- Page 1 Owner’s Manual ATTENTION: Please read the content of your owner’s manual before operating your scooter. The Ultimate In Style & Performance ® Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
- Page 2 WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. CAUTION! Failure to heed the cautions in this owner’s manual may result in damage to your scooter. Copyright © 2002 Pride Mobility Products Corp. INFMANU1754/REV B/JULY 2002 Revo Sport...
-
Page 3: Table Of Contents
C O N T E N T S INTRODUCTION ......................... 4 SAFETY ............................6 III. EMI/RFI ............................15 IV. SPECIFICATIONS ........................17 YOUR REVO SPORT ....................... 19 VI. BATTERIES AND CHARGING .................... 23 VII. OPERATION ..........................27 VIII. COMFORT ADJUSTMENTS....................29 IX. DISASSEMBLY AND ASSEMBLY ..................31 OPTIONAL ACCESSORIES .................... -
Page 4: Introduction
I N T R O D U C T I O N Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride Scooter. Your scooter design combines the most advanced state-of-the-art components with modern, attractive styling. -
Page 5: I. Introduction
Quick Reference Information: Scooter Model:________________________________________________________________________ Serial Number:__________________________________________________________________________ Purchase Date:________________________________________________________________________ NOTE: If you ever lose or misplace your warranty card or this owner’s manual, write or e-mail us and we will be glad to send you a new one immediately. Revo Sport... - Page 6 Revo Sport safely. MODIFICATIONS Pride has designed and engineered your Revo Sport to provide maximum mobility and utility. A wide range of accessories is available from your Pride provider to further customize your scooter to better suit your needs and/ or preferences.
-
Page 7: Ii. Safety
PRE-RIDE SAFETY CHECK Get to know the feel of your Revo Sport and its capabilities. Pride recommends that you perform a safety check before each use to make sure your scooter operates smoothly and safely. For details on how to perform these necessary inspections, see XII. - Page 8 Revo Sport’s stability and its ability to climb grades under various weight loads and under controlled testing conditions. These tests were conducted with the Revo Sport’s seat in the highest position and adjusted backward on the seat base to its farthest rearward position. Use this information as a guideline. Your Revo Sport’s ability to travel up inclines is affected by your weight, your scooter’s speed, your angle of approach to the incline, and your scooter...
-
Page 9: Cornering Information
When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of gravity of you and your Revo Sport toward the front of the scooter for improved stability. WARNING! Do not exceed recommended linclines, weight limits, or any specifications presented in this manual. -
Page 10: Braking Information
WARNING! Be sure your scooter is traveling perpendicular to any curb you may be required to ascend or descend. See figures 3 and 3A. WARNING! Do not attempt to negotiate a curb that has a height greater than two inches. FIGURE 3. CORRECT CURB APPROACH FIGURE 3A. INCORRECT CURB APPROACH Revo Sport... -
Page 11: Safety
Your scooter is equipped with a manual freewheel lever that when pulled up allows the scooter to be pushed. For more information about how to place your scooter into and out of freewheel mode, see V. “Your Revo Sport.” WARNING! Do not use your scooter in freewheel mode without an attendant present. Personal injury may result. -
Page 12: Tire Inflation
Proper inflation pressures will prolong the life of your tires and help ensure the smooth operation of your scooter. Do not exceed 35 psi in your Revo Sport tires. WARNING! It is critically important that pneumatic tires be inflated to 30-35 psi. Do not underinflate or overinflate your tires. -
Page 13: Preventing Unintended Movement
Power down your scooter. See VII. “Operation.” n Ensure that your scooter is not in freewheel mode. See V. “Your Revo Sport.” n Make certain that the seat is locked into place and the key is removed from the key switch. -
Page 14: Positioning Belts
WARNING! Do not operate your scooter while you are under the influence of alcohol, as this may impair your ability to drive safely. REMOVABLE PARTS WARNING! Do not attempt to lift or move a scooter by any of its removable parts. Personal injury and damage to the scooter may result. Revo Sport... - Page 15 Has anyone been injured by the erratic, unintended motion of an electric mobility vehicle? The FDA has reports of injuries that resulted from uncontrolled motion of electric mobility vehicles, but it is not clear just how many of those injuries were actually caused by EMI/RFI. Revo Sport...
-
Page 16: Iii. Emi/Rfi
If unintended motion or unintended brake release occurs, turn off your mobility vehicle (by removing the key) as soon as it is safe to do so. If my mobility vehicle moves unintentionally, where should I report the incident? Call the Pride Technical Service Department at 1-800-800-8586 to report the incident. Revo Sport... - Page 17 I V . S P E C I F I C A T I O N S 12" 8" 80˚ 15.5" - 17.5" 2.5" FIGURE 4. REVO SPORT DIMENSIONS 17" 16" 22"- 29" 38" Turning Radius 22" Revo Sport...
-
Page 18: Specifications
Single cane/crutch holder; double cane/crutch holder; walker holder; forearm crutch holder; oxygen tank holder; rear basket; front basket; cup holder; safety flag; dust cover * Varies with user weight, terrain type, battery charge, battery condition, and tire pressure Revo Sport... -
Page 19: Your Revo Sport
Use your right thumb to push the right side of the lever to disengage your Revo Sport’s brakes and move forward. n Release the lever and allow your Revo Sport to come to a complete stop before pushing the other side of the lever to move in reverse. - Page 20 Do not press the Turbo button while driving on inclines of any type. Do not press the Turbo button while driving on uneven, bumpy terrain. Release the Turbo button before entering a turn, an incline, or uneven terrain of any type. Revo Sport...
- Page 21 The scooter is equipped with an easy to remove self-contained battery/charger pack. The pack contains every- thing necessary to charge and monitor the charging of the Revo Sport’s batteries, including the charger power cord receptacle, the ammeter, the main circuit breaker (reset button), and the batteries. See figure 6.
- Page 22 See figures 7 and 8. WARNING! Before placing your Revo Sport into or taking it out of freewheel mode, make certain that the key is removed from the key switch. Never sit on a scooter when it is in freewheel mode.
-
Page 23: Charging Your Batteries
V I . B A T T E R I E S A N D C H A R G I N G Your Revo Sport is equipped with a battery/charger pack which includes two sealed, maintenance free 17 AH batteries. -
Page 24: Vi. Batteries And Charging
If you use your scooter daily, charge its batteries as soon as you finish using it for the day. Your scooter will be ready each morning to give you a full day of service. We recommend that you charge your Revo Sport’s batteries for 8 to 14 hours after daily use. - Page 25 It may take a few days for the temperature of your Revo Sport’s batteries to stabilize and adjust to their new room or ambient temperature.
-
Page 26: Battery Replacement
V I . B A T T E R I E S A N D C H A R G I N G REPLACING YOUR REVO SPORT’S BATTERIES BATTERY 1 Battery Removal Remove the battery/charger pack from the scooter. See the dis- assembly portion of IX. - Page 27 Is the key fully inserted into the key switch? See V. “Your Revo Sport.” n Is the speed adjustment dial set to a slow setting? See V. “Your Revo Sport.” n Are you grasping the handgrips with a thumb resting on each side of the throttle control lever? See V. “Your Revo Sport.”...
-
Page 28: Vii. Operation
2. Make certain that the key is removed from the key switch. 3. Pull up on the seat lock lever and rotate the seat until you are facing toward the side of your Revo Sport. 4. Make certain that the seat is locked securely in position. -
Page 29: Comfort Adjustments
Revo Sport. FRONT-TO-BACK SEAT ADJUSTMENT You can reposition the Revo Sport’s seat forward or rearward to one of three settings, thereby adjusting the distance between the seat and the tiller. See figure 16. 1. Remove the seat from your Revo Sport. Refer to IX. “Disassembly and Assembly.”... -
Page 30: Seat Height Adjustment
The seat can be repositioned to one of three different UPPER SEAT heights. See figure 17. POST ADJUSTMENT HOLES 1. Remove the seat from your Revo Sport. See IX. DETENT PIN “Disassembly and Assembly.” LOWER SEAT 2. Use the attached ring to pull and remove the de- POST tent pin from the lower seat post. - Page 31 Revo Sport take up more floor space than the assembled Revo Sport. You can disassemble the Revo Sport into three pieces: the seat, weighing 23 lbs., the frame, weighing 62 lbs., and the battery/charger pack, weighing 32 lbs. Place the scooter in an area where you have sufficient clearance to move the parts around.
-
Page 32: Disassembly And Assembly
When it is necessary for two people to lift the Revo Sport, refer to figure 24 for the proper lifting positions. WARNING! Before lifting the Revo Sport, make certain the tiller adjustment knob is fully tightened. Revo Sport... -
Page 33: Optional Accessories
For information concerning these optional accessories, see your authorized Pride provider. •SINGLE CANE/CRUTCH HOLDER • DOUBLE CANE/CRUTCH HOLDER • WALKER HOLDER • FOREARM CRUTCH HOLDER • OXYGEN TANK HOLDER • REAR BASKET • FRONT BASKET • SAFETY FLAG • CUP HOLDER • DUST COVER Revo Sport... -
Page 34: Basic Troubleshooting
Fully charge your Revo Sport’s batteries. See VI. “Batteries and Charging.” n Have your authorized Pride provider load test each battery. If you experience any problems with your Revo Sport that you are not able to solve, contact your authorized Pride provider for information, maintenance, and service. -
Page 35: Care And Maintenance
M A I N T E N A N C E Your Revo Sport requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you may schedule inspection and maintenance with your authorized Pride provider. - Page 36 Insert a new 24V, 5-watt bulb. n Replace the light cover. NOTE: Replacement light bulbs can be purchased from your authorized Pride provider. CAUTION! Do not use regular automotive-type 12-volt light bulbs; your scooter is equipped with a 24-volt electrical system. Revo Sport...
-
Page 37: Warranty Exclusions
Tires and tire tubes (wear items and not warranted) n Upholstery and seating (wear items and not warranted) n Repairs and/or modifications made to any part of the Revo Sport without specific and prior consent from Pride n Circumstances beyond the control of Pride... -
Page 38: Xiii. Warranty
Some states do not allow limitations on how long an implied warranty lasts or do not allow the exclusion of limitation of incidental or consequential damages. So, the above limitation or exclusion may not apply to you. Revo Sport...
