  • Page 1 Picasso SERVICE GUIDE...

  • Page 2: Revision History

    Copyright Copyright © 2011 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 3 Conventions The following conventions are used in this manual: WARNING: Indicates a potential for personal injury. CAUTION: Indicates a potential loss of data or damage to equipment. IMPORTANT: Indicates information that is important to know for the proper completion of a procedure, choice of an option, or completing a task.

  • Page 4: General Information

    Acer-authorized Service Providers: Your Acer office may have a different part number code than those given in the FRU list in this service guide. The list provided by your regional Acer office must be used to order FRU parts...

  • Page 5: Table Of Contents

    CHAPTER 1 Hardware Specifications Features ..........1-5 Form Factor.
  • Page 6 Rear Camera ........1-24 Mini Card .
  • Page 7 Mainboard Removal....... . 3-31 Mainboard Installation ......3-33 Rear CCD Removal .
  • Page 8 CHAPTER 5 Jumper and Connector Locations Mainboard ......... . 5-3 CHAPTER 6 Field Replaceable Unit List Exploded Diagrams .
  • Page 9 CHAPTER Hardware Specifications...
  • Page 10 Features ..........1-5 Form Factor.
  • Page 11 Card Reader ........1-27 System LED Indicator .

  • Page 13: Features

    Hardware Specifications and Configurations Features The following is a summary of the computer’s many features: Form Factor 10.1" Tablet Tegra 250 Dual cortex A9, 1GHz ® GPU Ultra Low Power GeForce Memory RAM: LP DDR2 1GB eMMC: eMMC: 16G / 32G two SKU (SanDisk / Samsung) 10.1"...

  • Page 14: Camera

    Camera Main camera: 5M Camera with Auto focus with flash lights (single LED) Second camera : 2M FF Connectivity ® Bluetooth 2.1+EDR Wi-Fi IEEE 802.11b/g/n (2.4Ghz) Micro USB 2.0 type B for Client USB 2.0 Host Input Capacitive Multi-Touch Screen (Real 4 touch, up to 10) Function buttons Side (mechanical key): Volume Up, Volume Down, screen lock...

  • Page 15: Expansion Slot

    Expansion Slot MicroSD memory card up to 32G (SDHC 2.0 compatible) AC Adapter and Battery Battery Rechargeable Lithium-ion polymer battery Capacity: 24.1W (3260mAh cell , 2S1P) AC Adapter Voltage range/frequency: 100 ~ 240V AC, 50/60 Hz DC output: 12V and 1.5 A, 18W Green Requirement Rohs compliance WEEE compliance...

  • Page 16: Notebook Tour

    Notebook Tour Front View Figure 1-1. Front View Table 1-1. Front View Icon Item Description Front Camera 5M Pixel CCD Touch Window Hardware Specifications and Configurations...

  • Page 17: Rear View

    Rear View Figure 1-2. Front View Table 1-2. Front View Icon Item Description 2M Pixel CCD & LED 2 Speakers Hardware Specifications and Configurations...

  • Page 18: Top View

    Top View Figure 1-3. Top View Table 1-3. Top View Icon Item Description Power Button Headset Jack HDMI Jack 1-10 Hardware Specifications and Configurations...

  • Page 19: Left View

    Left View Figure 1-4. Left View Table 1-4. Left View Icon Item Description Docking Station Jack 1-11 Hardware Specifications and Configurations...

  • Page 20: Right View

    Right View Figure 1-5. Right View Table 1-5. Right View Icon Item Description Volume Button Touch Screen Lock Switch Micro-SD & SIM Card Ports 1-12 Hardware Specifications and Configurations...

  • Page 21: Bottom View

    Bottom View Figure 1-6. Bottom View Table 1-6. Bottom View Icon Item Description Reset Button USB Port Micro-USB Port AC Adapter Jack 1-13 Hardware Specifications and Configurations...

  • Page 22: System Block Diagram

    System Block Diagram Figure 1-7. System Block Diagram 1-14 Hardware Specifications and Configurations...

  • Page 23: Specification Tables

    Specification Tables Computer specifications Item Metric Imperial Dimensions Length 260mm 10.23in Width 177mm 6.96in Height 13.3mm 0.52in (front to rear) Weight (equipped with optical 750g 1.65lb drive, flash drive, and battery) Weight (equipped with optical drive, flash drive, and battery) Input power Operating voltage 12.0 V dc @ 1.5 A - 18 W...

  • Page 24: System Board Major Chips

    System Board Major Chips Item Specification Core logic Tegra 250 Dual cortex A9, 1GHz Integrate in Tegra 250 CPU not in this computer USB 2.0 Integrate in Tegra 250 CPU Super I/O controller Bluetooth Broadcom BCM4329 Wireless Broadcom BCM4329 PCMCIA Audio codec Wolfson WM8903 Card reader...

  • Page 25: Processor Specifications

    Processor Specifications Item CPU Speed Cores/ Cache Package Voltage Threads Speed Tech Size (GHz) (FSB/ (nm) DMI/QBI) 1 GHz 2 Cores 40 nm 23x23 1.0-1.2V FCBGA CPU Fan True Value Table (N/A) CPU Temperature Fan Speed (RPM) SPL Spec (dBA) System Memory Item Specification...

  • Page 26: Memory Combinations

    Memory Combinations Slot 1 (MB) Slot 2 (MB) Total Memory (MB) 1024 1024 2048 2048 4096 4096 8192 8192 1024 1024 1024 1024 2048 1024 2048 3072 1024 4096 5120 1024 8192 9216 2048 2048 2048 1024 3072 2048 2048 4096 2048 4096...
  • Page 27 BIOS (N/A) Item Specification BIOS vendor BIOS Version BIOS ROM type BIOS ROM size Features LAN Interface (N/A) Item Specification LAN Chipset LAN connector type LAN connector location Features Keyboard (N/A) Item Specification Type Total number of keypads Windows logo key Internal &...
  • Page 28 Hard Disk Drive (AVL components) (N/A) Item Specification Vendor & Model Name Capacity (GB) Bytes per sector Data heads Drive Format Disks Spindle speed (RPM) Performance Specifications Buffer size Interface Fast data transfer rate (Mbits / sec, max) Media data transfer rate (Mbytes/sec max) DC Power Requirements...

  • Page 29: Embedded Multimediacard (Avl Components)

    Embedded MultiMediaCard (AVL components) Item Specification Vendor & Model Sandisk Samsung Sandisk Samsung Name SDIN4C2-16G KLMAG4EEHM SDIN4E2-32G KLMBG8FEJA Capacity (GB) DC Power Requirements Voltage tolerance 1.8V Super-Multi Drive (N/A) Item Specification Vendor & Model name Performance Specification Transfer rate (KB/sec) Buffer Memory Interface Applicable disc format...

  • Page 30: Led 10.1

    LED 10.1” Item Specification Vendor/Model name AUO/B101EW05 V1 Screen Diagonal (mm) 255.85 mm Active Area (mm) 216.96 mm x 135.6 mm Display resolution (pixels) 1280x 3(RGB) x 800 Pixel Pitch (mm) 0.1695mm × 0.1695mm Typical White Luminance 300 cd/m2 (cd/m ) also called Brightness Contrast Ratio 1000 min / 1300 type...

  • Page 31: Display Supported Resolution (Lcd)

    Display Supported Resolution (LCD) Resolution 16 bits 32 bits Intel NVIDIA 1280x 3(RGB) x 800 NOTE: Resolution fixed at 1280 x 800. Not adjustable by end user. Graphics Controller (N/A) Item Specification VGA Chip Supports Display Supported Resolution (GPU) Resolution 16 bits 32 bits Intel...

  • Page 32: Front Camera

    Front Camera Item Specification Vendor and Model Chicony / Aptina 2031 Type Rear Camera Item Specification Vendor and Model Liteon / OV5650 CSI Liteon / Aptina 5140 Type Mini Card Item Specification Number supported Features 1 mini card slot (for WWAN) 3G Card Item Specification...

  • Page 33: Audio Codec And Amplifier

    Audio Codec and Amplifier Item Specification Audio Controller Audio codec: Wolfson WM8903 Features 4.5mW Power consumption for DAC to headphone playback DAC SNR 96dB typical , THD -86dB typical ADC SNR 92dB typical , THD -80dB typical Control sequencer for pop minimized start-up and shut-down Single register write for default start-up sequence Stereo digital microphone input 3 single ended inputs per stereo channel...

  • Page 34: Wireless Module 802.11B/G/N

    Wireless Module 802.11b/g/n Item Specification Chipset Azurewave AW-NH611 - Broadcom BCM4329 SoC Data throughput 802.11b/g: 11~54 Mbps 802.11n: MCS 0-7 Protocol IEEE 802.11b/g/n Interface SDIO/SPI interface. Battery Item Specification Vendor & Model name SIMPLO BAT-1010 SANYO BAT100 Battery Type Li-ion Pack capacity 3260mAh/24Wh Number of battery cell...

  • Page 35: Ac Adapter

    AC Adapter Item Specification Input rating Maximum input AC current 0.5A(RMS) at 100Vac Inrush current 60A Max. @230Vac Efficiency Refer to EPS 2.0 standard level V System Power Management Item Specification Mech. Off (G3) Only EC working. Soft Off (G2/S5) Only EC working.

  • Page 36: System Dma Specification

    System DMA Specification Legacy Mode Power Management DMA0 Not applicable DMA1 Not applicable DMA2 Not applicable DMA3 Not applicable DMA4 Direct memory access controller DMA5 Available for ExpressCard DMA6 Not Assigned DMA7 Not Assigned *ExpressCard controller can use DMA 1, 2, or 5. System Interrupt Specification (N/A) Hardware IRQ System Function...
  • Page 37 System IO Address Map (N/A) I/O address (hex) System Function (shipping configuration) 000 - 00F 010 - 01F 020 - 021 022 - 024 025 - 03F 02E - 02F 040 - 05F 044 - 05F 062 - 063 065 - 06F 070 - 071 072 - 07F 080 - 08F...
  • Page 38 System I/O Address Specifications (N/A) I/O address (hex) System Function (shipping configuration) 220 - 22F 230 - 26D 26E - 26 278 - 27F 280 - 2AB 2A0 - 2A7 2A8 - 2E7 2E8 - 2EF 2F0 - 2F7 2F8 - 2FF 300 - 31F 320 - 36F 370 - 377...

  • Page 39: System Utilities

    CHAPTER System Utilities...

  • Page 40: Introduction

    Introduction ......... 2-3...

  • Page 41: Introduction

    System Utilities Introduction System Utilities...
  • Page 42 System Utilities...

  • Page 43: Maintenance Procedures

    CHAPTER Maintenance Procedures...
  • Page 44 Introduction ......... 3-3 General Information .

  • Page 45: Introduction

    Machine Maintenance Procedures Introduction This chapter contains general information about the notebook, a list of tools needed to perform the required maintenance and step by step procedures on how to remove and install components from the notebook computer. General Information Recommended Equipment The following tools are required to perform maintenance on the notebook: Wrist grounding strap and conductive mat...

  • Page 46: Maintenance Flowchart

    Maintenance Flowchart The flowchart in Figure 3-1 provides a graphic representation of the module removal and installation sequences. It provides information on what components need to be removed and installed during servicing. Figure 3-1. Maintenance Flow Machine Maintenance Procedures...

  • Page 47: Getting Started

    Getting Started The flowchart (Figure 3-1) identifies sections illustrating the entire removal and install sequence. Observe the order of the sequence to avoid damage to any of the hardware components. Perform the following prior to performing any maintenance procedures: 1. Place system on a flat work surface. 2.

  • Page 48: Sim/Micro-Sd Card Removal

    SIM/Micro-SD Card Removal 1. Open SIM/Micro-SD card cover. (Figure 3-3) Figure 3-3. Opening SIM/Micro-SD Card Cover 2. Remove SIM card from spring locking mechanism. (Figure 3-4) Figure 3-4. Removing SIM Card Machine Maintenance Procedures...
  • Page 49 3. Remove Micro-SD card from spring locking mechanism. (Figure 3-5) Figure 3-5. Removing Micro-SD Card 4. Secure SIM/Micro-SD card cover. (Figure 3-6) Figure 3-6. Securing SIM/Micro-SD Card Cover Machine Maintenance Procedures...

  • Page 50: Sim/Micro-Sd Card Installation

    SIM/Micro-SD Card Installation 1. Open SIM/Micro-SD card cover. (Figure 3-3) 2. Install and secure SIM card. (Figure 3-4) 3. Install and secure Micro-SD card. (Figure 3-5) 4. Close and secure SIM/Micro-SD card cover. (Figure 3-6) Machine Maintenance Procedures...

  • Page 51: Lower Case Removal

    Lower Case Removal Prerequisite: SIM/Micro-SD Card Removal 1. Open SIM/Micro-SD card cover (A). (Figure 3-7) Figure 3-7. Opening SIM/Micro-SD Card Cover 2. Insert plastic pry into slot below Micro-SD card cover as shown in Figure 3-8 to unlock latch. (Figure 3-8) Figure 3-8.
  • Page 52 3. Starting from edge as shown in Figure 3-9, unlock locking latches on rear cover from bezel. Figure 3-9. Unlocking Locking Latches (2 of 5) Figure 3-10. Unlocking Locking Latches (3 of 5) 3-10 Machine Maintenance Procedures...
  • Page 53 Figure 3-11. Unlocking Locking Latches (4 of 5) Figure 3-12. Unlocking Locking Latches (5 of 5) 3-11 Machine Maintenance Procedures...

  • Page 54: Lower Case Installation

    4. Remove lower case from bezel. (Figure 3-13) Figure 3-13. Removing Lower Case Lower Case Installation 1. Open SIM/Micro-SD card cover. (Figure 3-14) Figure 3-14. Opening SIM/Micro-SD Card Cover 3-12 Machine Maintenance Procedures...
  • Page 55 2. Align Micro-SD port with slot on bezel. (Figure 3-15) Figure 3-15. Aligning Lower Case with Bezel 3. Install lower case on bezel. (Figure 3-16) Figure 3-16. Installing Lower Case on Bezel 3-13 Machine Maintenance Procedures...
  • Page 56 4. Starting at volume button, secure locking latches to rear cover on all sides of bezel. (Figure 3-17 through Figure 3-20) Figure 3-17. Securing Locking Latches (1 of 4) Figure 3-18. Securing Locking Latches (2 of 4) 3-14 Machine Maintenance Procedures...
  • Page 57 Figure 3-19. Securing Locking Latches (3 of 4) Figure 3-20. Securing Locking Latches (4 of 4) 3-15 Machine Maintenance Procedures...
  • Page 58 5. Secure SIM/Micro-SD card cover. (Figure 3-21) Figure 3-21. Securing SIM/Micro-SD Card Cover 6. Install SIM/Micro-SD card. 3-16 Machine Maintenance Procedures...

  • Page 59: Dc-In Cable Removal

    DC-In Cable Removal Prerequisite: Lower Case Removal 1. Remove tape (A) covering DC-In and antenna cables. (Figure 3-22) Figure 3-22. Removing Protective Tape 2. Disconnect DC-In cable (B) from mainboard connector (b). (Figure 3-23) Figure 3-23. Disconnecting DC-In Cable 3-17 Machine Maintenance Procedures...
  • Page 60 3. Remove DC-In cable from the LCD support plate (C) and bezel (D) guides. (Figure 3-24) Figure 3-24. Removing DC-In Cable 4. Remove DC-In jack from bezel. (Figure 3-25) Figure 3-25. Removing DC-In Jack 3-18 Machine Maintenance Procedures...

  • Page 61: Dc-In Cable Installation

    DC-In Cable Installation 1. Install and secure DC-In jack on bezel. (Figure 3-25) 2. Connect DC-In cable (B) to mainboard connector (b). (Figure 3-23) 3. Install and secure DC-In cable to bezel (D) and LCD support plate (C) guides. (Figure 3-24) 4.

  • Page 62: Battery Removal

    Battery Removal Prerequisite: DC-In Cable Removal 1. Remove four (4) screws (A) from LCD support plate. (Figure 3-26) Figure 3-26. Removing Battery Screws 2. Disconnect battery cable (B) from mainboard connector (b). (Figure 3-27) Figure 3-27. Disconnecting Battery Cable 3-20 Machine Maintenance Procedures...

  • Page 63: Battery Installation

    3. Remove battery (C). (Figure 3-28) Figure 3-28. Removing Battery Battery Installation 1. Install battery (C) on LCD support plate. (Figure 3-28) 2. Connect battery cable (B) to mainboard connector (b). (Figure 3-27) 3. Install and secure four (4) screws (A) to LCD support plate. (Figure 3-26) 4.

  • Page 64: 3G Module Removal

    3G Module Removal Prerequisite: Battery Removal 1. Locate 3G module (A) on LCD support plate. (Figure 3-29) Figure 3-29. 3G Module on LCD Support Plate 2. Disconnect auxiliary (blue) and main (black) cables from 3G module connectors. (Figure 3-30) Figure 3-30. Disconnecting 3G Cables 3-22 Machine Maintenance Procedures...
  • Page 65 3. Remove two (2) screws (B) from LCD support plate. (Figure 3-31) Figure 3-31. Removing 3G Module Screws 4. Remove 3G module (C) from mainboard connector (c). (Figure 3-32) Figure 3-32. Removing 3G Module 3-23 Machine Maintenance Procedures...

  • Page 66: 3G Module Installation

    3G Module Installation 1. Install and connect 3G module (C) to mainboard connector (c). (Figure 3-32) 2. Install and secure two (2) screws (B) to LCD support plate. (Figure 3-31) 3. Connect main 3G antenna cable (black) to 3G module connector labeled M. (Figure 3-30) 4.

  • Page 67: Docking Board Removal

    Docking Board Removal Prerequisite: Battery Removal 1. Locate Docking Board (A). (Figure 3-33) Figure 3-33. Docking Board Overview 2. Disconnect docking board FFC (B) from docking board connector (b). (Figure 3-34) Figure 3-34. Disconnecting Docking Board FFC from Docking Board 3-25 Machine Maintenance Procedures...
  • Page 68 3. Disconnect docking board FFC (C), labeled MB, from mainboard connector (c). (Figure 3-35) Figure 3-35. Disconnecting Docking Board FFC from Mainboard 4. Remove three (3) screws (C) from bezel. (Figure 3-36) Figure 3-36. Removing Docking Board Screws 3-26 Machine Maintenance Procedures...
  • Page 69 5. Remove docking board from bezel. (Figure 3-37) Figure 3-37. Removing Docking Board 3-27 Machine Maintenance Procedures...

  • Page 70: Docking Board Installation

    Docking Board Installation 1. Align docking board with bezel guides (E). (Figure 3-38) Figure 3-38. Aligning Docking Board Bezel Guides 2. Install board on bezel. (Figure 3-37) 3. Install and secure three (3) screws (D) to bezel. (Figure 3-36) 4. Install and connect docking board FFC (C), labeled MB, to mainboard connector (c).

  • Page 71: Gps Antenna Removal

    GPS Antenna Removal Prerequisite: Battery Removal 1. Disconnect GPS antenna (A) from mainboard connector. (Figure 3-39) Figure 3-39. Disconnecting GPS Antenna 2. Remove GPS module. (Figure 3-40) Figure 3-40. Removing GPS Module 3-29 Machine Maintenance Procedures...

  • Page 72: Gps Antenna Installation

    GPS Antenna Installation 1. Install GPS module on bezel. (Figure 3-40) 2. Connect GPS antenna (A) to mainboard connector. (Figure 3-39) 3. Install battery. 3-30 Machine Maintenance Procedures...

  • Page 73: Mainboard Removal

    Mainboard Removal Prerequisite: 3G Module Removal 1. Disconnect the following cables: (Figure 3-41) Front and rear microphone cables (A) from mainboard connectors (a) Touch screen cable (B) from mainboard connector (b) Main (black) WLAN cable (C) from mainboard connector (c) Front camera FFC (D) from mainboard connector (d) LVDS cable (E) from mainboard connector (e) Speaker cable (F) from mainboard connector (f)
  • Page 74 2. Remove screw (H) and four (4) screws (J) from bezel. (Figure 3-42) Figure 3-42. Removing Mainboard Screws 3. Lift and remove mainboard from bezel. (Figure 3-43) Figure 3-43. Removing Mainboard 3-32 Machine Maintenance Procedures...

  • Page 75: Mainboard Installation

    Mainboard Installation CAUTION: The touch screen lock button guides may be damaged when the mainboard screws are secured. Make sure to align the touch screen lock button switch with the lock button guides. 1. Set touch screen lock button (K) to unlock position. (Figure 3-44) unlocked locked Figure 3-44.
  • Page 76 3. Align with bezel guide pins (L). (Figure 3-46) Figure 3-46. Aligning Mainboard with Bezel Guide Pins 4. Align touch screen lock button switch (M) with lock button guides (N). (Figure 3-47) Figure 3-47. Install Mainboard to IO Ports 3-34 Machine Maintenance Procedures...
  • Page 77 5. Install and secure one screw (H) and four (4) screws (J) to bezel. (Figure 3-42) 6. Connect the following cables: (Figure 3-41) Front and rear microphone cables (A) to mainboard connectors (a) Touch screen cable (B) to mainboard connector (b) Main (black) WLAN cable (C) to mainboard connector (c) Front camera FFC (D) to mainboard connector (d) LVDS cable (E) to mainboard connector (e)

  • Page 78: Rear Ccd Removal

    Rear CCD Removal Prerequisite: Mainboard Removal 1. Place bottom of mainboard on a flat surface.(Figure 3-48) Figure 3-48. Mainboard Overview 2. Remove rear camera (A) from mainboard. 3. Remove rear camera holder from mainboard by pressing holder through the board. (Figure 3-49 through Figure 3-51) Figure 3-49.
  • Page 79 Figure 3-50. Removing Rear CCD Holder (2 of 3) Figure 3-51. Removing Rear CCD Holder (3 of 3) 3-37 Machine Maintenance Procedures...

  • Page 80: Rear Ccd Installation

    Rear CCD Installation 1. Align rear camera holder guide (B) with mainboard slot (C).(Figure 3-52) Figure 3-52. Align Rear CCD Holder Guide with Mainboard Slot 2. Install and secure rear camera holder on mainboard by pressing holder into the opening in mainboard.(Figure 3-50 through Figure...

  • Page 81: Front Ccd Removal

    Front CCD Removal Prerequisite: Mainboard Removal 1. Release bezel locking latches (A).(Figure 3-53) Figure 3-53. Release Bezel Locking Latches 2. Remove front camera from bezel.(Figure 3-54) Figure 3-54. Removing Front CCD Front CCD Installation 1. Install and secure front camera in bezel locking latches (A).(Figure 3-53) 2.

  • Page 82: Two-Piece Microphone Removal

    Two-Piece Microphone Removal Prerequisite: Mainboard Removal 1. Remove two-piece microphone (A) from bezel guides.(Figure 3-55) Figure 3-55. Removing Two-piece Microphone 3-40 Machine Maintenance Procedures...

  • Page 83: Two-Piece Microphone Installation

    Two-Piece Microphone Installation 1. Install and secure microphone (B) in front microphone guide (closest to touch screen board) facing down.(Figure 3-56) Figure 3-56. Installing Two-piece Microphone to Front Guide 2. Install and secure microphone (C) in rear microphone guide (furthest away from touch screen board) facing up.(Figure 3-57) Figure 3-57.

  • Page 84: Speakers Removal

    Speakers Removal Prerequisite: Mainboard Removal 1. Remove three (3) screws (A) from bezel.(Figure 3-58) Figure 3-58. LCD Support Plate Overview with Speakers 2. Remove speakers (B) and speaker cable (C) from bezel. Speakers Installation 1. Install speakers (B) and speaker cable (C) on bezel. (Figure 3-58) 2.

  • Page 85: Usb Module Removal

    USB Module Removal Prerequisite: Speakers Removal 1. Disconnect module FFC (A) from module connector (a). (Figure 3-59) Figure 3-59. Disconnecting USB FFC 2. Remove module FFC. 3. Remove two (2) screws (A) from bezel. (Figure 3-60) Figure 3-60. Removing USB Module Screws 3-43 Machine Maintenance Procedures...

  • Page 86: Usb Module Installation

    4. Remove module support bracket (B). 5. Remove module (C). (Figure 3-61) Figure 3-61. Removing USB Module USB Module Installation 1. Align module with bezel guides (B). (Figure 3-62) Figure 3-62. Aligning USB Module to Bezel Guides 2. Install module on bezel. 3.
  • Page 87 Size Quantity Screw Type M2.0x4.0 Ni 3-45 Machine Maintenance Procedures...

  • Page 88: Lcd Support Plate Removal

    LCD Support Plate Removal Prerequisite: Speakers Removal 1. Remove Mylar tape (A) from LCD support plate. (Figure 3-63) Figure 3-63. Removing Mylar Tape 2. Remove antenna cables from LCD support plate guides (B). (Figure 3-64) Figure 3-64. Removing Antenna Cables 3-46 Machine Maintenance Procedures...
  • Page 89 3. Remove one screw (C) and one screw D) from bezel. (Figure 3-65) Figure 3-65. Removing LCD Support Plate Screws 4. Remove LCD support plate. (Figure 3-66) Figure 3-66. Removing LCD Support Plate 5. Disconnect touch screen FFC (E) from board connector (e). (Figure 3-67) 3-47 Machine Maintenance Procedures...
  • Page 90 Figure 3-67. Disconnecting Touch Screen FFC 6. Remove adhesive tape (F) covering LVDS cable (G) and LCD panel connector (g). (Figure 3-68) Figure 3-68. Removing LVDS Adhesive Tape 7. Disconnect and remove LVDS cable. 3-48 Machine Maintenance Procedures...

  • Page 91: Lcd Support Plate Installation

    LCD Support Plate Installation 1. Connect LVDS cable (G) to LCD panel connector (g). (Figure 3-68) 2. Install and secure adhesive tape (F) covering LVDS cable and LCD panel connector. 3. Connect and secure touch screen FFC (F) to board connector (f). (Figure 3-67) 4.

  • Page 92: Touch Screen Board Removal

    Touch Screen Board Removal Prerequisite: LCD Support Plate Removal 1. Remove touch screen board (A) from LCD support plate (B). (Figure 3-69 and Figure 3-70) Figure 3-69. Removing Touch Screen Board (1 of 2) Figure 3-70. Removing Touch Screen Board (2 of 2) 3-50 Machine Maintenance Procedures...

  • Page 93: Touch Screen Board Installation

    2. Disconnect and remove touch screen board cable (C) from board connector (c). (Figure 3-71) Figure 3-71. Removing Touch Screen Board Cable Touch Screen Board Installation 1. Install and connect touch screen cable (C) to board connector (c). (Figure 3-71) 2.
  • Page 94 Figure 3-73. Installing Touch Screen Board 4. Install LCD support plate. 3-52 Machine Maintenance Procedures...

  • Page 95: 3G Antenna Removal

    3G Antenna Removal Prerequisite: LCD Support Plate Removal 1. Remove main (A, black) and auxiliary (B, blue) antennas from bezel. (Figure 3-74) Figure 3-74. Removing 3G Antennas 3G Antenna Installation 1. Align main (black) antenna to bezel guide (C).(Figure 3-75) 3-53 Machine Maintenance Procedures...
  • Page 96 Figure 3-75. Aligning Main 3G Antenna 2. Align auxiliary (blue) antenna to bezel guide (D).(Figure 3-76) Figure 3-76. Aligning Auxiliary 3G Antenna 3. Install and secure 3G antennas on bezel. 4. Install LCD support plate. 3-54 Machine Maintenance Procedures...

  • Page 97: Wlan Antenna Removal

    WLAN Antenna Removal Prerequisite: LCD Support Plate Removal 1. Remove main (black) WLAN antenna (A) from bezel. (Figure 3-77) Figure 3-77. Removing WLAN Antenna 3-55 Machine Maintenance Procedures...

  • Page 98: Wlan Antenna Installation

    WLAN Antenna Installation 1. Align main (black) WLAN antenna to bezel guide (B).(Figure 3-78) Figure 3-78. Aligning WLAN Antenna 2. Install and secure WLAN antenna on bezel. 3. Install LCD support plate. 3-56 Machine Maintenance Procedures...
  • Page 99 CHAPTER Troubleshooting...
  • Page 100 Introduction ......... 4-3 General Information .

  • Page 101: Troubleshooting

    NOTE: NOTE: The diagnostic tests are intended for Acer products only. Non-Acer products, prototype cards, or modified options can give false errors and invalid system responses. 1. Obtain as much detailed information as possible about the problem.

  • Page 102: Power On Issues

    Power On Issues If the system doesn’t power on, perform the following: Start Check AC cable / BATT Swap AC cable/ BATT only power on Swap M/B Figure 4-1. Power On Issues Troubleshooting...

  • Page 103: No Display Issues

    No Display Issues If the system doesn’t display, perform the following: Start Go to no power power on Trouble shoo ng step Check LCD cable swap LCD cable LCD panel Swap LCD panel Swap M/B Figure 4-2. No Display Issues Troubleshooting...

  • Page 104: Lcd Picture Failure

    LCD Picture Failure If the LCD picture fails, perform the following: Start Check LCD cable Swap LCD cable Check LCD panel Swap LCD panel Swap M/B Figure 4-3. LCD Picture Failure Troubleshooting...

  • Page 105: Touch Screen Failure

    Touch Screen Failure If the touch screen fails, perform the following: Start Check touch Swap touch screen cable screen cable Check touch Swap touch screen small/B screen small/B Check touch Swap touch screen panel screen panel Swap M/B Figure 4-4. Touch Screen Failure Troubleshooting...

  • Page 106: Internal Speaker Failure

    Internal Speaker Failure If the internal speakers fail, perform the following: Start Check SPK Swap SPK Swap M/B Figure 4-5. Internal Speaker Failure Troubleshooting...

  • Page 107: Internal Microphone Failure

    Internal Microphone Failure If the internal microphone fails, perform the following: Start Check the front MIC and the back MIC Swap the Check the Check the Swap the front MIC back MIC front MIC back MIC Swap M/B Swap M/B Figure 4-6.

  • Page 108: Usb Failure

    USB Failure If the USB fails, perform the following: Start Swap the USB/B Check the USB/B to M/B FFC to M/B FFC Check the USB/B Swap the USB/B Swap M/B Figure 4-7. USB Failure 4-10 Troubleshooting...

  • Page 109: Front Camera Failure

    Front Camera Failure If the front camera fails, perform the following: Start Check the Swap the front camera front camera Swap M/B Figure 4-8. Front Camera Failure 4-11 Troubleshooting...

  • Page 110: Back Camera Failure

    Back Camera Failure If the back camera fails, perform the following: Start Check the Swap the back camera back camera Swap M/B Figure 4-9. Back Camera Failure 4-12 Troubleshooting...

  • Page 111: P-Sensor Failure

    P-Sensor Failure If the P-sensor fails, perform the following: Start Check conduc ve Add conduc ve co on co on on the Lower Check related Mylar Add related Mylar on the MB Swap M/B Figure 4-10. P-Sensor Failure 4-13 Troubleshooting...

  • Page 112: 3G Function Failure

    3G Function Failure If the 3G function fails, perform the following: Start Check the Swap the 3G Main antenna 3G antenna Check the Swap the 3G card 3G card Swap M/B Figure 4-11. 3G Function Failure 4-14 Troubleshooting...

  • Page 113: Wireless Function Test Failure

    Wireless Function Test Failure If the wireless function fails, perform the following: Start Check the Swap the antenna W/L antenna Swap M/B Figure 4-12. Wireless Function Failure 4-15 Troubleshooting...

  • Page 114: Gps Function Test Failure (Wi-Fi Sku)

    GPS Function Test Failure (Wi-Fi SKU) If the GPS function test fails, perform the following: Start Check the Swap the antenna GPS antenna Swap M/B Figure 4-13. GPS Function Test Failure 4-16 Troubleshooting...

  • Page 115: Gps Function Test Failure (3G Sku)

    GPS Function Test Failure (3G SKU) If the GPS function test fails, perform the following: Start Check the 3G Swap the 3G Aux antenna Aux antenna Check the Swap the 3G card 3G card Swap M/B Figure 4-14. GPS Function Test Failure 4-17 Troubleshooting...

  • Page 116: Docking Station Test Failure

    Docking Station Test Failure If the docking station test fails, perform the following: Start Check the Docking/B Swap the Docking/B to M/B FFC to M/B FFC Check the Swap the Docking/B Docking/B Swap M/B Figure 4-15. Docking Station Test Failure 4-18 Troubleshooting...

  • Page 117: Other Functions Failure

    Other Functions Failure 1. Check component connection to mainboard. 2. To test for mainboard fault, swap mainboard. 4-19 Troubleshooting...
  • Page 118 4-20 Troubleshooting...
  • Page 119 CHAPTER Jumper and Connector Locations...
  • Page 120 Mainboard ......... . 5-3...

  • Page 121: Jumper And Connector Locations

    Jumper and Connector Locations Mainboard SW3 U135 LED3 VB1 JLINE1 JP67 JMIN2 JHDMI1 Figure 5-1. Mainboard Top Table 5-1. Mainboard Top Item Description Item Description LED3 Power / Battery LED Micro SD connector Vibrator JMIN2 3G connector SW2, SW3 Volume key Power button U135 Light sensor...
  • Page 122 PJP3 JP58 JMIC4 PJP2 JMIC3 ANT5 U146 JP14 ANT3 JLVDS3 JP12 U132 JP68 JP55 JP57 JP69 Figure 5-2. Mainboard Bottom Table 5-2. Mainboard Bottom Item Description Item Description U146 P-sensor JP55 Speaker connector Flash LED U132 E-compass ANT5 WIFI Antenna JP12 Docking connector JP58...

  • Page 123: Field Replaceable Unit List

    CHAPTER Field Replaceable Unit List...
  • Page 124 Exploded Diagrams ........6-4 Main Assembly ........6-4 FRU List .

  • Page 125: Fru List

    Guide. For Acer Authorized Service Providers, the Acer office may have a different part number code from those given in the FRU list of this printed Service Guide. Users MUST use the local FRU list provided by the regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 126: Exploded Diagrams

    Exploded Diagrams Main Assembly Figure 6-1. Main Assembly with 3G Exploded Diagram FRU List...
  • Page 127 Table 6-1. Main Assembly (3G) Exploded Diagram Description LOWER CASE INCL. CAMERA GLASS FOR 3G 60.H6002.001 USB SUPPORT PLATE 33.H6002.002 USB BOARD 55.H6002.002 BATTERY BT.00207.001 MAINBOARD MB.70500.041 ANTENNA 3G-AUX 50.H6002.007 ANTENNA WLAN 50.H6002.005 DC-IN CABLE 50.H6002.001 LCD SUPPORT PLATE FOR 3G 33.H6M02.001 LCD BEZEL TOUCH PANEL CABLE...

  • Page 128: Fru List

    Figure 6-2. Main Assembly without 3G Exploded Diagram FRU List...
  • Page 129 Table 6-2. Main Assembly without 3G Exploded Diagram Description LOWER CASE INCL. CAMERA GLASS FOR 3G 60.H6002.001 USB SUPPORT PLATE 33.H6002.002 USB BOARD 55.H6002.002 BATTERY BT.00207.001 MAINBOARD MB.70500.041 ANTENNA WLAN 50.H6002.005 DC-IN CABLE 50.H6002.001 LCD SUPPORT PLATE FOR W/O 3G 33.H6002.001 LCD BEZEL TOUCH PANEL CABLE...

  • Page 130: Fru List

    FRU List Table 6-3. FRU List CATEGORY Description Adapter Adapter PHIHONG 18W 12V/1.5A Black AP.0180P.002 PSA18R-120P(AI)-R LF Battery Battery SIMPLO BAT-1010 Polymer 2S1P LGC 2 Cell BT.00207.001 3260mAh Main COMMON BAT-1010 Battery SANYO BAT-1010 Polymer 2S1P SANYO 2 Cell BT.00203.002 3260mAh Main COMMON BOARD DOCKING BOARD...
  • Page 131 Table 6-3. FRU List (Continued) CATEGORY Description TOUCH PANEL CABLE 50.H6002.004 EXTERNAL HDMI CABLE XZ.70200.117 EXTERNAL USB CABLE XZ.70200.115 AC CLIP 18W -EU 27.L0302.001 AC CLIP 18W -US 27.L0302.002 AC CLIP 18W -CN 27.L0302.003 AC CLIP 18W -UK 27.H6002.001 AC CLIP 18W -AU 27.H6002.002 ANTENNA WLAN 50.H6002.005...
  • Page 132 Table 6-3. FRU List (Continued) CATEGORY Description DIGITAL LIGHT DEVICE CAMERA 2M 57.H6002.001 CAMERA 5M 57.H6002.002 IC Elpida Memory 168b PoP EDB8132B2PB-6D-F 40nm IC.0800E.001 IC Hynix Memory H8TJR00X0MLR-0YM 44nm IC.0080H.002 eMMC SanDisk Memory eMMC SDIN4C2-16G 32nm IC.0160B.001 IC SanDisk Memory SDIN4E2-32G 43nm IC.0320B.001 ASSY LCD TOUCH MODULE 10.1 FOR WIFI 6M.H6002.001...
  • Page 133 Table 6-3. FRU List (Continued) CATEGORY Description LCD PANEL CONDUCTIVE TAPE 47.H6002.003 ANTI-TEAR LABEL 47.H6002.004 SPEAKER MIC SET 23.H6002.001 SPEAKER L+R 23.H6002.002 6-11 FRU List...

  • Page 134: Screw List

    Screw List Table 6-4. Screw List Category Description SCREWS SCREW 2.0D 3.0L K 4.6D ZK NL CR3 86.H6002.002 SCREW 2D 4.0L K 4.6D NI NL 86.H6002.001 6-12 FRU List...
  • Page 135 CHAPTER Model Definition and Configuration...
  • Page 136 A500 ..........7-3 A501 .
  • Page 137 Model Definition and Configuration A500 Table 7-1. RO & Description Model Country Description A500 AU/NZ XE.H60AN.010 A500 Tablet None AAP_GEN4 AndroidAU-Tab-1 AU- Silver WiFi Only_16G A500 AU/NZ XE.H60AN.012 A500 Tablet None EMEA_GEN1 AndroidAU-Tab-1 AU- Silver Sample ONLY N A500 AU/NZ XE.H6LAN.010 A500 Tablet None AAP_GEN4 AndroidAU-Tab-1 AU- Silver WiFi Only_32G...
  • Page 138 Table 7-1. RO & Description (Continued) Model Country Description A500 XE.H6LCN.001 CHINA A500 Tablet None AAP_GEN4TW AndroidHK-Tab-1 UK- Silver WiFi Only_32G A500 XE.H60AN.002 A500 Tablet None AAP_GEN4 AndroidID-Tab-1 EU- Silver WiFi Only_16G N A500 XE.H6LAN.001 A500 Tablet None AAP_GEN4 AndroidID-Tab-1 EU- Silver WiFi Only_32G N A500 XE.H60AN.001 A500 Tablet None AAP_GEN4...
  • Page 139 Table 7-1. RO & Description (Continued) Model Country Description A500 XE.H6LEN.011 EMEA A500 Tablet EMEA_GEN6 AndroidPL EU- Silver WiFi Only_32G A500 XE.H60EN.011 EMEA A500 Tablet EMEA_GEN3 AndroidRU-8 EU- Silver WiFi Only_16G A500 XE.H6LEN.012 EMEA A500 Tablet EMEA_GEN3 AndroidRU-8 EU- Silver WiFi Only_32G A500 XE.H60AN.005 A500 Tablet None AAP_GEN4...
  • Page 140 Table 7-1. RO & Description (Continued) Model Country Description A500 West EU-1 XE.H60EN.004 EMEA A500 Tablet EMEA_GEN3 AndroidWEU5 EU- Silver WiFi only_16G A500 West EU-1 XE.H6LEN.001 EMEA A500 Tablet EMEA_GEN1 AndroidWEU3 EU- Silver WiFi only_32G A500 West EU-1 XE.H6LEN.003 EMEA A500 Tablet EMEA_GEN3 AndroidWEU4 EU- Silver WiFi only_32G A500...
  • Page 141 Table 7-2. BOM Name, CPU & LCD1 (Continued) Model Country BOM Name LCD1 A500 MOYO XE.H6LEN.006 A500_32s NV-TEGRA250 H10.1WXGA w/TP A500 XE.H60PN.004 A500_16s NV-TEGRA250 H10.1WXGA w/TP A500 XE.H6LPN.004 A500_32s NV-TEGRA250 H10.1WXGA w/TP A500 XE.H60AN.003 A500_16s NV-TEGRA250 H10.1WXGA w/TP A500 XE.H6LAN.002 A500_32s NV-TEGRA250 H10.1WXGA w/TP...

  • Page 142: A500 Pl Xe.h6Len.011

    Table 7-3. Memory1, Communication & Front Camera Model Country Memory1 Communication Front Camera A500 AU/NZ XE.H60AN.010 eMMC16GB WiFi Camera Module A500 AU/NZ XE.H60AN.012 eMMC16GB WiFi Camera Module A500 AU/NZ XE.H6LAN.010 eMMC32GB WiFi Camera Module A500 XE.H60EN.006 eMMC16GB WiFi Camera Module A500 XE.H6LEN.007 eMMC32GB...
  • Page 143 Table 7-3. Memory1, Communication & Front Camera (Continued) Model Country Memory1 Communication Front Camera A500 XE.H6LAN.004 eMMC32GB WiFi Camera Module A500 XE.H60AN.006 eMMC16GB WiFi Camera Module A500 XE.H6LAN.005 eMMC32GB WiFi Camera Module A500 XE.H60EN.012 eMMC16GB WiFi Camera Module A500 XE.H6LEN.009 eMMC32GB WiFi Camera Module...
  • Page 144 Table 7-4. Main Camera1, Battery & Adapter (Continued) Model Country Main Camera1 Battery Adapter A500 GCTWN XE.H6LTN.001 Camera Module 2CELL3.26 A500 XE.H60CN.001 Camera Module 2CELL3.26 A500 XE.H6LCN.001 Camera Module 2CELL3.26 A500 XE.H60AN.002 Camera Module 2CELL3.26 A500 XE.H6LAN.001 Camera Module 2CELL3.26 A500 XE.H60AN.001 Camera Module...

  • Page 145: A500 West

    Table 7-4. Main Camera1, Battery & Adapter (Continued) Model Country Main Camera1 Battery Adapter A500 West EU-1 XE.H60EN.001 Camera Module 2CELL3.26 A500 West EU-1 XE.H60EN.002 Camera Module 2CELL3.26 A500 West EU-1 XE.H60EN.004 Camera Module 2CELL3.26 A500 West EU-1 XE.H6LEN.001 Camera Module 2CELL3.26 A500 West EU-1...
  • Page 146 A501 Table 7-5. RO & Description Model Country Description A501 AU/NZ XE.H6MAN.008 A501 Tablet 900 AAP_GEN4 AndroidAU-Tab-1 AU- Silver EM770W_16G A501 AU/NZ XE.H6NAN.008 A501 Tablet 900 AAP_GEN4 AndroidAU-Tab-1 AU- Silver EM770W_32G A501 AU/NZ XE.H6PAN.005 A501 Tablet 3G AAP_GEN4 AndroidAU-Tab-1 AU- Silver F5521gw_16G A501 AU/NZ XE.H6QAN.005...

  • Page 147: Emea

    Table 7-5. RO & Description (Continued) Model Country Description A501 XE.H6MAN.002 A501 Tablet 900 AAP_GEN4 AndroidID-Tab-1 EU- Silver EM770W_16G N A501 XE.H6NAN.002 A501 Tablet 900 AAP_GEN4 AndroidID-Tab-1 EU- Silver EM770W_32G N A501 XE.H6MAN.001 A501 Tablet 900 AAP_GEN4 AndroidIN-Tab-1 EU- Silver EM770W_16G N A501 XE.H6NAN.001 A501 Tablet 900 AAP_GEN4...
  • Page 148 Table 7-5. RO & Description (Continued) Model Country Description A501 XE.H6MAN.004 A501 Tablet 900 AAP_GEN4 AndroidPH-Tab-1 US- Silver EM770W_16G A501 XE.H6NAN.004 A501 Tablet 900 AAP_GEN4 AndroidPH-Tab-1 US- Silver EM770W_32G A501 XE.H6MEN.012 EMEA A501 Tablet EMEA_GEN6 AndroidPL EU- Silver EM770W_16G A501 XE.H6NEN.011 EMEA A501 Tablet EMEA_GEN6 AndroidPL EU-...
  • Page 149 Table 7-5. RO & Description (Continued) Model Country Description A501 XE.H6NEN.009 EMEA A501 Tablet EMEA_CUS5TR AndroidTR-4 EU- Silver EM770W_32G A501 XE.H6PEN.009 EMEA A501 Tablet EMEA_CUS5TR AndroidTR-4 EU- Silver F5521gw_16G A501 XE.H6QEN.009 EMEA A501 Tablet EMEA_CUS5TR AndroidTR-4 EU- Silver F5521gw_32G A501 XE.H6MEN.007 EMEA A501 Tablet EMEA_GEN1 AndroidGB-5 UK-...
  • Page 150 Table 7-5. RO & Description (Continued) Model Country Description A501 West EU-1 XE.H6PEN.003 EMEA A501 Tablet EMEA_GEN3 AndroidWEU4 EU- Silver F5521gw_16G A501 West EU-1 XE.H6PEN.004 EMEA A501 Tablet EMEA_GEN3 AndroidWEU5 EU- Silver F5521gw_16G A501 West EU-1 XE.H6QEN.001 EMEA A501 Tablet EMEA_GEN3 AndroidWEU5 EU- Silver F5521gw_32G A501 West EU-1...
  • Page 151 Table 7-6. BOM Name & CPU (Continued) Model Country BOM Name A501 XE.H6NAN.002 A501_32s900770W NV-TEGRA250 A501 XE.H6MAN.001 A501_16s900770W NV-TEGRA250 A501 XE.H6NAN.001 A501_32s900770W NV-TEGRA250 A501 XE.H6MEN.001 A501_16s900770W NV-TEGRA250 A501 XE.H6NEN.002 A501_32s900770W NV-TEGRA250 A501 XE.H6PEN.001 A501_16s3G5521GW NV-TEGRA250 A501 XE.H6QEN.003 A501_32s3G5521GW NV-TEGRA250 A501 MOYO XE.H6MEN.010 A501_16s900770W...
  • Page 152 Table 7-6. BOM Name & CPU (Continued) Model Country BOM Name A501 XE.H6PEN.009 A501_16s3G5521GW NV-TEGRA250 A501 XE.H6QEN.009 A501_32s3G5521GW NV-TEGRA250 A501 XE.H6MEN.007 A501_16s900770W NV-TEGRA250 A501 XE.H6NEN.006 A501_32s900770W NV-TEGRA250 A501 XE.H6PEN.012 A501_16s3G5521GW NV-TEGRA250 A501 XE.H6QEN.006 A501_32s3G5521GW NV-TEGRA250 A501 XE.H6PPN.003 A501_16s3G5521GW NV-TEGRA250 A501 XE.H6QPN.003 A501_32s3G5521GW NV-TEGRA250...
  • Page 153 Table 7-7. LCD1, Memory1 & Communication (Continued) Model Country LCD1 Memory1 Communication A501 AU/NZ XE.H6QAN.005 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6MEN.006 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6NEN.005 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6PEN.011 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6QEN.005 H10.1WXGA w/TP eMMC32GB HSUPA A501...
  • Page 154 Table 7-7. LCD1, Memory1 & Communication (Continued) Model Country LCD1 Memory1 Communication A501 XE.H6MEN.008 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6NEN.007 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6PEN.007 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6QEN.007 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6MAN.005 H10.1WXGA w/TP eMMC16GB HSUPA A501...
  • Page 155 Table 7-7. LCD1, Memory1 & Communication (Continued) Model Country LCD1 Memory1 Communication A501 West EU-1 XE.H6QEN.004 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6MEN.005 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6NEN.008 H10.1WXGA w/TP eMMC32GB HSUPA A501 XE.H6PEN.008 H10.1WXGA w/TP eMMC16GB HSUPA A501 XE.H6QEN.008 H10.1WXGA w/TP eMMC32GB HSUPA...
  • Page 156 Table 7-8. Front Camera & Main Camera1 (Continued) Model Country Front Camera Main Camera1 A501 MOYO XE.H6PEN.010 Camera Module Camera Module A501 MOYO XE.H6QEN.010 Camera Module Camera Module A501 XE.H6MAN.003 Camera Module Camera Module A501 XE.H6NAN.003 Camera Module Camera Module A501 XE.H6PAN.001 Camera Module...
  • Page 157 Table 7-8. Front Camera & Main Camera1 (Continued) Model Country Front Camera Main Camera1 A501 XE.H6NAN.007 Camera Module Camera Module A501 West EU-1 XE.H6MEN.002 Camera Module Camera Module A501 West EU-1 XE.H6MEN.003 Camera Module Camera Module A501 West EU-1 XE.H6MEN.004 Camera Module Camera Module A501...
  • Page 158 Table 7-9. Battery & Adapter (Continued) Model Country Battery Adapter A501 XE.H6MCN.001 2CELL3.26 A501 XE.H6NCN.001 2CELL3.26 A501 XE.H6MAN.002 2CELL3.26 A501 XE.H6NAN.002 2CELL3.26 A501 XE.H6MAN.001 2CELL3.26 A501 XE.H6NAN.001 2CELL3.26 A501 XE.H6MEN.001 2CELL3.26 A501 XE.H6NEN.002 2CELL3.26 A501 XE.H6PEN.001 2CELL3.26 A501 XE.H6QEN.003 2CELL3.26 A501 MOYO XE.H6MEN.010...
  • Page 159 Table 7-9. Battery & Adapter (Continued) Model Country Battery Adapter A501 XE.H6NAN.006 2CELL3.26 A501 XE.H6MEN.009 2CELL3.26 A501 XE.H6NEN.009 2CELL3.26 A501 XE.H6PEN.009 2CELL3.26 A501 XE.H6QEN.009 2CELL3.26 A501 XE.H6MEN.007 2CELL3.26 A501 XE.H6NEN.006 2CELL3.26 A501 XE.H6PEN.012 2CELL3.26 A501 XE.H6QEN.006 2CELL3.26 A501 XE.H6PPN.003 2CELL3.26 A501 XE.H6QPN.003 2CELL3.26...
  • Page 160 7-26 Model Definition and Configuration...
  • Page 161 CHAPTER Test Compatible Components...

  • Page 162: Android Os Environment Test

    Android OS Environment Test......8-4 ICONIA Tablet A500/501 ......8-4...
  • Page 163 Test Compatible Components This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system functions are tested under Android OS environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.

  • Page 164: Description

    Huawei Accessory 10001012 Dust proof Bag Acer Picasso Dust proof bag XZ.70200.116 COMPAL 10001012 HDMI Cable 1.5 Picasso / VanGogh HDMI Cable 1.5 XZ.70200.117 COMPAL meter, non-shielded meter, non-shielded Accessory 10001012 Micro USB cable Acer Micro USB cable Micro USB XZ.70200.115...
  • Page 165 Table 8-1. ICONIA Tablet A500/501 (Continued) Vendor Type Description 60001915 NV-TEGRA250 HH CPU nVidia Tegra 250 BGA 664 CU.25007.001 NVIDIA 1GHz Front Camera 10001044 Camera Module Camera Module CHICONY 2M FF QM.02M06.001 CHICONY CBFA233 FPC Micro SOC2031 MIPI 60003316 H10.1WXGA w/TP LED LCD AUO 10.1'' WXGA Glare LK.10105.008 B101EW05 0A LF 300nit 25ms w/TP...
  • Page 166 Test Compatible Components...
  • Page 167 CHAPTER Online Support Information...
  • Page 168 Introduction ......... 9-3...

  • Page 169: Online Support Information

    This section describes online technical support services available to help users repair their Acer Systems. For distributors, dealers, ASP or TPM, please refer the technical queries to a local Acer branch office. Acer Branch Offices and Regional Business Units may access our website.
  • Page 170 Online Support Information...

Table of Contents
