- Page 1 RC 9322 .. Twin Cavity Gas Cooker Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured so- lely for the cooking of domestic (household) food and is not sui- table for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not use a steam cleaner because the moisture can get into the applian- ce thus make it unsafe. • Do not touch the appliance with wet or damp hands (or feet). • Do not use the appliance whilst in barefoot. • If you should decide not to use this appliance any longer (or decide to sub- stitute another model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner in accordance to health and...
- Page 5 • WARNING: Danger of fire: do not store items on the cooking surfaces. • WARNING: When correctly installed, your product meets all safety require- ments laid down for this type of product category. However special care should be taken around the rear or the underneath of the appliance as the- se areas are not designed or intended to be touched and may contain sharp or rough edges, that may cause injury.
-
Page 6: Features And Technical Data
Features and Technical Data Right Gas oven Left Fig. 1 Gas oven GAS BURNERS Auxiliary burner (A) 1,00 kW Semi-rapid burner (SR) 1,75 kW Rapid burner (R) 3,00 kW Triple-ring burner (TR) 3,50 kW Important Notes: – The electric ignition is incorporated in the knobs. –... -
Page 7: Control Panel
Control Panel Fig. 2 Controls Description Left gas oven/gas grill control knob Left oven light control knob Minute counter Right oven rotisserie / light control knob Front left burner control knob Rear left burner control knob Front central burner control knob Rear central burner control knob Rear right burner control knob 10. -
Page 8: Minute Counter
Minute Counter Minute Counter The minute counter is a timed acoustic warning device which can be set for a maximum of 60 mi- nutes. The knob (Fig. 3) must be rotated clockwise as far as the 60 minute position and then set to the required time by rotating it anticlockwise. -
Page 9: How To Use The Hob Burners
How to Use the Hob Burners Hob Burners Each hob burner is controlled by a separate gas valve operated by a control knob (fig. 4) which has 3 positions marked on the control panel, these are: – Symbol : Tap closed (burner off ) –... - Page 10 Choice of Burner The burner must be choosen according to the diameter of the pans and energy required. Saucepans with handles which are excessively heavy, in relationship to the weight of the pan, are safer as they are less likely to tip. Pans which are positioned centrally on burners are more stable than those which are of- fset.
- Page 11 CORRECT USE OF TRIPLE-RING BURNER Flat-bottomed pans are to be placed directly onto the pan-support. • To use the WOK, you must place the wok stand in the CORRECT position as shown in figs. 6 - 7. • IMPORTANT The special grille for wok pans (fig. 7) MUST BE PLACED ONLY over the pan-rest for the triple-ring burner.
-
Page 12: How To Use The Gas Oven (Left Oven)
How to use the gas oven (left oven) Attention: General Features The oven door be- comes very hot du- The oven is furnished completely clean; it is advisable, however, upon first use, to turn ring operation. the oven on to the maximum temperature (position ) to eliminate possible traces Keep children away. -
Page 13: Lighting The Oven Gas Burner
Lighting the oven gas burner The thermostat allows the automatic control of the temperature. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-failure device. To light the oven burner operate as follow: Open the oven door WARNING: Risk of explosion! The oven door must be open during this operation. -
Page 14: How To Use The Gas Grill (Left Oven)
How to use the gas grill (left oven) Lighting the grill gas burner Do not grill with oven door closed. The grill burner generates the infra-red rays for grilling. Always fit the heat To light the grill burner operate as follow: shield supplied Open the oven door. -
Page 15: Use Of The Grill
Use of the grill Very important: the grill must always be used with the oven door slightly open and with shield “A” mounted (Fig. 14). Mount shield “A” which serves to protect the control panel from the heat. Turn on the grill, as explained in the preceding paragraphs and let the oven preheat for about 5 minutes with the door ajar. -
Page 16: How To Use The Gas Oven (Right Oven)
How to use the gas oven (right oven) General features Attention: the oven door becomes very The oven is furnished completely clean; it is advisable, however, upon first use, to turn hot during opera- the oven on to the maximum temperature (position ) to eliminate possible traces tion. - Page 17 Lighting the oven gas burner The thermostat allows the automatic control of the temperature. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-failure device. To light the oven burner operate as follows: Open the oven door WARNING: Risk of explosion! The oven door must be open during this operation.
-
Page 18: How To Use The Gas Grill (Right Oven)
How to use the gas grill (right oven) Lighting the grill gas burner Do not grill with oven door closed. The grill burner generates the infra-red rays for grilling. Always fit the heat To light the grill burner operate as follow: shield supplied Open the oven door. - Page 19 Use of the grill Very important: the grill must always be used with the oven door slightly open and with shield “A” mounted (Fig. 21). Mount shield “A” which serves to protect the control panel from the heat. Turn on the grill, as explained in the preceding paragraphs and let the oven preheat for about 5 minutes with the door ajar.
-
Page 20: Rotisserie (Right Oven)
Rotisserie (right oven) This is used for spit roasting under the grill and compri- ses: • an electric motor fitted to the rear of the oven • a stainless steel skewer provided with slide-out heat-resistant handgrip and two sets of adjustable forks •... -
Page 21: Oven Cooking Temperatures
Oven cooking temperatures APPROX. HEAT OF MARK TYPE OF DISH TO COOK TEMP. OVEN Very cool Meringue cakes, 130°C oven slow cooking items Cool or Milk puddings, very rich fruit cakes, i.e., 140°C slow oven Christmas Cool or Stews, casseroles, braising, rich fruit ca- 155°C slow oven kes, i.e., Dundee... -
Page 22: Do's And Do Not's
Do’s and do not’s • Do always grill with the oven door closed. • Do read the user instructions carefully before using the cooker for first time. • Do allow the oven to heat for one and a half hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 23: Care And Maintenance
Care and Maintenance IMPORTANT: It is advisable to clean when the appliance is cold and especially for cleaning the Before ope- enamelled parts. ration of cleaning Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the sur- maintenance faces. -
Page 24: Changing The Oven Light
Changing the Oven Light Disconnect the electrical power supply (for example, by switching off the main power switch). Unscrew the light cover Fit a new bulb. Refit the cover. Note: Use only bulbs designed to resist up to 300°C with the following characteristics: 230 V, type E14 and same power (check watt power as stamped in the bulb itself ) of the replaced bulb. - Page 25 Fig. 24 Fig. 25 Fig. 26 Fig. 27 Fig. 28...
-
Page 26: Storage Compartment
Removal of the Inner Glass Door Panel • The inner glass door panel can easily be removed for cleaning by unscrewing the fixing screws (fig. 29). • When re-assembling ensure that the inner glass is correctly positioned and do not over tighten the screws. - Page 27 Assembling and Dismantling of the Side Runner Frames • Fit the side runner frames into the holes on the side walls inside the oven (Fig. 31). • Slide into the guides, the shelf and the tray (left main oven only) (fig. 32). The rack must be fitted so that the safety notch, which stops it sliding out, faces the inside of the oven.
- Page 28 Oven Doors Removing the Oven Doors The oven door can easily be removed as follows: • Open the door to the full extent (fig. 33a). • Open the lever “A” completely on the left and right hinges (fig. 33b). • Hold the door as shown in fig.
-
Page 29: For The Installer
For the Installer Location The appliance may be installed in a kitchen, Kitchen/diner or a bed sitting room, but not in a room or space containing a bath or a shower. The appliance must not be installed in a bed-sitting room of less than 20m The appliance is designed and approved for domestic use only and should not be installed in a commercial , semi commercial or communal environment. -
Page 30: Assembling The Backguard
Assembling the Backguard • Remove the two spacers “A” and the screw “B” from the rear of the cooktop. • Assemble the backguard as shown in figure 35 and fix it by screwing the central screw “B” and the spacers “A”. -
Page 31: Fitting The Adjustable Feet
Fitting the Adjustable Feet • The adjustable feet must be fitted to the base of the cooker before use. • Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet. -
Page 32: Levelling The Cooker
Warning To move the cooker always ensure two people carry out this manoeuvre to prevent damage to the ap- pliance (fig. 38). Warning Be careful: do not lift the cooker by the door handles (fig. 39). Warning When moving cooker to its final position DO NOT DRAG (fig. -
Page 33: Stability Bracket
Stability Bracket We recommend a stability bracket is fitted to the cooker. The type shown in fig. 42 can be purchased from most plumbers merchants and do it yourself (D.I.Y.) shops. Existing slot in rear of cooker Brackets Dotted line showing the position of cooker when xed Fig. -
Page 34: Provision For Ventilation
Provision for Ventilation • The appliance should be installed into a room or space with an air supply in accordance with BS 5440-2: 2000. • For rooms with a volume of less than 5 m - permanent ventilation of 100 cm free area will be required. -
Page 35: Gas Installation
Gas Installation Important Note This appliance is supplied for use on NATURAL GAS or LPG (check the gas regulation label attached on the appliance). • Appliances supplied for use on NATURAL GAS: they are adjusted for this gas only and cannot be used on any other gas (LPG) without modification. -
Page 36: Gas Connection
Gas Connection The installation of the gas appliance to Natural Gas or LP Gas must be carried out by a suitably qualified and registered installer. Installers shall take due account of the provisions of the relevant British Standards Code of Practice, the Gas Safety Regulations and the Building Standards (Scotland) (Consolidation) Regulations issued by the Scottish Development Department. - Page 37 Gas Connection Cat: II 2H3+ The gas supply must use the nearest gas inlet pipe which is located at the left or the right hand side at the rear of the appliance (fig. 45). The hose should also be connected in such a way that it does not touch the floor. To screw the connecting tube operate with two spanners (fig.
- Page 38 Important Prescriptions for Gas Connection Rear wall Suggested area for gas mains connection Fig. 46...
-
Page 39: Conversion To Natural Gas Or To Lpg
Conversion to Natural Gas or to LPG Injectors Replacement of Top Burners Every cooker is provided with a set of injectors for the various types of gas. Injectors not supplied can be obtained from the After-Sales Service. Select the injectors to be replaced according to the table at page 47. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector. -
Page 40: Lubrication Of The Gas Taps
Table for the Choice of the Injectors Cat: II 2H3+ G30 - 28-30 mbar G20 - 20 mbar G31 - 37 mbar Nominal Reduced Burners Power Power Tube ring Tube ring Ø Injector Ø Injector opening opening 1/100 mm 1/100 mm [mm] [mm] Auxiliary (A) - Page 41 OPERATIONS TO BE EXECUTED FOR THE REPLACEMENT OF THE INJECTORS OF THE OVEN AND GRILL BURNERS Some models are provided with a set of injectors for the various types of gas. If the injectors are not supplied they can be obtained from the “Service Centre”. Select the injectors to be replaced according to the “Table for the choice of the injectors”...
- Page 42 GRILL BURNER Unscrew and remove the burner securing screw “A” (fig. 52). • Withdraw the burner as shown in figure 53. Take care not to damage the safety valve probe • and the electric ignition electrode. Using a 7 mm box spanner, unscrew the injector (indicated by the arrow in fig. 53) and replace •...
- Page 43 REGULATION OF AIR SUPPLY TO OVEN AND GRILL BURNERS To regulate the air supply it is necessary to remove the burners from their housings (figs. 51 - 53). Using a cross-head screwdriver, slacken the screws “A” securing the air flow regulation collar •...
-
Page 44: Regulating Of The Oven Minimum
Regulating of the oven minimum Considering that in the minimum position the flame must have a length of about 4 mm and must remain lit even with a rapid shift from the maximum position to that of minimum. To be effected only for the oven burner (as the grill burner only has a fixed input) operating on the thermostat as follows: •... - Page 45 IMPORTANT: The cooker must be installed in accordance with the manufacturer’s instructions. Incor- rect installation, for which the manufacturer accepts no responsibility, may cause damage to persons, animals and things. The connection of the appliance to earth is mandatory. The manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition.
-
Page 46: Electrical Installation
Electrical Installation WARNING! Electricity can be extremely dangerous. This appliance must be earthed. Electrical Feeder Cable Connection To connect the supply cable: • Remove the screw securing the cover “A” on the rear of the cooker (fig. 57). • Unscrew cable clamp “D” (Fig. 58). •... -
Page 47: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: Model type, make and model –... - Page 48 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
