x7722271404 / x772000164
GRASS TRIMMER /
BRUSH CUTTER
Operator's Manual
The muffler or catalytic muffler and surrounding cover may become extremely hot.
Always keep clear of exhaust and muffler area, otherwise serious personal injury may
occur.
The engine exhaust from this product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Users of this equipment risk injury to themselves and others if the unit is used
improperly and/or safety precautions are not followed. ECHO provides an operator's
manual and a safety manual. Both must be read and understood for proper and safe
operation. Failure to do so could result in serious injury.
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time
of publication, but are subject to change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
X7532098207
© 2/2014 ECHO Inc.
SRM-230
Burn Hazard

Advertisement

Table of Contents
loading

Related Manuals for Echo SRM-230

Summary of Contents for Echo SRM-230

  • Page 1 Users of this equipment risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed. ECHO provides an operator’s manual and a safety manual. Both must be read and understood for proper and safe operation.

  • Page 2: Table Of Contents

    The Operator’s Manual..........................3 The Safety Manual ............................3 Servicing Information ............................3 Parts/Serial Number ............................ 3 Service................................. 3 Echo Consumer Product Support........................ 3 Warranty Registration..........................3 Additional or Replacement Manuals......................4 Safety ................................. 4 Manual Safety Symbols and Important Information..................4 International Symbols ..........................

  • Page 3: Introduction

    Service of this product during the warranty period must be performed by an Authorized ECHO Service Dealer. For the name and address of the Authorized ECHO Service Dealer nearest you, ask your retailer or call: 1-800-432-ECHO (3246). Dealer information is also available on our Web Site. When presenting your unit for Warranty service/repairs, proof of purchase is required.

  • Page 4: Additional Or Replacement Manuals

    ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. SAFETY Manual Safety Symbols and Important Information Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words.

  • Page 5: International Symbols

    Fuel and oil Keep bystanders and helpers Hot Surface mixture away 15 m (50 ft.). AVOID KICKOUT. Thrown Direction of Keep bystanders at least 15 meters objects blade (50 feet) away. Beware Thrown Objects Wear Eye Protection X7532098207 © 2/2014 ECHO Inc.

  • Page 6: Personal Condition And Safety Equipment

    Breathing Protection Wear a facemask to protect against dust. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing Wear snug fitting, durable clothing; • Pants should have long legs, shirts with long sleeves.
  • Page 7 ECHO does not recommend the use of ECHO products by anyone who has a pacemaker.

  • Page 8: Equipment

    Equipment Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 9: Emission Control (Exhaust & Evaporative)

    The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual. X7532098207 © 2/2014 ECHO Inc.

  • Page 10: Description

    Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
  • Page 11 19. PURGE BULB - Pumping purge bulb before starting engine draws fresh fuel from the fuel tank, purging air from the carburetor. Pump purge bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump purge bulb an additional 4 or 5 times. X7532098207 © 2/2014 ECHO Inc.

  • Page 12: Contents

    The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, shield installation and other assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 13: Assembly

    Using nylon line heads with metal debris shield can result in trimmer damage, caused by operation with excessive line length. Note: Your nylon line head may appear different than nylon line head shown. X7532098207 © 2/2014 ECHO Inc.

  • Page 14: To Advance Trimmer Line

    2. Remove line head (E) by turning it clockwise until head is completely off of shaft. 3. Remove locking tool (D). Support Handle Installation Note: Label shows minimum spacing for support handle location. 1. Position support handle for comfortable operation and secure screws. SPACING X7532098207 © 2/2014 ECHO Inc.

  • Page 15: Operation

    • Arbor Diameter of Upper Blade Plate must match arbor diameter of blades. • New cotter pin required each time blade is installed. • Brush cutters over 16.5 lbs (7.5 kg) dry weight (weight w/o fuel) require a double shoulder harness. X7532098207 © 2/2014 ECHO Inc.

  • Page 16: Blade Selection

    During blade operation, the same fatigue reduction is achieved. Safety to the operator is also enhanced by reducing the possibility of blade contact with the operator's hands and feet by restricting trimmer movement. X7532098207 © 2/2014 ECHO Inc.

  • Page 17: Fuel

    QR code. Fuel Alternative fuels, such as E-15 (15% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement.

  • Page 18: Starting Cold Engine

    1. Stop Switch Move stop switch button (A) forward, away from the STOP position. 2. Choke X7532098207 © 2/2014 ECHO Inc.

  • Page 19: Starting Warm Engine

    The attachment should not move at idle, otherwise serious personal injury may result. Note: If attachment moves, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch X7532098207 © 2/2014 ECHO Inc.

  • Page 20: Stopping Engine

    Move stop switch button (A) backward to STOP position. If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using unit again. X7532098207 © 2/2014 ECHO Inc.

  • Page 21: Maintenance

    If you are unsure or are not equipped with the necessary tools, you may want to take your unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded.

  • Page 22: Air Filter

    When servicing model year 2012 and later equipment, only fuel supply hoses certified by EPA can be used to replace the original equipment supply hose. Fines up to $37,500 may be enforced for using an un-certified replacement part. X7532098207 © 2/2014 ECHO Inc.

  • Page 23: Spark Plug

    Removal of cooling passage blockages or cleaning of cooling fins is considered “Normal Maintenance.” Any failure attributed to lack of maintenance is not warranted. 1. Remove spark plug lead. X7532098207 © 2/2014 ECHO Inc.

  • Page 24: Exhaust System

    5. Clean carbon deposits from muffler components. Note: When cleaning carbon deposits, be careful not to damage the catalytic element inside muffler. 6. Replace screen if it is cracked, plugged, or has holes burned through. 7. Assemble components in reverse order. X7532098207 © 2/2014 ECHO Inc.

  • Page 25: Exhaust Port Cleaning

    This engine has been factory adjusted to maintain satisfactory starting, emission, and durability performance up to 1,100 feet above sea level (ASL) (96.0 kPa). To maintain proper engine operation and emission compliance above 1,100 feet ASL the carburetor may need to be adjusted by an authorized ECHO service dealer.

  • Page 26: Lubrication

    3. Slide the flexible cable back in the drive housing. DO NOT get dirt on the flex cable. 4. Install the gear housing and shield assembly. Flat edge of washers (D) must be against drive shaft. X7532098207 © 2/2014 ECHO Inc.

  • Page 27: Nylon Line Head Disassembly Instructions

    4. Hold trimmer head while turning knob clockwise to wind line onto spool until about 5” (13 cm) of each line remains exposed. Trimmer head is now fully loaded and ready for operation. X7532098207 © 2/2014 ECHO Inc.

  • Page 28: Sharpening Metal Blades

    Speed-Feed® head is required. Wear Indicators Sharpening Metal Blades Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service.
  • Page 29 SRM-230 MAINTENANCE 3. After sharpening teeth, check each tooth radius for evidence of a square (sharp) corner. Use the round (rat tail) file to renew the radius. X7532098207 © 2/2014 ECHO Inc.

  • Page 30: Troubleshooting

     See your Echo dealer doesn’t start Stop switch off  Turn switch to ON  Spark at end of See your Echo dealer  No spark Electrical problem plug wire Interlock switch See your Echo dealer Spark gap incorrect Adjust to .65mm (0.026 in.)...

  • Page 31: Storage

    Observe the piston location through the spark plug hole. Pull the recoil handle slowly until the piston reaches the top of its travel and leave it there. 8. Install the spark plug (do not connect ignition cable). X7532098207 © 2/2014 ECHO Inc.

  • Page 32: Specifications

    400 LH Nylon line head, Line capacity 6.0 m (20 ft.) ® Handle Front - loop, Rear handle (w/o rubber) Shoulder Harness Optional Idle Speed 3,000 RPM Clutch Engagement Speed 3,850 RPM Wide Open Throttle Speed (W.O.T.) 8,500 RPM X7532098207 © 2/2014 ECHO Inc.

  • Page 33: Warranty Statements

    ECHO'S RESPONSIBILITY ECHO Incorporated’s Limited Warranty, provides to the original purchaser that this ECHO product is free from defects in material and workmanship. Under normal use and maintenance from date of purchase, ECHO agrees to repair or replace at ECHO’s discretion, any defective product free of charge at any authorized ECHO servicing dealer within listed below application time periods, limitations and exclusions.
  • Page 34 HWKDQRO JUDLQ DOFRKRO RU  07%( PHWK\OWHUWLDU\EXW\OHWKHU is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual. ‡ (QJLQH GDPDJH FDXVHG E\ XVH RI HWKHU RU DQ\ VWDUWLQJ ÀXLGV ‡...

  • Page 35: Notes

    SRM-230 NOTES NOTES X7532098207 © 2/2014 ECHO Inc.
  • Page 36 ECHO, INCORPORATED S65611001001/S65611999999 400 Oakwood Road S73112001001/S73112999999 Lake Zurich, IL 60047 www.echo-usa.com...
