Epson Stylus Pro 4000 Print Engine Specifications
Printing Method
8 Channel Print Head Technology
Using:
7-colors (CcMmYk + PK or Mk)
Variable Droplet Micro Piezo DX3 drop-on-demand
ink jet technology
Epson UltraChrome pigmented ink technology
Nozzle Configuration
Color and Monochrome heads: 180 nozzles x 8
Black Ink Mode Configurations
7-color Print Mode:
Photo-K or Matte-K + Light-K
Photo-K and Matte-K inks automatically switch
depending upon media selection within printer driver
Droplet Technology
Smallest droplet size:
3.5 picoliter
Variable Droplet Technology can produce various
droplet sizes per print line
Resolution
2880 x 1440 dpi; 1440 x 720 dpi; 720 x 720 dpi;
720 x 360 dpi; 360 x 360 dpi; 360 x 180 dpi
Print Engine Speed
A
Letter prints from 50 secs to 9:30 – 1440 dpi is 3:40
13" x 19" prints from 1:44 to 18:44 – 1440 dpi is 7:49
Acoustic Noise Level
Approximately 50 dB(A) according to ISO 7779
Printer Language/Drivers
Epson ESC/P2 Raster Photographic Drivers standard
Supported by most leading third-party RIPs and workflows
Operating Systems Supported
Macintosh
®
OS 8.5.1 through OS X
Windows
®
95, 98, Me, NT 4.x (Service Pack 3
and later), 2000, and XP
Printer Interfaces
Includes one USB (1. 1 /2.0 compatible),
one IEEE 1394 (FireWire) and one Epson
Expansion Slot used for installing the optional
internal 10/100 BaseT Ethernet card
Dimensions
33.4" (W) x 14" (H) x 30" (D)
Printer weight: 83.7 lb
BorderFree Printing
Left and right borderless "bleed" printing
for the following media widths:
8", 8.5", 10", 12", 13", 14", 16", 17"
Top and bottom edges can be automatically cut to any
length three different ways during printing on roll media
Epson America, Inc.: 3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Inc.: 3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Epson Latin America Inc.: 6303 Blue Lagoon Drive, Suite 195, Miami, FL 33126
Internet Website: www.prographics.epson.com
Printable Area
Maximum paper width
17"
Left and right margins
0 or 3mm each (0.24" total)
Top and bottom margins
0 or 3mm or 14mm each
Maximum printable width
17.16"
Maximum printable length
Up to 100' (limited by roll length)
(limited by software application)
Media Handling
Roll media size
Single roll up to 17" width
Roll media length
Up to 132' (limited by core dia.)
Cut sheet input tray size
Up to 17"x 22"
Cut sheet media input
Up to 250 sheet tray, top and
rear manual feed slots
Media core compatibility
Handles both 2" and 3" cored media
Max. roll media diameter
4" (2" core) or 6" (3" core)
Weight
12 lb bond up to 1.5mm cardboard
Built-in media cutter
Automatic and manual cutting
Line Accuracy
+ or – 0.2% of specified page length
Epson Intelligent Ink Cartridge
Ink cartridge size
110ml or 220ml
each color x 8 colors total
Ink cartridge shelf life
2 years from printed production
date or 6 months after open
On cartridge I.C. chip automatically tracks several ink
usage data points for use in very accurate production
cost estimations and reporting
Lightfastness Ratings
B
Epson UltraChrome Ink
Color:
Up to 108 years
B&W:
Over 100 years
Environmental Characteristics
Temperature operating
50˚ to 95˚ F (10˚ to 35˚ C)
Storage
-4˚ to 104˚ F (-20˚ to 40˚ C)
Humidity operating
20 to 80% relative humidity
Storage
5 to 85% relative humidity
(no condensation)
Safety Approval
Safety standards
UL1950, CSA 22.2 950 FDA
EMI
FCC Part 15 subpart B class B,
CSA
C108.8 class B
AS/NZS 3548 class B
Engine Reliability
Total print volume
~20,000 A2 pages at 360 x 360 dpi
Print head life
8.4 billion shots per nozzle
Cutter life
~2,000 times (coated media)
Maintenance parts
Pump unit, flushing box, RTC battery,
head cleaner, cap assembly
Electrical Requirements
Voltage
AC120V or (220V to 240V)
Frequency
50 to 60 Hz
Current
1.0A / 100-120V
Power consumption
Approx. 59W (operating)
< 21W (standby)
< .7W (power off mode)
Energy Star compliant
Specifications and terms are subject to change without notice. Epson, Epson Stylus and Micro Piezo are registered
trademarks of Seiko Epson Corporation. UltraChrome, BorderFree and DX3 are trademarks of Epson America, Inc.
All other product brand names are trademarks and/or registered trademarks of their respective companies. Epson
disclaims any and all rights in these marks.
© Epson America, Inc. 2003. CPD -16025R1 35K 5/04 GAC
Product/Accessories
Epson Stylus Pro 4000 Print Engine
Epson Stylus Pro 4000 Graphic Arts Bundle
Epson Stylus Pro 4000
Printer Cabinet Stand
Internal 10/100 BaseT
Ethernet Type-B Card
Paper Roller Spindle
(Normal Tension) – 2"or 3"
Paper Roller Spindle
(High Tension) – 2"or 3"
Replacement Printer
Cutter Blade
Replacement
Ink Maintenance Tank
Additional One-year Epson
Preferred Plus Service
Additional Two-year Epson
Preferred Plus Service
Epson UltraChrome Ink
(110ml)
Photo Black ink cartridge
T543100
Cyan ink cartridge
T543200
Magenta ink cartridge
T543300
Yellow ink cartridge
T543400
Light Cyan ink cartridge
T543500
Light Magenta ink cartridge
T543600
Light Black ink cartridge
T543700
Matte Black ink cartridge
T543800
Based upon print engine speed only. Total throughput times depend upon front-end RIP, file size,
A
printer resolution, ink coverage, networking, etc.
Ink lightfastness rating based on accelerated testing of prints on specialty media, displayed indoors,
B
under glass. Actual print stability will vary according to media, printed image, display conditions,
light intensity, humidity, and atmospheric conditions. Epson does not guarantee longevity of prints.
For maximum print life, display all prints under glass or lamination or properly store them.
Visit www.wilhelm-research.com for the latest information.
TM
Part Numbers
C511001UCM
C511001GAN
C4000STAND
C12C824052
C12C811171
C12C811191
C12C815291
C12C890071
EPP40EX1
EPP40EX2
(220ml)
T544100
T544200
T544300
T544400
T544500
T544600
T544700
T544800
