  • Page 1: Epson Stylus Pro

    EPSON ® Epson Stylus Pro 4800 ® QUICK REFERENCE GUIDE...

  • Page 2: Loading Roll Paper

    firmly into the end of the roll. Open the roll paper cover. Place the roll paper in the printer as shown. (The black end of the spindle goes on the left.) Make sure the printer is turned on, then press the Paper Source button until the appears.

  • Page 3: Loading Paper In The Tray

    Loading Paper in the Tray Loading Paper in the Tray Make sure the printer is on and roll paper is not loaded for printing. Pull out the paper tray and cover. Lift up the paper tray cover. Flip up the paper guide roller and slide the edge guide all the way to the left.

  • Page 4: Loading Paper Manually

    Extend the paper tray and cover to support the sheet as it comes out of the printer. Make sure the roll paper support is not raised. Align paper with line...

  • Page 5: Checking And Aligning The Print Head

    3sec. Press the Menu button again so that *STD appears on the display. This is the correct thickness setting for most Epson papers, including Enhanced Matte Paper and Premium Luster Photo Paper. Press the Menu button to register the value, then press the button to display PAPER THKNS again.

  • Page 6: Checking Ink Levels

    Matte Black T543800 When one of the indicators shows empty and INK OUT is displayed on the LCD panel, the cartridge is empty. To replace the cartridge, first make sure the printer is on. Menu (empty) 8 Light Light Black...

  • Page 7: Replacing The Cutter Blade

    E*****F indicates a new cutter. If no stars are displayed, the cutter needs to be replaced. Caution: Do not use the cutter for the following media: • Fine art paper (such as Epson UltraSmooth™ , Textured, or Velvet) • Canvas • Backlight film •...

  • Page 8: Replacing The Maintenance Tank

    Replacing Printer Parts (continued) Replacing Printer Parts (continued) Hold down the side pin, as shown, then turn the latch to the right. Release the side pin and carefully remove the cutter blade. Insert the new cutter blade. Hold down its side pin and secure it with the latch.

  • Page 9: Control Panel Messages

    Pause light on PLEASE WAIT Pause light flashing PAUSE Pause light on CUTTING CHARGING INK Error messages For a complete list of error messages, see your Printer Guide. Message Light Ink light flashing INK LOW Ink light on INK OUT CHANGE PAPER...

  • Page 10: Where To Get Help

    World Wide Web Support for non-Epson RIP Epson and Epson Stylus are registered trademarks of Seiko Epson Corporation. Epson UltraChromeK3 and UltraSmooth are trademarks and Epson Preferred is a service mark of Epson America, Inc. © 2005 Epson America, Inc.
  • Page 11 Power button Pause light and button Ink light Hold for 3 seconds to cancel a print job or reset the printer. Left arrow or Paper Source button Down arrow button Hold for 3 seconds to cut roll paper after printing.
