Model No. IMHS81590
Serial No.
Write the serial number in the
space above for reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Save this manual for reference.
USERÕS MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
¨
Patent Pending

Advertisement

Table of Contents
loading

Related Manuals for Image IMHS81590

Summary of Contents for Image IMHS81590

  • Page 1 Model No. IMHS81590 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    Table of Contents WARNING DECAL PLACEMENT ............2 IMPORTANT SAFETY INSTRUCTIONS .

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the following important precautions before using the RENEW 815. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the RENEW 815 are ade- quately informed of all precautions.

  • Page 4: Save These Instructions

    ation. If the spa jet unit continues to run after the ÒtestÓ button is pressed, then the GFCI is damaged. Do not use the RENEW 815 until the GFCI has been repaired or replaced by a qualified electrician. 20. Keep all electrical appliances such as radios, telephones, televisions, and lights at least five feet (1.52 meters) away from the water.

  • Page 5: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is IMHS81590. The serial number can be found on a decal attached to spa jet unit (see the front cover of this manual).

  • Page 6: Choosing A Location For The Hydrotherapy Spa

    Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the RENEW 815. These factors vary depending on whether you use the RENEW 815 inside or outside. We have listed several factors you may wish to consider as you decide where you want to use the RENEW 815.

  • Page 7: Assembly

    Assembly Before beginning assembly, carefully read the following information and instructions: ¥ Place all parts in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed. 1. Before beginning assembly, be sure that you have read and understand the information in the box above and on the previous page.
  • Page 8 2. Orient the dry side jet pack (A) as shown and posi- tion it next to the three holes in the Inflatable Liner (29). Attach the Temperature Probe Assembly (30) to the small hole in the Inflatable Liner (29). To do this, place the Temperature Probe Gasket (46) over the Probe connector threads.
  • Page 9 5. Attach the nozzle on the air pump to the valve on the floor of the Inflatable Liner (29). Use the air pump to fill the bottom of the Inflatable Liner with air. Be extremely careful not to puncture the Liner.

  • Page 10: Using The Hydrotherapy Spa

    Using the Hydrotherapy Spa The RENEW 815 is designed for up to three adults. The RENEW 815 holds 268 gallons of water and offers an automatic, programmable heating (70¡F to 104¡F) and filtration system. The guidelines below explain how to properly use the RENEW 815.
  • Page 11 in the spa. Allow the water to circulate for five min- utes. You should now test the pH level of the water. Use the included test strips to check the pH of the water. Refer to the instructions on the test strip pack- aging to see how to use the test strips.
  • Page 12 The spa jet unit features an automatic filter cycle and freeze protection. If the spa jet unit has not been operated for three hours, the pump will begin circulat- ing the water for twenty minutes to filter any impuri- ties. Also, if the water temperature falls below 40¡F, the pump will begin circulating and heating the water to prevent the water from freezing.

  • Page 13: Maintenance

    Maintenance CLEANING THE INFLATABLE SPA LINER The liner should be cleaned with a mild soap solution. Do not use solvents. The liner should always be clean and dry before being moved or stored. CHECKING AND CLEANING THE FILTER The filter should be checked periodically for build-up of dirt and oil.

  • Page 14: Trouble-Shooting

    Trouble-shooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1.
  • Page 15 Note: If the unit is to be kept outdoors in cold weather, you must allow the spa to maintain a safe temperature IMAGE ¨ by running in automatic mode. Allowing the spa jet unit to freeze will damage the unit. If...

  • Page 16: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: 1. The MODEL NUMBER of the product (IMHS81590) 2. The NAME of the product (IMAGE 3.
  • Page 17 Remove this Part List/Exploded Drawing from the manual. Save this Part List/Exploded Drawing for future reference. Protect Your Spa Investment! Based on customer input, we have determined the key areas you need to be aware of to get maximum enjoyment from your spa. Please review this sum- mary carefully.
  • Page 18 PART LISTÑModel No. IMHS81590 Key No. Qty. Description Pressure Switch Pump Frame Temperature Probe High Limit Inflatable Cover #8 x 1/2Ó Screw Cover Panel Overlay Filter Cap Spa Surround Fixed Jet Spa Cover Heater Tail Piece Gasket Filter Housing Assembly...
