Samsung HW-E550 User Manual
Crystal surround air track
Hide thumbs
Also See for HW-E550:
- User manual (32 pages) ,
- User manual (62 pages) ,
- User manual (30 pages)
Table of Contents
Related Manuals for Samsung HW-E550
Summary of Contents for Samsung HW-E550
-
Page 1: User Manual
HW-E550 HW-E551 Crystal Surround Air Track (Active Speaker System) user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register... -
Page 2: License
Multi-function Remote Control The supplied remote control can be used to control the TV connected to this unit. (Works only for Samsung TVs) The remote control has a TV hotkey that enables you to perform various operations with the simple press of a button. -
Page 3: Safety Information
safety information SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of CAUTION electric shock or personal injury. -
Page 4: Precautions
PRECAUTIONS 68.6 mm 2.7 inch 99.1 mm 3.9 inch 3.9 inch 3.9 inch 99.1 mm 99.1 mm Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (76~102 mm). -
Page 5: Table Of Contents
contents FEATURES Features License SAFETY INFORMATION Safety warnings Precautions GETTING STARTED Before reading the user’s manual What’s included DESCRIPTIONS Front/Rear Panel Subwoofer Front/Rear Panel REMOTE CONTROL Tour of the remote control CONNECTIONS Air Track Installation Overview Connecting the Speakers (Type 3 and 4) Installing the Speakers on the Standing Table Installing the Speakers on the Stand Assembled Speaker Wall Mount... -
Page 6: Getting Started
2) If a problem occurs, check Troubleshooting. (See page 28) Copyright ©2012 Samsung Electronics Co.,Ltd. All rights reserved; no part or whole of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. -
Page 7: What's Included
WHAT’S INCLUDED Check for the supplied accessories shown below. POWER TV POWER SOUND SPEAKER SOURCE EFFECT SAT MUTE SMART 3D SOUND VOLUME VOLUME S/W LEVEL AUDIO SYNC REPEAT DIMMER AUTO POWER TV SOURCE TV INFO TV CH TV VOL TV VOL MUTE TV CH TV PRE-CH... -
Page 8: Descriptions
descriptions FRONT/REAR PANEL DISPLAY Displays the current mode. POWER SUPPLY Plug the power supply cable into the AC wall outlet. JACK VOLUME BUTTON Controls the volume level. POWER BUTTON Turns the Crystal Surround Air Track on and off. ▪ When you turn on the power of this unit, there will be a 4 to 5 second delay before it produces sound. -
Page 9: Subwoofer Front/Rear Panel
SUBWOOFER FRONT/REAR PANEL DIGITAL AUDIO IN ID SET (OPTICAL) AUX IN HDMI IN 1 HDMI IN 2 HDMI OUT DIGITAL AUDIO IN ID SET (OPTICAL) AUX IN HDMI IN 1 HDMI IN 2 U S B HDMI OUT U S B DIGITAL AUDIO IN ID SET... -
Page 10: Remote Control
Mutes the sound from the TV. Press again to restore the sound to the previous volume level. ▪ SAT stands for Surround Air Track, which is a Samsung’s proprietary name. ▪ The remote control can operate TVs made by SAMSUNG only. ▪... -
Page 11: Connections
connections AIR TRACK INSTALLATION OVERVIEW You can choose installation from 4 typical setups. CONNECTING THE SPEAKERS (TYPE 3 AND 4) 1. Installation type 3 and 4 require cabling to the cradle’s terminal tabs. 2. Press down the terminal tab on the back/bottom of the cradle. 3. -
Page 12: Installing The Speakers On The Standing Table
connections INSTALLING THE SPEAKERS ON THE STANDING TABLE You can use the standing table to install this unit on a shelf. Make sure you place the unit on a flat surface. Connecting • To secure the MAIN SET with Standing Table, follow instructions below in order to assemble it. 1. -
Page 13: Installing The Speakers On The Stand
INSTALLING THE SPEAKERS ON THE STAND Separated speakers can be installed on your desired spot individually. Connecting • Check both MAIN SET (RIGHT), speaker (LEFT) speaker units. 1. Check pairs of separated MAIN SET A, B and cradles N, O/ J. 2. -
Page 14: Assembled Speaker Wall Mount
connections ASSEMBLED SPEAKER WALL MOUNT You can use the wall mount bracket to mount this unit on a wall. Installation Precautions • Install on a vertical wall only. • For the installation, avoid a location with high temperature or humidity, or wall that cannot sustain the weight of the set. -
Page 15: Separated Speaker Wall Mount
5. This is the completion of the suggested wall mount installation. 2 inches (5 cm) or more ▪ Do not hang onto the installed unit and avoid any impact to the unit. ▪ Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may cause an injury or damage to the product. -
Page 16: Connecting The Wireless Subwoofer
connections CONNECTING THE WIRELESS SUBWOOFER DIGITAL AUDIO IN The Subwoofer's linking ID is preset at the factory and the main unit and sub should link (connect wirelessly) ID SET (OPTICAL) AUX IN HDMI IN 1 HDMI IN 2 HDMI OUT U S B automatically when main unit is turned on. -
Page 17: Attaching The Toroidal Ferrite Core To The Power Cord Of The Subwoofer
ATTACHING THE TOROIDAL FERRITE CORE TO THE POWER CORD OF THE SUBWOOFER If you attach a Toroidal ferrite core to the power cord of the Subwoofer, it will help to prevent RF interference from radio signals. 1. Pull the fixing tab of the Toroidal ferrite core to open it. 2. -
Page 18: Connecting The Crystal Surround Air Track
CONNECTING THE CRYSTAL SURROUND AIR TRACK HDMI is a standard digital interface for connection to such devices as a TV, projector, DVD player, Blu-ray player, set top box and more. HDMI removes any loss of signal from analog conversion, enabling you to enjoy video and audio sound quality as it was originally created in the digital source. - Page 19 connections CONNECTING THE CRYSTAL SURROUND AIR TRACK This section explains two ways (digital and analog) of connecting the unit to a external devices. This unit is equipped with one optical digital jack and one audio analog jack for connecting a external devices. DIGITAL AUDIO IN ID SET...
-
Page 20: Functions
functions BASIC FUNCTIONS Turning the power on/off 1. Press the POWER ( ) button in the right corner. Press POWER on the remote control to turn on the power. 2. Press the POWER ( ) button in the right corner. Press POWER on the remote control again to turn off the power. -
Page 21: Advanced Functions
ADVANCED FUNCTIONS Using the input mode POWER TV POWER POWER TV POWER SOURCE SOUND SPEAKER EFFECT SAT MUTE SMART 3D SOUND You can select either D.IN, AUX, HDMI, BT input or USB input. VOLUME SOURCE SOUND SPEAKER VOLUME S/W LEVEL AUDIO SYNC EFFECT Press an appropriate button on the remote control to select a desired mode:... -
Page 22: To Connect The Air Track To A Bluetooth Device
To connect the Air Track to a Bluetooth device Check if the Bluetooth device supports the Bluetooth Space here compliant Connect stereo headset function. 1. Press the SAT SOURCE button on the remote control of AirTrack to display the BT message. •... - Page 23 To disconnect the Bluetooth device from Air Track You can disconnect the Bluetooth device from Air Track. For instructions, see the Bluetooth device's user manual. • Air Track will be disconnected. • When Air Track is disconnected from the Bluetooth device, Air Track will display DISCON on the front display.
-
Page 24: Muting The Sound
5. Do not connect multiple storage devices to the product via a multi- card reader. It may not operate properly. 6. Digital camera PTP protocols are not supported. 7. Do not remove the USB device while it is being read. 8. - Page 25 Using the 3D Depth Sound function POWER TV POWER POWER TV POWER SOURCE SOUND SPEAKER EFFECT SAT MUTE SMART 3D SOUND VOLUME SOURCE SOUND SPEAKER The 3D sound feature adds depth and spaciousness to the sound. VOLUME S/W LEVEL AUDIO SYNC EFFECT REPEAT DIMMER AUTO POWER...
- Page 26 POWER TV POWER SOURCE SOUND SPEAKER EFFECT SAT MUTE SMART 3D SOUND VOLUME Anynet+ is a function that enables you to control other Samsung Devices SOURCE SOUND SPEAKER VOLUME S/W LEVEL AUDIO SYNC EFFECT REPEAT DIMMER AUTO POWER with your Samsung TV's remote control.
-
Page 27: Software Upgrade
HDMI OUT singly and use them to upgrade the firmware one at a time. U S B Please visit Samsung.com or contact the Samsung call center to receive more information about downloading upgrades files. ▪ Insert a USB drive containing the firmware upgrade into the USB port on the back of the subwoofer. -
Page 28: Troubleshooting
troubleshooting Before requesting service, please check the following. Symptom Check Remedy The unit will not turn on. • Is the power cord plugged • Connect the power plug to into the outlet? the outlet. A function does not work when •... -
Page 29: Appendix
Engineering Society) guidelines. *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - For the power supply , refer to the label attached to the product. - Page 30 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Area Contact Centre Web Site ` Asia Pacific AUSTRALIA 1300 362 603 www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com...
