Summary of Contents for IBM G41/G50
- Page 1 IBM G41/G50 Colour Monitor User’s Guide...
- Page 2 Notices References in this publication to IBM products, programs, or services do not imply that IBM intends to make these available in all countries in which IBM operates. Any reference to an IBM product, program or service is not intended to state or imply that only IBM’s product, program, or service may be used.
- Page 3 IBM product. To avoid electrical shock, always use the power cord and plug with a properly grounded outlet. IBM power cords used in the United States and Canada are listed by the Underwriters Laboratories (UL) and certified by the Canadian Standards Association (CSA).
-
Page 4: Table Of Contents
Contents Introduction ...2 Getting started ...3 Product Records ...4 General Specifications ...5 Installation ...6 Connecting the Monitor...7 Optimising performance ...8 Adjusting the image...10 Indicators...12 Disabling DDC ...14 Working with your Monitor ...15 Troubleshooting...16 Glossary...19 Specifications...20 Compliances...21 Warranties ...22... -
Page 5: Introduction
(EPA) “Energy Star” and the Swedish NUTEK power consumption requirements, conserving energy, reducing costs and prolonging monitor life. Further information If you would like further information about IBM and its products, please call one of the following numbers: IBM information 1-800-426-3333... -
Page 6: Getting Started
Unpacking Your monitor is heavy, so handle it with care. Whenever you need to move or lift it, minimise the risk of injury by keeping your back straight and by keeping the weight near to your body. If in doubt, ask someone to assist you. Lift the monitor by holding it firmly under each side and use proper lifting techniques. -
Page 7: Product Records
Product Records Important: Be sure to retain your proof of purchase because it might be required to receive warranty service. You should record the following information. IBM G41 / G50 1. Monitor name ______________________________ 2. Machine type/model ____________________ 3. Serial number _________________________ 4. -
Page 8: General Specifications
The following table provides the machine type and model number with their respective mains voltages and typical currents: G41: 14 inch (nominal) CRT with maximum viewable screen size, when measured diagonally of 336mm (13.2 inches) G50: 15 inch (nominal) FST with maximum viewable screen size, when measured diagonally of 342mm (13.4 inches) Machine Type 6542/301 6542/302... -
Page 9: Installation
Installation Workplace preparation This section gives advice on the things that you should consider before you set up your monitor. Positioning the Monitor Choose a suitable place to position the monitor. Ensure that the furniture or equipment can support the weight of the monitor. -
Page 10: Connecting The Monitor
Important: Before connecting the monitor, turn off the power supply to the computer and attached devices. If a switched mains power outlet is being used, ensure that it is turned off. Standard connection to a PC 1. Connect the signal cable to your computer taking care to ensure that you do not force the cable into your computer the wrong way round may have a video adapter card installed. -
Page 11: Optimising Performance
Optimising performance "Plug and Play" Monitor implementation of the VESA DDC standard offers the capability of automatic optimisation of monitor performance (“Plug and Play”). In order for automatic optimisation to be effective, the attaching computer must also be hardware and software enabled for DDC operation. - Page 12 How to change display modes Your operating system manual defines the procedure you should follow to change the default display mode. After selecting the optimum mode you need not perform this operation again unless you change your computer or software configuration. Notes: 1.
-
Page 13: Adjusting The Image
The image is already optimised for many display modes. However, the controls can be used to adjust the image to your liking. IBM recommends that the factory preset image size position and shape is used when operating with a display mode listed in Table 1. - Page 14 8 (brightness) or 9 (contrast). You can adjust the screen image. The pictures show how the image is affected. IBM recommends that the contrast is adjusted so that white text on a dark background does not appear to “bloom”. (The edges of the characters should remain sharp).
-
Page 15: Indicators
Indicators Power Management To benefit from power management (electricity conservation), the monitor must be used in conjunction with a computer that implements the Video Electronics Standards Association (VESA) Display Power Management Signalling (DPMS) Standard. The table below summarises the states shown by the power indicator: Power indicator Operating state... - Page 16 803299. To reactivate the monitor, simply press a key or move the mouse. There will be a short delay before the screen image reappears. As an Energy Star Partner, IBM has determined that this product meets Energy Star guidelines for energy efficiency.
-
Page 17: Disabling Ddc
Disabling DDC As previously mentioned, DDC offers “Plug and Play” ease of setup to the user. To take advantage of DDC requires suitable hardware and software inside your computer and it is possible that you will be attaching your monitor to a computer that does not support DDC. In most cases, this does not cause a problem other than the fact that the screen mode will need to be optimised manually. -
Page 18: Working With Your Monitor
Working with your Monitor IBM recommends that the use of primary colour blue on a dark background be avoided. It is difficult to see and may cause eyestrain due to insufficient contrast. -
Page 19: Troubleshooting
Troubleshooting If you have a problem setting up or using the monitor, you might be able to solve it yourself. Before calling IBM you should try the suggested actions that are appropriate to your problem. Problem Suggested action Screen is blank and •... - Page 20 Problem Suggested action Power indicator is • Display mode of the flashing green. computer is outside the range of the monitor. Reconfigure the computer to use a supported display mode. Refer to the Specifications section on page 20 and to Table 1 on page 9.
- Page 21 Call IBM HELPCENTER. In the US call 1-800-772-2227 In Canada call 1-800-565-3344 In other countries contact your dealer or other IBM authorised Servicer. Before calling, please have available as much of the following information as possible: 1.
-
Page 22: Glossary
Addressability The number of horizontal and vertical picture elements (pels) in the image. The higher the addressability, the more detailed the image that can be displayed on the screen. (Addressability is sometimes referred to as resolution). Display Data Channel. A VESA Standard enabling ‘Plug and Play’. -
Page 23: Specifications
Specifications G41: 14 inch (nominal) CRT with maximum viewable screen size, when measured diagonally of 336mm (13.2 inches) G50: 15 inch (nominal) FST with maximum viewable screen size, when measured diagonally of 348mm (13.7 inches) Dimensions Width: Depth: Height: Weight - G41: Weight - G50: Image Size... -
Page 24: Compliances
TV communications and to other electrical or electronic equipment. Such cables and connectors are available from IBM authorised dealers. Note (1): This compliance applies to universal (100 - 240 Vac) and Low voltage (100 - 120 Vac) monitor. -
Page 25: Warranties
Europe The warranty terms and conditions applicable in the country of purchase in respect of an IBM product are available from the supplier. Please retain them with your proof of purchase. No statements contained in this documentation shall affect the statutory...
