). – For specific control programming information, contact your AMX – Install and open the program from the AMX AutoPatch CD (if your AMX – Open the program, select the COM port, and Port...
- Page 28 Attaching External XNNet Controllers An XNNet device is any device that sends and receives XNNet protocol over the REMOTE port. AMX AutoPatch XNNet control devices include remote control panels, Single Bus Controllers (SBCs), and Preset SBCs. The instructions below are for attaching a device to the REMOTE port, found on the CPU. For specific product information, see the individual device’s documentation.
-
Page 29: Attaching Inputs & Outputs
Installation & Setup Attaching Inputs & Outputs Input and output connectors are the attachment points for source and destination devices that connect to the system. Viewed from the rear of a Precis SD enclosure, the inputs (for sources) are on the left side of the enclosure, and the outputs (for destinations) are on the right side. - Page 30 Cabling Video Connectors The video connectors are color coded; the white BNC connectors are inputs and the black BNC connectors are outputs. Tip: Using lacer bars or some other type of cable management system lessens the strain from cable weight on the connectors and makes servicing the enclosures easier. For RGBHV signals, you need to attach corresponding input and output connectors on five connectors to route the entire signal.
- Page 31 Installation & Setup Wiring Audio Connectors The stereo audio connectors for the Precis SD are pluggable 5-position terminal block that can be wired for balanced (differential) or unbalanced (single-ended) audio (FIG. 14). Wiring Sources & Destinations Source and destination devices require either balanced (differential) or unbalanced (single-ended) connections.
-
Page 32: Applying Power & Startup
To avoid an overload, note the power consumption rating of all the equipment connected to the circuit breaker before applying power. Caution: To avoid system damage, turn on all power switches for the AMX AutoPatch equipment at the same time before applying power to the system’s source and destination devices. -
Page 33: Serial Control Device Startup
(see Appendix B on page 55). For additional information on checking the firmware version, see page 57. Note: AMX reserves the right to add to the contents of the splash screen at any time, without notice. Firmware version Precis SD Instruction Manual... -
Page 34: Executing A Test Switch
You can execute a test switch from the following: Control panel AMX control device Control software such as APControl 3.0 or APWeb BCS (Basic Control Structure) commands over an external controller An external third-party controller... - Page 35 When Output Key 2 illuminates, the switch is successful. Verify that the source signal is present (visible and/or audible) at the destination. AMX Control Device For executing and disconnecting switches using an AMX control device, see the specific control device documentation. APControl 3.0 or APWeb Directions for executing and disconnecting switches using APControl 3.0 are found in its Help file.
-
Page 36: Troubleshooting
Verify that the source signal is present (visible and/or audible) at the destination. For a complete list of BCS commands and responses, see the BCS Protocol Instruction Manual on the AMX AutoPatch CD or at www.amx.com. Troubleshooting If the test switch did not execute correctly: Check the power indicator on the front of the enclosure. -
Page 37: Technical Support
Before contacting technical support with a question, please consult this manual. If you still have questions, contact your AMX representative or technical support. Have your system’s serial number ready. The system’s serial number is normally located in two places on the enclosure; on the left rear and on the left side (near the power receptacle). -
Page 38: Signal Specifications
Signal Specifications This chapter contains the specifications for the video and audio signals routed by the Precis SD system. For information on cabling and wiring video and audio connectors, see “Attaching Inputs & Outputs” on page 24. Ultra-Wideband (500 MHz) Specifications Ultra-Wideband (500 MHz) Signal Specifications Parameter Frequency Response... -
Page 39: Standard Audio Specifications
Type Connectors * Total of input gain plus output gain cannot exceed +10 dB. AMX reserves the right to modify its products and their specifications without notice. Conditions 20 Hz to 20 kHz 20 Hz to 20 kHz, Vin = -10 dBu to +20 dBu <0.1%... -
Page 40: Precis Sd Control Panel Operation
Precis SD 12x8 control panel (with digital volume control) FIG. 18 Note: AMX AutoPatch enclosures can also be controlled using BCS (Basic Control Structure) commands transmitted through an external controller; for more information, see the “BCS Protocol Instruction Manual” on the “AMX AutoPatch CD” or at www.amx.com. -
Page 41: Control Keys
Precis SD Control Panel Operation Control Keys Macro Key or Up Arrow Key (for audio) Lock Key or Down Arrow Key (for audio) Cancel Key Status Key or Volume Adjust Key (for audio) FIG. 19 Precis SD control panel keys (dual-labeled keys can adjust audio) Modes of Operation A Precis SD Control Panel works in three standard modes: Switch (default) –... -
Page 42: Executing & Disconnecting Switches
Executing & Disconnecting Switches A switch is an active connection between an input (source) device and one or more output (destination) devices. The signals routed in a switching operation are individual signals or groups of individual signals coming through the connectors on the rear of an enclosure. You can execute switches from the Control Panel using the steps below or by executing a local preset / macro (see page 40). - Page 43 Precis SD Control Panel Operation Note: Only one input signal can be routed to any given output. To execute a switch selecting output (destination) first: Press the Cancel Key. All the lights on the control panel turn off. The control panel is in Switch mode. Press a Level Key to select a level (can be omitted when switching on the default level).
-
Page 44: Verifying Signal Status
Verifying Signal Status Signal status can be verified to confirm that a switch has executed properly or to confirm correct routing to multiple outputs (destinations) without accidently executing or disconnecting switches. Input status and output status both function on the Precis SD Control Panel. An output can only be connected to one input (source);... -
Page 45: Executing Macros (Local Presets)
Local presets are not programmed (defined) at the factory. To program local presets, use XNConnect (see “Appendix A – Managing Configuration Files” on page 45 and the Help file) or contact your AMX representative (for contact information, see page 32). Once the local presets have been defined as part of the configuration file, local presets can be executed at any time during normal operation. -
Page 46: Adjusting Audio
When volume or digital input gain is adjusted for a device on one level, the adjustment remains in effect for that device on all levels switching audio signals. Important: For AMX AutoPatch systems, the total through-system gain (the amount of input gain plus the amount of output gain) specified for any input/output routing path cannot exceed 10 dBr. - Page 47 Precis SD Control Panel Operation Adjusting Digital Input Gain If your system has digital input gain control, adjustments (within the gain range for the specific audio inputs) can be made at any time during normal operation. When audio is adjusted for a device on one level, the adjustment remains in effect for that device on all levels switching audio signals.
-
Page 48: Locking & Unlocking The Control Panel
Locking & Unlocking the Control Panel The Precis SD Control Panel can be locked by pressing a sequence of Level Keys. Locking the panel prohibits access to the system and can prevent accidental switching. The password can be any combination of the first five Level Keys. The factory default password is the first five Level Keys, going from left to right. - Page 49 Precis SD Control Panel Operation Precis SD Instruction Manual...
-
Page 50: Appendix A - Managing Configuration Files
Make a copy of the current .xcl file every time the file is modified. * If you cannot locate the AMX AutoPatch CD that shipped with your system and your AMX account has the required permissions, you can download the newest version of XNConnect from www.amx.com. -
Page 51: Installing & Launching Xnconnect
Even if XNConnect is already on your PC, install the newest version that shipped on the CD that shipped with your system. We strongly recommend uninstalling the old version of XNConnect before installing a new version. If you cannot locate the AMX AutoPatch CD that shipped with your system, contact technical support (see page 32). System Requirements... -
Page 52: Discovering A System
The XNConnect program opens. When XNConnect is open, you can do either of the following: Discover the system (recommended); see below. Open an .xcl file that is compatible with the system (located on the AMX AutoPatch CD); see page 48. Discovering a System The discovery process queries the attached system for configuration information and properties, including information regarding assigned signals and virtual matrix (level) definitions. -
Page 53: Opening An .Xcl Configuration File
Use the standard Open dialog box to locate and open a compatible configuration file (the file extension is .xcl). The default location is in the APConfig/XCL Samples folder on the AMX AutoPatch CD. From the File menu, select Save As, make a duplicate copy of the file with a new name, and save it to the PC. -
Page 54: Navigating The Interface
Hardware tab Virtual Matrices tab Primary Components of the device primary device View of all AMX AutoPatch devices View of all Communication settings FIG. 24 XNConnect interface showing Hardware view Precis SD Instruction Manual Appendix A – Managing Configuration Files... -
Page 55: Modifying An .Xcl Configuration File
Appendix A – Managing Configuration Files Modifying an .xcl Configuration File Modifying an .xcl configuration file with XNConnect involves entering information in a field or in a series of dialog boxes. A brief look at the contents in the Help file provides a quick overview of the possible modifications. - Page 56 Setting the Control Panel Password Important: The control panel password can be set without loading the entire .xcl configuration file to the system, thereby retaining the factory configuration with the Device Discovery feature. For Precis SD control panels, the numbers in the password correspond to the Level Keys (in order from left to right, the level Keys represent the numbers “0”...
- Page 57 Appendix A – Managing Configuration Files Creating Local Presets (Macros) A local preset is a predetermined collection of switches on the same virtual matrix (level) to be routed simultaneously. Executing a local preset affects only those inputs and outputs specified, not the whole system.
- Page 58 For the first switch, click the source channel (input) and one or more destination channels (outputs). Select multiple destination channels by holding down the Control key while selecting the channels. Click the Assign Switch button. The input appears in the Assignment column of the Destination Channels list; the switch will execute when the local preset is executed.
-
Page 59: Loading An .Xcl Configuration File
XNConnect is all that is necessary. However, certain conditions may warrant a custom string, such as the need to limit the VMs that are available for control by the AMX control system. Or a need may exist to limit the features available for a system, e.g., omitting the ability to adjust input gain, but leaving support for output volume. -
Page 60: Appendix B - Programmer's Interface For System Diagnostics
PC. * AMX reserves the right to add to the contents of the splash screen at any time, without notice. ** Verbosity (i.e., wordiness) refers to the amount of information provided; the higher the verbosity setting, the more information is displayed. -
Page 61: Using Bcs To Access System Diagnostic Information
Appendix B – Programmer’s Interface for System Diagnostics Verbosity Settings The verbosity (v) settings (v0, v1, v2, v3) correspond to the level of detail that will be displayed, with v0 being the lowest level of detail and v3 being the highest level. Component Settings Detailed information for a single system component can be specified by using its identity (i) number setting (i0 through i5) in the following table. -
Page 62: Splash Screen Examples
Splash Screen Examples Following are four examples of splash screen information that could be displayed when different verbosity/component settings are specified. Depending on the amount of detail provided, you may need to scroll to see the entire display. Use the first example to check the host software (IOS) version and the hardware driver (appcode) version. - Page 63 Appendix B – Programmer’s Interface for System Diagnostics ~scrv3i4! [4:Hardware Boards] detected [io boards] count = 5 [board 1] 40d5 [board 2] 40d5 [board 3] 40d5 [board 4] 40fc [board 5] 4180 FIG. 28 Display for v3i4 (verbosity 3, component 4) ~scrv3i5! [5:VM Configuration] count = 3 [VM 0] ‘RGBHVA2’...
- Page 64 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
