Model No. IMSB53940
Serial No.
The serial number is on a sign
behind the access panel. Write the
serial number in the space above.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our customer
hot line will provide immediate
assistance, free of charge.
1-877-897-7493
CUSTOMER HOT LINE:
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
V
USERʼS MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Image PARADISE IMSB53940
Summary of Contents for Image PARADISE IMSB53940
- Page 1 USERʼS MANUAL Model No. IMSB53940 Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a replacement sign. Post the sign as described above. IMAGE is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10. - Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
- Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
-
Page 6: Before You Begin
IMSB53940. The serial number can be found on a powerful massage action further eases tension and decal on the access panel inside the spa (see the front stress throughout the body. The IMAGE PARADISE cover of this manual). hydrotherapy spa gives you the specialized treatment you need to feel your best. -
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa. -
Page 8: Assembly
Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • One phillips screwdriver • Place all parts in a cleared area and remove the packing materials from the spa shell. Do not dis- A wire connector is provided on the electronics pose of the packing materials until assembly is pack of the spa to connect a minimum No. - Page 9 3. Insert the Pillow (38) into the lounge seat recepta- cle. Note: The Pillow can be rotated 180º and reat- tached in a high or low position. 4. The hydrotherapy spa operates on a 240 volt power source and must be wired directly to a 240 volt Ground Fault Circuit Interrupter (GFCI) installed in your home.
-
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat seven 4. Turn the power on. The spa will begin an auto- adults. The spa holds approximately 375 gallons of matic priming sequence. water and offers a heating system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. - Page 11 8. After one minute, the current temperature of the Once you have tested the GFCI, verify that water is water will be displayed. Push the temperature up flowing from the jets. Set the air controls to the lowest or down button to set the temperature of the setting (see USING THE CONTROLS on page 13).
-
Page 12: Jet Layout Diagram
Jet Layout Diagram A. The underwater light can be used for night opera- G. The two neck jets can be adjusted to spray sooth- tion (see USING THE CONTROLS on page 13). ing water on your neck. The spa includes both red and blue covers for the H. -
Page 13: Using The Controls
Using the Controls Air Controls 1, 2, and 3 Air Control 4 Blower Mode Button Button Display Pump Pump Light Temperature Button 1 Button 2 Button Buttons two minutes. “Std” displays momentarily when stan- dard mode is selected. • Economy Mode heats the spa to the set tempera- ture only during the filter cycles. - Page 14 The Light Button controls the light. To turn the light matically display the last measured water tempera- on, press the light button. To turn the light off, press ture. the light button again. If the temperature sensors detect a drop below 40°F, The Temperature Buttons control the temperature set- then pump 1 (and the heater if necessary will auto- ting of the water.
-
Page 15: Maintenance
Maintenance MAINTAINING THE SPA COVER The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover. - Page 16 WATER CHEMISTRY To maintain the proper pH level, test the pH of the water regularly. To test the water, purchase a pH test Maintaining the pH level of the water is very important kit at a pool and spa supply store. The pH reading to the operation of the spa.
- Page 17 ATTACHING AND REMOVING THE ACCESS PANEL To drain the hydrotherapy spa, follow the steps below: Turn off the spa power. To remove the indicated 1. Using the console, adjust the temperature to the Access Panel (25), remove the eight #10 x 2” lowest setting.
- Page 18 DRAINING THE PUMPS REPLACING THE LIGHT BULB After the hydrotherapy spa is drained, the jet pumps If the underwater light burns out, you will need to should also be drained if the spa will be stored for remove the access panel to replace it (see ATTACHING more than thirty days or if it may be exposed to freez- AND REMOVING THE ACCESS PANEL on page 17).
-
Page 19: Troubleshooting
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1. - Page 20 9. SYMPTOM: THE WATER LEVEL DROPS 11. SYMPTOM: THE CONSOLE DISPLAYS “--,” “OHH,” “ICE,” “SnA,” “SnB,” “SnS,” “HFL,” “LF,” “dr,” “OHS,” or “drY” a. A clamp or seal inside the pump compartment may be loose. Check inside the pump compart- ment for excess water and watch the pump unit a.
- Page 21 Notes...
-
Page 22: Part List
Part List—Model No. IMSB53940 R0204A Key No. Qty. Description Key No. Qty. Description Console With Overlay 1/4” Washer 3-wire Power Cord Face Plate Filter Cover Panel Rubber Washer Heater Collar With Screw Filter Cartridge Volcano Jet Rubber Isolator Drain Plug Blue Light Cover #10 x 2”... -
Page 23: Exploded Drawing
Exploded Drawing—Model No. IMSB53940 R0204A... -
Page 24: Ordering Replacement Parts
• The MODEL NUMBER of the product (IMSB53940) • The NAME of the product (IMAGE PARADISE hydrotherapy spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and the EXPLODED DRAWING on...
