CompuLab MintBox 2 Owner's Manual

Computer accesorry
Hide thumbs
Table of Contents

Advertisement

Quick Links

MintBox 2
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for CompuLab MintBox 2

Summary of Contents for CompuLab MintBox 2

  • Page 1 MintBox 2 Owner’s Manual...
  • Page 2 MintBox 2 Owner’s Manual December-2013 Introduction Package contents Hardware specifications MintBox 2 features Quick start guide Connecting MintBox 2 Booting Linux Maintenance Opening service door Service bay BIOS Setup Utility Warranty and RMA Warranty Tips for saving power General In Operating System For more information and to obtain the latest revision of this document, please visit www.fit-pc.com...

  • Page 3: Package Contents

    2x USB 3.0 5 Gbps 2x USB 2.0 480 Mbps 4x USB 2.0 in front Serial RS232 full UART (mini connector, cable sold separately) Power 12V DC Operating temperature 0 – 50 * Local resellers may supply MintBox 2 with other AC cord types.

  • Page 4: Front Panel

    Standard HDMI with audio support DisplayPort To connect MintBox 2 to a DVI display, use the provided HDMI to DVI-D adapter. Use a DVI cable to connect the adapter to the display. To connect MintBox 2 to a VGA display use fit-VGA (sold separately).

  • Page 5: Serial Port

    Depending on the FACE Module used - some models incorporate additional 4 USB 2.0 ports in the front. Serial port The RS232 mini-serial port is located on the back panel. Mini-serial to DB9 cable to connect to standard serial devices is sold separately. eSATA MintBox 2 features two eSATA ports. Ports are located on the back panel.

  • Page 6: Booting Linux

    Quick start guide Connecting MintBox 2  Turn off the display and connect it to the MintBox 2 HDMI connector (use the HDMI to DVI adapter if needed).  Connect the USB keyboard and mouse to USB 2 connectors. ...

  • Page 7: Maintenance

    Maintenance MintBox 2 requires no maintenance. You should not take the MintBox 2 apart other than opening the service door. Taking MintBox 2 apart will void its warranty. The following operations can be conducted by the user: Opening service door Unscrew marked Philips screw at the bottom to release service-door.

  • Page 8: Bios Setup Utility

    This warranty is void if the product has been altered or damaged by accident, misuse or abuse. Keep the original package for shipping in case of hardware failure. In case of HW failure of a MintBox 2 under warranty, please contact the seller of that MintBox 2. Please provide the following required information: ...
  • Page 9 -Increase the separation between the equipment and party responsible for compliance receiver. (CompuLab Ltd.) could void the user’s -Connect the equipment into an outlet on a circuit authority to operate the equipment. different from that to which the receiver is connected.
