- Page 1 12-2158.fm Page 1 Wednesday, September 13, 2000 1:50 PM Flat-Face Car CD Player with Signal Level Meter Display...
-
Page 2: Table Of Contents
12-2158.fm Page 2 Wednesday, September 13, 2000 1:50 PM ˆ Contents Features ..........................3 Installation ..........................4 Preparing the Mounting Area .................... 4 Routing Speaker Wires ..................... 4 Removing the Shipping Screws ..................4 Making the Connections ....................5 Using an Adapter Harness ..................5 Connecting Ground, Power, and Optional Components .......... -
Page 3: Features
12-2158.fm Page 3 Wednesday, September 13, 2000 1:50 PM ˆ Features Your RadioShack Flat-Face Car CD Player Audible Search — lets you rapidly play a has many practical, easy-to-use features, CD forward or backward to locate a desired and you can install it in almost any vehicle track or section of a track. -
Page 4: Installation
12-2158.fm Page 4 Wednesday, September 13, 2000 1:50 PM ˆ Installation Before you install your CD player, read all • Be sure to avoid obstructions behind the the instructions in this owner’s manual. You mounting surface. should be able to answer all of these ques- Note: If the mounting area is too large, you tions about your vehicle’s electrical and might be able to mount the CD player with an... -
Page 5: Making The Connections
12-2158.fm Page 5 Wednesday, September 13, 2000 1:50 PM MAKING THE the following procedure. Do not use a common wire or chassis ground for any CONNECTIONS speaker connection. The supplied harness with the 14-pin con- The CD player’s buzzer alarm sounds if you nector includes all the lead wires you need to make an incorrect connection that could connect the CD player to ground, power, op-... -
Page 6: Testing The Power Connections
12-2158.fm Page 6 Wednesday, September 13, 2000 1:50 PM Connecting an Equalizer/Booster point in your vehicle’s fuse block that provides a continuous source of 12 If you are connecting the CD player to a sep- volts. This provides power for the CD arate equalizer or booster, you need addi- player’s components, and continuous tional wires (not included). -
Page 7: Completing The Connection
12-2158.fm Page 7 Wednesday, September 13, 2000 1:50 PM 5. Connect the green wire to the left rear when you play the radio (see “Radio Opera- speaker’s positive terminal. tion” on Page 11). 6. Connect the green/black wire to the left If the display does not light and you do not rear speaker’s negative terminal. -
Page 8: Removing The Cd Player From The Dash
12-2158.fm Page 8 Wednesday, September 13, 2000 1:50 PM 4. Take off the plastic trim ring by lifting the 9. To further secure the CD player, use the top of the trim ring. supplied hardware to attach one end of the supplied metal strap to the mounting bolt on the back of the CD player. -
Page 9: Mounting In Toyota, Nissan And Suzuki Vehicles
12-2158.fm Page 9 Wednesday, September 13, 2000 1:50 PM 4. Remove the plastic trim ring by lifting the 7. Disconnect the 14-wire harness and the top of the trim ring. antenna. 5. Insert the supplied keys into the slots at 8. -
Page 10: Installing/Removing The Control Panel
12-2158.fm Page 10 Wednesday, September 13, 2000 1:50 PM INSTALLING/REMOVING sure the pins in the recess fill the slots in the edge of the control panel. THE CONTROL PANEL CD Player Control Panel The CD player's control panel must be in place for the CD player to operate. -
Page 11: Adjusting The Sound
12-2158.fm Page 11 Wednesday, September 13, 2000 1:50 PM Resetting the Display display after about 5 seconds if you do not press any buttons. Adjusting the Sound 1. Press to adjust the vol- VOL + VOL – ume or repeatedly press until appears on the display. -
Page 12: Cd Player Operation
12-2158.fm Page 12 Wednesday, September 13, 2000 1:50 PM appears. If you get a steady FM signal, (CD play), then TRACK 01 , and appears to the right side of the CD plays from Track 1. Adjust the CD player’s controls to your listen- •... -
Page 13: Audible Search
12-2158.fm Page 13 Wednesday, September 13, 2000 1:50 PM to select the next or 2. Press again to resume normal play. TRACK + TRACK – previous track. Repeat Play Audible Search 1. To repeat a track, press during play. To search for a particular section within a When the track ends, it automatically track, hold down during... -
Page 14: The Fcc Wants You To Know
12-2158.fm Page 14 Wednesday, September 13, 2000 1:50 PM and void your FCC authorization to operate • If you park your vehicle in the sun, tem- it. If your CD player is not performing as it peratures inside the vehicle can easily should, take it to your local RadioShack for reach levels that could damage your assistance. -
Page 15: Specifications
12-2158.fm Page 15 Wednesday, September 13, 2000 1:50 PM 5. Reassemble the red power wire’s fuse 6. Reassemble the filter and fuse box by holder by squeezing it together until it closing it then pushing the latch until it latches. clicks. -
Page 16: General
12-2158.fm Page 16 Wednesday, September 13, 2000 1:50 PM General Power Source ....................... 12V DC Negative Ground Speaker Output Impedance ..................... 4 or 8 Ohms Maximum Power: One Pair of Speakers (Max Output) ................. 25 Watts RMS/Channel Power Output (10% THD @ 1kHz) .................. 16W × 2 or 5W ×4 Two Pairs of Speakers (Max Output) .................
