Summary of Contents for Jonsered CS 2117 EL
- Page 1 GB Operator’s Manual 115 44 51-26...
- Page 2 Original instructions...
-
Page 3: Table Of Contents
EC DECLARATION OF CONFORMITY Husqvarna AB, 561 82, Huskvarna, Sweden, declare under our sole responsibility that the product(s); Category.......... Electric chainsaw Type(s)..........Jonsered CS2117 EL & CS2121 EL Identifi cation of Series..... See Product Rating Label Year of Construction......See Product Rating Label conforms to the essential requirements &... -
Page 4: Symbols
SYMBOLS USED IN OPERATOR’S MANUAL: Always disconnect power before performing Visual inspection. cleaning or maintenance work. Do not use a coiled extension cord. mm ² Minimum wire cross-section: Always use approved safety gloves. Maximum cable length: 30 m Voltage: 230 V Clean your chain saw regularly. - Page 5 IMPORTANT! READ BEFORE USING CHAIN SAW e) When operating a power tool outdoors, use an extension of inattention while operating chain saws may cause entanglement cord suitable for outdoor use. Use of a cord suitable for outdoor of your clothing or body with the saw chain. use reduces the risk of electric shock.
-
Page 6: Technical Specifi Cations
TECHNICAL SPECIFICATIONS Model CS2117 EL CS2121 EL Rated power Slip clutch Electronic start control Electronic speed control Electronic overload protection Weight Without guide bar and chain With 14” guide bar and chain Chain lubrication Oil tank volume litres Oil consumption approx. litres 0.1/20 min. -
Page 7: Chain Saw Parts
CHAIN SAW PARTS 1. Rear handle 2. Power trigger lockout 11. Chain 3. Front handle 12. Guide bar 4. Serial No. plate 18. Chain catcher - defl ects chain in case 13. Chain brake release button 5. Chain tensioner chain breaks or derails 14. - Page 8 • See to it that others keep their distance as long as the • Ensure that you can move and stand safely at all times. chain is in motion. Keep onlookers, children and animals Watch out for roots, stones, branches, holes, mounds away from the work area.
-
Page 9: Starting And Stopping
STARTING AND STOPPING CAUTION! • Make certain at all times that your footing is secure and that the chain touches nothing but the wood you are cutting. • Keep bystanders away from your work area. Starting • Grip the front handle fi rmly with your left hand. •... -
Page 10: Kickback Prevention
DANGER! Kickbacks occur suddenly and without warning. A kickback may be violent enough to throw a chainsaw back at the user. A running chain can infl ict severe and even fatal injury. It is imperative for users to be familiar with the causes of kickbacks in order to exercise the proper care and use working techniques to prevent kickback. -
Page 11: Chain Brake With Kickback Guard
CHAIN BRAKE WITH KICKBACK GUARD Your chain saw is equipped with a chain brake designed to stop • The chain brake may be activated manually or by the force of the chain instantaneously in the event of a kickback. A chain brake inertia depending on the strength of the kickback and the po- can reduce the risk of accident, but only the operator can prevent sition of the saw in relation to the object which made contact... -
Page 12: Mounting Guide Bar And Adjusting Chain
MOUNTING GUIDE BAR AND ADJUSTING CHAIN CAUTION! Always disconnect power before performing cleaning or maintenance work. CAUTION! A loose chain can jump out of its groove during operation and cause serious or even fatal injury. 6. Replace the chain drive cover and screw the mounting nut hand tight. -
Page 13: Chain Catcher
CHAIN CATCHER The chain catcher is designed to catch a chain which breaks or jumps out of its groove. This problem will generally be avoided, however, if the chain is tensioned properly (see chapter on «Mounting guide bar and adjusting chain» page 10) and the chain and guide bar properly maintained. -
Page 14: Chain And Guide Bar Lubrication
CHAIN AND GUIDE BAR LUBRICATION CAUTION! Inadequate lubrication can lead to cutting equipment failure and serious or fatal personal injury. Chain oil • A full reservoir is suffi cient for 20 minutes of steady use. • The chain and bar are lubricated by an automatic oiling system. •... -
Page 15: Filing Chain
FILING CHAIN See «Technical Specifi cations» for the details which apply to General instructions regarding cutters your chain. It is very diffi cult to fi le a chain saw correctly with- • Never cut wood using a dull chain. Having to press hard is a out the proper aids. -
Page 16: Crosscutting
CROSSCUTTING • Cutting a log supported at one end. The log is more than likely CAUTION! to splinter if cut straight through from the top down. If the chain becomes stuck in the kerf, STOP THE SAW! Do not attempt to jerk the saw free. You could be harmed by the chain if the saw suddenly comes loose. -
Page 17: Danger Zone
Danger zone danger zone surrounds tree distance Notch depth should be around 1/4 of the 2 1/2 times the height of the tree. See to it that no one is standing diameter of the tree and the angle should within this zone while you are felling the tree. be around 45°. - Page 20 Trøskenveien 36 P.O.B. 10 N - 1708 Sarpsborg Norway 115 44 51-26, rev. 2 ´®z+VM,¶6Z¨ ´®z+VM,¶6Z¨ 2012W40...
