Model No. IMSB62820
IMSG62820
Serial No.
The serial number is on a plastic sign
inside the spa behind the access
panel. Write the serial number in the
space above for reference.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our customer
hot line will provide immediate
assistance, free of charge.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
®
Next page ->

Summary of Contents

  • Page 1

    Model No. IMSB62820 IMSG62820 Serial No. The serial number is on a plastic sign inside the spa behind the access panel. Write the serial number in the space above for reference. Access Panel QUESTIONS? If you have questions, or if there...

  • Page 2: Table Of Contents

    Table of Contents Posting the Warning Sign ..............2 Important Safety Instructions .

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions.

  • Page 4

    The effects of hyperthermia include failure to per- ceive heat; failure to recognize the need to exit the spa or hot tub; unawareness of impending hazard; fetal damage in pregnant women; physical inability to exit the spa or hot tub and unconsciousness resulting in danger of drowning.

  • Page 5

    35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.

  • Page 6: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is IMSB62820 or IMSG62820. The serial number can be found on a decal attached to the frame inside the spa (see the front cover of this user’s manual).

  • Page 7: Choosing A Location For The Hydrotherapy Spa

    Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.

  • Page 8: Assembly

    Assembly Before beginning assembly, carefully read the following information and instructions: • Place all parts in a cleared area and remove the packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is completed and the spa is operating. •...

  • Page 9

    3. The hydrotherapy spa operates on a 240-volt power source and must be wired directly to a 30 amp Ground Fault Circuit Interrupter (GFCI) installed in your home. This procedure must be performed by a qualified, licensed electrician. A wiring diagram is found on the inside of the electronics package for reference. Under no circumstances should the spa be wired by someone other than a qualified electrician.

  • Page 10: Using The Hydrotherapy Spa

    Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat six adults. The spa holds 300 gallons of water and offers a heat- ing system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. Follow the guidelines below to use and maintain the spa for your long-term enjoyment.

  • Page 11: Spa Shell Diagram

    Spa Shell Diagram A. The filter can be removed for cleaning or replace- ment (see CHECKING AND CLEANING THE FILTER CARTRIDGE on page 13). B. The underwater light can be used for night opera- tion (see USING THE CONTROLS on page 12). The spa includes both red and blue covers for the light.

  • Page 12: Using The Controls

    Using the Controls Air Controls Display Pump Light Temp Button Button Refer to the diagram above. The function of each control is explained below: Temperature Buttons: Control the temperature setting of the water. The temperature can be set from 80°F to 104°F.

  • Page 13: Maintenance

    Maintenance The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. MAINTENANCE SCHEDULE Daily • Check the water level and refill the spa to the level shown in step 4 on page 9. •...

  • Page 14

    5. Keep containers closed tightly when not in use. 6. Never add water to the chemicals—always add the chemicals to the water as directed. 7. Always store chemicals in a cool, dry place. MAINTAINING THE PROPER PH BALANCE The pH factor is a measure of the relative acidity or alkalinity in the water, and is measured on a scale of 1 to 14.

  • Page 15

    To drain the hydrotherapy spa, follow the steps below: 1. Using the console, adjust the temperature to the lowest setting. 2. Shut off the power to the spa, at the circuit breaker or GFCI. 3. Remove the pump access panel from the spa. 4.

  • Page 16: Troubleshooting

    Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1.

  • Page 17

    10. SYMPTOM: THE SPA JET UNIT CONTINUES TO RUN AFTER IT HAS BEEN SHUT OFF a. To turn the main jets off, press pump button once or twice. Note: If the actual spa water temperature is below the set temperature, or if the spa is running a filter cycle, the heater pump/motor will not shut off.

  • Page 18: Part List

    PART LIST — Model Nos. IMSB62820, IMSG62820 Key No. Qty. Description Thermometer Fitting 4-wire Power Cord Filter Cover Corner Panel Filter Cartridge #10 x 2” Sheet Metal Screw Blue Light Cover Red Light Cover #10 x 1 1/2” Sheet Metal Screw...

  • Page 19: Exploded Drawing

    EXPLODED DRAWING — Model Nos. IMSB62820, IMSG62820 R0602A...

  • Page 20

    Friday, 8 a.m. until 5 p.m. Central Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • The MODEL NUMBER of the product (IMSB62820 or IMSG62820) • The NAME of the product (RENEW 628 hydrotherapy spa) •...
