Read all instructions BEFORE assembly and USE of product.
KEEP INSTRUCTIONS FOR FUTURE USE.
baby trend
Model #7315 LX-PT
Sit N Stand LX
Tandem Stroller
with Car Seat Snap N Go Attachment System
US PATENT #5,664,795
Instruction Manual
09.06
Convenience through innovation and thoughtful design
Advertisement
Related Manuals for Baby Trend 7315 LX-PT
Summary of Contents for Baby Trend 7315 LX-PT
- Page 1 Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. baby trend Model #7315 LX-PT Sit N Stand LX Tandem Stroller with Car Seat Snap N Go Attachment System US PATENT #5,664,795 Instruction Manual 09.06 Convenience through innovation and thoughtful design...
- Page 2 Pacific Coast Time. Please do not return to the store as once it is returned it cannot be resold and the materials and energy used to make it are wasted. To contact us: Baby Trend, Inc. Parts Hotline: 1567 S. Campus Ave.
- Page 3 PARTS Parent Tray Front Wheels Child Tray Canopy Snap N Go Attachment Rear Wheels Foot Rest Stroller ASSEMBLING TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE ASSEMBLY 1. Remove stroller from box. The front wheels, rear wheels, child tray, and canopy need to be installed prior to use.
-
Page 4: To Secure Child
6. To attach the front child tray, push the tray onto the front frame tube, lining up the tray between the protruding rivet and the seat. Push backward on the latch until snapped into place. The protruding rivet on the outside Fig. - Page 5 TO USE JUMP SEAT 1. Have child sit on the jump seat facing backwards. Secure the seat belt, Fig. 11. which is attached to the back of the seat, around the child’s waist, and buckle to the crotch strap. See figure 11. 2. Adjust the seat belt to be snug around the child’s waist. 3.
-
Page 6: To Fold Stroller
BRAKES WARNING: Always set brakes when the stroller is not being pushed so that the Fig. 13. stroller will not roll away. Never leave stroller unattended on a hill or incline as the stroller may slide down the hill. 1. To engage brakes, apply light downward pressure to the brake lever Fig. - Page 7 TO UNFOLD STROLLER TO UNFOLD STROLLER Do Not allow children near stroller while unfolding. 1. Release the folding latch, which is located on the right side. See figure 2. Lift up on the stroller handle with both hands until the stroller frame is erect and locked in the open position. The stroller has spring-loaded latches on both sides of the frame. Test that both latches are fully engaged prior to placing your child in the stroller.
