Wolf FS-6J-27 Quick Manual

Model FS-6J-27
Design Certified by the American Gas Association
Design Certified by the Canadian Gas Association
Listed by the National Sanitation Foundation
Approved by ______________________
Date: _____________________________
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
F-39093 (9/05)
COMMANDER SERIES
SIX BURNER HEAVY-DUTY GAS RANGE
Item #_____________ C.S.I. Section 11420
BASIC MODEL:
FS-6J-27 36" wide six burner heavy-duty gas range
KEY FEATURES:
Stainless steel front, sides, bullnose, stub back and 6" adjust-
able legs. Sides finished in black epoxy powder coat paint.
1
1 ⁄ " diameter front gas manifold.
4
Six 30,000 BTU/hr. two piece burners. Individual pilot for each
burner.
Three heavy-duty cast iron top grates measure 12"w x 27"d.
Oven controls located in the cool zone.
Oven interior measures 27
enamel on steel oven hearth, rear panel and door liner. One
oven rack and four rack positions. 40,000 BTU/hr. burner with
pilot ignition. Thermostat adjusts from 250° to 500°F.
Oven door counterbalanced with weights.
One year limited parts and labor warranty.
OPTIONAL FEATURES:
Elevated rear (4" step-up) burners.
30,000 BTU/hr. Snorkler convection oven in place of standard
oven. Porcelain enamel on steel interior measures 26
23"d x 14"h. Two oven racks and 4 rack positions. Thermostat
adjusts from 200° to 500°F.
power cord and plug. 115/60/1, 4 amps.
Cabinet storage base in place of oven. Specify model no.
FS-6J-0-36.
Stainless steel doors on cabinet base.
Stainless steel finishing back.
Common stainless steel bullnose up to 120" wide. (Provide a
drawing showing the position of each piece of equipment in
the line-up with the order.)
Cap and cover manifold end(s). (No charge.)
Leveling bolts in place of legs for curb installation.
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 96" wide.
Rear gas connection. (Specify
DESCRIPTION:
Heavy-duty six burner gas range with oven, Wolf Model No.
FS-6J-27. Stainless steel front, sides, bullnose, stub back and 6"
1
adjustable legs. 1 ⁄ " diameter front gas manifold. Six 30,000 BTU/
4
hr. two piece burners. Individual pilot for each burner. Three heavy-
duty cast iron top grates measure 12"w x 27"d. Oven interior mea-
sures 27 1 ⁄ "w x 28 1 ⁄ "d x 14 1 ⁄ "h. Porcelain enamel on steel oven
2 2 2
hearth, rear panel and door liner. One oven rack and four rack
positions. 40,000 BTU/hr. burner with pilot ignition. Thermostat
adjusts from 250° to 500°F. Oven controls located in the cool zone.
Oven door counterbalanced with weights. Total input 220,000 BTU/
hr.
Exterior dimensions: 36"w x 38"d x 36" working height on 6"
adjustable legs.
Wolf Range Company
Division of ITW Food Equipment Group LLC
(800) 366-9653
www.wolfrange.com
1 ⁄ "w x 28 1 ⁄ "d x 14 1 ⁄ "h. Porcelain
2 2 2
1 ⁄ "w x
4
1
⁄ H.P. blower motor with 6 foot
4
3 ⁄ " or 1 1 ⁄ ".)
4 4
