- Page 1 Operation/Reference Guide AMXUSBLAN USB LAN Driver (v2.2.1.5 or higher) D o c u m e n t I D : 0 3 3 - 0 0 4 - 2 9 9 5 T o u c h P a n e l I n t e r f a c e L a s t R e v i s e d : 9 / 0 7 / 2 0 0 6...
- Page 2 RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Dealer for a third party.
- Page 3 AMX's entire liability and Licensee's exclusive remedy shall be repair or replacement of the AMX Software that does not meet AMX's Limited Warranty and which is returned to AMX. This Limited Warranty is void if failure of the AMX Software has resulted from accident, abuse, or misapplication.
-
Page 5: Table Of Contents
Installing the AMX USBLAN Software Driver ...3 Connecting a Touch Panel via USB ...9 Overview ... 9 To View Your Current AMX USB Device Connections ... 11 Uninstalling the AMXUSBLAN Driver ...13 Overview ... 13 To Remove Panel/Driver Associations ... 13 Troubleshooting ...15... - Page 6 Table of Contents AMXUSBLAN...
-
Page 7: Amxusblan Driver
NetLinx Studio and/or TPDesign4 software applications. This driver is scheduled to be packaged with the next release of the aforementioned AMX software applications; but at this time, it is being distributed as a stand-alone executable for use with all current USB-compatible Modero panels. - Page 8 AMXUSBLAN Driver AMXUSBLAN...
-
Page 9: Installing The Amx Usblan Software Driver
Installing the AMX USBLAN Software Driver 1. Navigate to www.amx.com > Tech Center > Application Files and download the executable (EXE) file. 2. Launch the AMX USBLAN v5.02.08.exe file by double-clicking the file. 3. The driver will prompt for a language. - Page 10 Installing the AMX USBLAN Software Driver FIG. 3 Choose Install Location dialog The default is C:\PROGRAM FILES\AMX\USBLAN. If a different folder is desired select Browse and choose the location where you would like the files installed. It is recommended that the default location be used for this installation.
- Page 11 If you are prompted to replace AXBLAN.INF select Yes (FIG. 5). FIG. 5 Replace AXBLAN.INF 8. When prompted to install the "Checked driver" select No (FIG. 6). FIG. 6 Do Not Install The "Checked Driver" AMXUSBLAN Installing the AMX USBLAN Software Driver...
- Page 12 Installing the AMX USBLAN Software Driver 9. Once the driver installation begins it may encounter cases where a previous version of some files already exist. This can occur if you have previously installed the latest release versions of NetLinx Studio v2.3 and TPDesign4 v2.4.
- Page 13 This option is not displayed on Windows 2000 machines. Click the NEXT button when done. 12. At the end of installation select the Finish button (FIG. 10). FIG. 10 Select The Finish Button AMXUSBLAN Installing the AMX USBLAN Software Driver...
- Page 14 Installing the AMX USBLAN Software Driver AMXUSBLAN...
-
Page 15: Connecting A Touch Panel Via Usb
Connecting a Touch Panel via USB Overview The first time each AMX touch panel is connected to the PC via USB it will be detected as a new hardware device and the USBLAN driver will be associated with it. Each time thereafter the panel is "recognized"... - Page 16 Each time a different touch panel is connected to the computer, the previous procedures will need to be repeated. The previous version of the AMX USBLAN driver (used for the MVP and CV7 panels) showed a USB connection icon in the system tray when a panel was connected. The new version of the driver does not do this.
-
Page 17: To View Your Current Amx Usb Device Connections
In the System Properties dialog, click the Hardware tab and select Device Manager. In the Device Manager dialog, the AMX USBLAN device appears under Network Adapters and has a name such as AMX USB LAN LINK #2 (FIG. 14) . FIG. 14 Device Manager dialog The number changes depending on which panel is currently connected. - Page 18 Connecting a Touch Panel via USB AMXUSBLAN...
-
Page 19: Uninstalling The Amxusblan Driver
1. Navigate to Start > Control Panel > System. 2. In the System Properties dialog, click the Hardware tab and select the Device Manager. In Device Manager, all AMX USBLAN devices should appear under Network Adapters and have a name such as AMX USB LAN LINK #2. - Page 20 See the Connecting a Touch Panel via USB section on page 9 for details. It may be necessary to perform this uninstall procedure for every AMX USB device in the list if you are unsure which one you need to remove.
-
Page 21: Troubleshooting
3. Click the plus-sign next to Network Adapters to expand the view. You should see an entry named "AMX USB LAN LINK #3" in the list of Network Adapters. 4. Double-click on AMX USB LAN LINK #3 to open the Properties dialog for this driver. 5. Open the Driver tab and check the Driver Version. - Page 22 Troubleshooting AMXUSBLAN...
- Page 23 Troubleshooting AMXUSBLAN...
- Page 24 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...
