10. Remove the knob from the pin. Make sure that the collar
and the spring are on the pin as shown. Insert the pin
into the Latch Housing (30), and tighten the knob back
onto the pin.
11. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place; the large allen wrench is used to adjust the
walking belt (see page 20). To protect the floor or carpet, place a mat under the treadmill.
10
Knob
10
Spring
Pin
30
Collar
