- Page 1 NSX-AV840 COMPACT DISC STEREO SYSTEM • BASIC TAPE MECHANISM 2ZM-3MK2 PR7NF • TYPE • BASIC CD MECHANISM 4ZG-1 Z3RNDSHM SIMPLE MANUAL • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No 09–997–408–9T2...
- Page 2 ELECTRICAL PARTS LIST-1/10 NOTE: The characters in the suffix column indicate the part usage. EZSE ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 CAP,E 100-16 ....87-010-178-080 CHIP CAP 1000P ....87-010-186-080 CAP,CHIP 4700P ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....
- Page 3 ELECTRICAL PARTS LIST-2/10 87-012-157-080 C-CAP,S 330P-50 CH ....87-010-408-040 CAP,E 47-50 SME ....87-010-421-040 CAP,E 4.7-50 5L ....87-010-421-040 CAP,E 4.7-50 5L ....87-012-369-080 C-CAP,S 0.047-50F ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....87-010-196-080 CHIP CAPACITOR,0.1-25 ....
- Page 4 ELECTRICAL PARTS LIST-3/10 LED 440 87-A40-608-040 LED,SLV-312VC RED ....LED 444 87-A40-609-040 LED,SLV-312MC PG ....LED 445 87-A40-609-040 LED,SLV-312MC PG ....LED 448 87-A40-609-040 LED,SLV-312MC PG ....LED 447 87-A40-609-040 LED,SLV-312MC PG ....LED 446 87-A40-609-040 LED,SLV-312MC PG ....LED 443 87-A40-609-040 LED,SLV-312MC PG ....
- Page 5 ELECTRICAL PARTS LIST-4/10 87-010-318-080 C-CAP,S 47P-50 CH A....87-010-318-080 C-CAP,S 47P-50 CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-145-080 CAP, CHIP S 270P CH A....87-012-157-080 C-CAP,S 330P-50 CH A....87-012-157-080 C-CAP,S 330P-50 CH ....87-012-157-080 C-CAP,S 330P-50 CH ....
- Page 6 ELECTRICAL PARTS LIST-5/10 SFR 305 87-A90-433-080 SFR,50K H NVZ6TLTA A....SFR 306 87-A90-433-080 SFR,50K H NVZ6TLTA A....SFR 303 87-A90-557-080 SFR,33K H HOKU A....SFR 304 87-A90-557-080 SFR,33K H HOKU A....SFR 301 87-A90-557-080 SFR,33K H HOKU A....SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA A....
-
Page 7: Electrical Parts List-6
ELECTRICAL PARTS LIST-6/10 87-A30-075-080 C-TR,2SA1235F ....87-A30-075-080 C-TR,2SA1235F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-234-080 TR,CSC4115BC A....87-A30-075-080 C-TR,2SA1235F A....87-A30-075-080 C-TR,2SA1235F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-026-609-080 TR,KTA1266GR A....87-A30-076-080 C-TR,2SC3052F A....87-A00-261-080 RES,M/F 0.56-1W J .... - Page 8 ELECTRICAL PARTS LIST-7/10 87-A91-042-080 C-THMS,100K 55001 ....87-010-176-080 C-CAP,S 680P-50 SL ....87-010-176-080 C-CAP,S 680P-50 SL ....87-010-402-080 CAP, ELECT 2.2-50V A....87-010-402-080 CAP, ELECT 2.2-50V A....87-010-993-080 C-CAP,S 0.056-25 B A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....
-
Page 9: Electrical Parts List-8
ELECTRICAL PARTS LIST-8/10 87-010-993-080 C-CAP,S 0.056-25 B A....87-099-564-010 CONN,4P TUC-P4P-B1 A....87-070-136-080 ZENER,MTZJ5.1B A....87-A40-442-080 ZENER,MTZJ9.1A A....87-A21-097-040 C-IC,M62463AFP A....87-A21-015-040 C-IC,M62491FP A....87-A60-746-010 JACK,PIN 6P R/W,R/W, O/B A....87-003-383-010 COIL,1UH-S A....87-A30-086-070 C-TR,CSD1306E A....87-022-214-080 C-RES S100K-1/10WF A....87-010-195-080 C-CAP,S 0.068-25 F A.... - Page 10 ELECTRICAL PARTS LIST-9/10 87-010-408-080 CAP, ELECT 47-50V ....87-010-408-080 CAP, ELECT 47-50V ....87-010-408-080 CAP, ELECT 47-50V A....87-010-408-080 CAP, ELECT 47-50V A....87-010-260-080 CAP, ELECT 47-25V A....87-010-260-080 CAP, ELECT 47-25V A....87-010-322-080 C-CAP,S 100P-50 CH A....87-012-368-080 C-CAP,S 0.1-50 F A....
- Page 11 ELECTRICAL PARTS LIST-10/10 87-A30-190-080 TR,CC5551 A....87-A30-097-010 TR,FN 1016 A....87-A30-098-010 TR,FP 1016 A....87-A30-098-010 TR,FP 1016 A....87-A30-137-010 TR,2SD2494 ....87-A30-138-010 TR,2SB1625 ....87-A30-138-010 TR,2SB1625 ....87-A30-190-080 TR,CC5551 A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....
- Page 12 ELECTRICAL MAIN PARTS LIST - 1/3 (TUNER: ZZA-1) NOTE: The characters in the suffix column indicate the part usage. ZRDS ....XX........F....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-381-080 0E CAP, ELECT 330-16V ABCDEFGH.... 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGH.... 87-010-260-080 0E CAP, ELECT 47-25V ABCD.FGH....
- Page 13 ELECTRICAL MAIN PARTS LIST - 2/3 (TUNER: ZZA-1) 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGH.... 87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-012-275-080 0E C-CAP,U 1200P-50 B ABCDEFGH.... 87-012-275-080 0E C-CAP,U 1200P-50 B ABCDEFGH.... 87-012-286-080 0E CAP, U 0.01-25 ABCDEFGH....
- Page 14 ELECTRICAL MAIN PARTS LIST - 3/3 (TUNER: ZZA-1) 87-A50-173-010 0E COIL,OSC SW-N(COI) ..E....87-A50-432-010 0E COIL,1MH K CW ..E....87-A50-430-010 0E COIL,ANT MW(3BSW) ..E....87-A50-431-010 0E COIL,OSC MW(3BSW) ..E....87-NF4-650-010 1D COIL,AM PACK 4N(TOK) A....87-NF4-651-010 1C COIL,AM PACK2N(TOM) ....88-NF8-625-110 1D COIL,AM PACK3N(TOK) ....
- Page 15 MECHANICAL PARTS LIST-1/1 NOTE: The characters in the suffix column indicate the part usage. EZSE ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-NF5-004-010 CABI,STEEL A....8Z-NF6-003-010 BOX,CASS 1 U ....8Z-NF6-004-010 BOX,CASS 2 U ....8Z-NF6-005-010 PANEL,TRAY U A....8Z-NF6-008-010 PANEL,FUN ....
- Page 16 ACCESSORIES / PACKAGE LIST-1/1 NOTE: The characters in the suffix column indicate the part usage. EZSE ....XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-NFT-903-010 IB,U(ESF)M ....8Z-NFT-906-010 IB,EZ(9L)E A....87-043-106-010 WIRE, FM ANT (Z) A....87-043-115-010 ANT,FEEDER FM ....87-A90-030-010 ANT,LOOP AM-NC C A....
- Page 17 SCHEMATIC DIAGRAM _ 1 (MAIN)
- Page 18 SCHEMATIC DIAGRAM _ 2 (FRONT)
- Page 19 SCHEMATIC DIAGRAM _ 3 (PRO-LOGIC)
- Page 20 SCHEMATIC DIAGRAM _ 4 (AMP)
- Page 21 SCHEMATIC DIAGRAM _ 5 (DECK)
- Page 22 SCHEMATIC DIAGRAM _ 6 (TUNER)
- Page 23 SCHEMATIC DIAGRAM _ 7 (PT)
- Page 24 9820527 Tokyo Japan Printed in Singapore...
