MPLS Model User Guide

Model Features

Modeler/Release 10.0
Multi-Protocol Label Switching (MPLS) is a multi-layer switching technology that
uses labels to determine how packets are forwarded through a network. The
first part of this document describes key features of the MPLS specialized model
and the second part focuses on procedures for configuring MPLS in your
network model.
This section contains a list of the main features available in the Multi-Protocol
Label Switching model:
• The MPLS model captures the following protocol behavior:
Table 6-1 MPLS Model Features
Feature
LSP (Label Switched Path) configuration
Differential Services (DiffServ)
Traffic Engineering
End of Table 6-1
6 MPLS Model User Guide
Description
• LSPs can be created manually or
automatically from traffic conversation
pairs.
• LSPs are easily reused in other scenarios
or projects by using the LSP import and
export features.
• Both dynamic and static LSPs are created
using the path object.
• DiffServ extensions, as defined in
RFC-2475, are provided.
• The model enables you to perform QoS
(quality of service) analyses by accounting
for different types of service.
Traffic engineered routes are computed
using Constrained Shortest Path First
(CSPF) with OSPF or IS-IS routing protocols.
SPM-6-1
