0970
Intrepid Multi Cover
1/01
Safety Notice: if thiS appliaNce iS Not properly iNStalled, operated aNd
maiNtaiNed, a houSe fire may reSult.
to reduce the riSk of fire, follow the iNStallatioN iNStructioNS. failure to
follow iNStructioNS may reSult iN property damage, bodily iNjury or eveN
death. coNtact local buildiNg officialS about reStrictioNS aNd iNStallatioN
iNSpectioN requiremeNtS iN your area.
do Not discard this manual: retain for future use
the intrepid
multi-fuel heater
model 1695ce
Homeowner's
Installation
and Operating
Manual
For use in Europe
2000970 1/10 Rev. 9
Advertisement
Related Manuals for Vermont Castings The Intrepid 1695CE
Summary of Contents for Vermont Castings The Intrepid 1695CE
- Page 1 the intrepid multi-fuel heater model 1695ce Homeowner’s Installation and Operating Manual For use in Europe 0970 Intrepid Multi Cover 1/01 Safety Notice: if thiS appliaNce iS Not properly iNStalled, operated aNd maiNtaiNed, a houSe fire may reSult. to reduce the riSk of fire, follow the iNStallatioN iNStructioNS. failure to follow iNStructioNS may reSult iN property damage, bodily iNjury or eveN death.
-
Page 2: Table Of Contents
At Vermont Castings, we are equally committed to your satisfaction as a customer and that is why we maintain an exclusive network of the finest dealers in the industry. Chosen for their expertise and dedication to cus- tomer service, our dealers are factory-trained and know each Vermont Castings products in detail. -
Page 3: Specifications
Vermont Castings Intrepid Multi-Fuel Specifications intrepid multi-fuel, model 1695ce, 1696ce, 1697ce Wood Smokeless Fuel Width (leg-to-leg) ........546 mm (21¹⁄₂”) Nominal heat output 7.5 kW 6.4kW Depth (leg-to-leg)........349 mm (13³⁄₄”) (25,500 BTU/hr) (21,750 BTU/hr) Height to top of flue collar:... -
Page 4: Installation
The metal label permanently attached to the back of chimney and chimney connector must be in good condi- every Vermont Castings stove indicates that the stove tion and kept clean. Figure 2 shows the two chimney has been tested to current standards. The test stan- types. - Page 5 Vermont Castings Intrepid Multi-Fuel connecting flue pipes masonry chimneys Connector pipes should meet the requirements of the An inspection of the chimney must confirm that it has building regulations. This can be achieved by the use a lining. Do not use an unlined chimney. The chimney...
- Page 6 Vermont Castings Intrepid Multi-Fuel These adaptors are designed so the top end will fit the stove and chimney. Using connectors and chim- outside the inner wall of the chimney, and the bottom neys from the same manufacturer makes the assembly end will fit inside the first section of chimney connector.
- Page 7 Vermont Castings Intrepid Multi-Fuel face of the flue liner, and cemented securely in place. fireplace chimney installations - Additional pieces of connector are then attached with through a fireplace sheet metal screws. If your fireplace height is at least 635 mm (25”), you...
- Page 8 Vermont Castings Intrepid Multi-Fuel Always adhere to local building codes when installing a wall pass-through. Figure 7 shows a method of passing a connector through a wall. All combustible material in the wall is cut away to provide the required clearance that is three times the pipe diameter.
- Page 9 Vermont Castings Intrepid Multi-Fuel Costructional Hearth Dimensions as below At least 150 mm or to a suitable heat resistant wall Appliance Appliance Doors Doors Hearth Surface Free of Com- At least bustible Material 150 mm Perimeter should be Perimeter should be clearly marked e.g.
- Page 10 Vermont Castings Intrepid Multi-Fuel connecting flue pipe - clearances Single wall connecting fluepipes can reach extremely high temperatures; therefore, clearances from the con- necting fluepipe (chimney connector) must comply with the requirements of Part J of Building Regulations 2000 (Combustion Appliances and Fuel Storage Systems).
-
Page 11: Assembly
Vermont Castings Intrepid Multi-Fuel assembly clean the griddle before use At the factory we coat the griddle with vegetable oil to prevent rusting while the stove is in transit and storage. 10³⁄₄" Remove the oil with a dry rag or paper towel before you use the stove. -
Page 12: Operation
Vermont Castings Intrepid Multi-Fuel attach the griddle handle Install the handle on the griddle. Place the griddle upside down at the edge of a flat surface and assemble the handle as shown. (Fig. 16) With the handle pointing 45° from its final position, tighten the nut as far as possible with pliers. - Page 13 Vermont Castings Intrepid Multi-Fuel Side view open (Updraft Mode) ST521a fig. 20 Top loading is the best way to add fuel during regular use. Front loading is useful for kindling a fire. ST521 Intrepid To open the front doors, insert the handle into the door loading latch stub and turn it to the left and up.
- Page 14 Vermont Castings Intrepid Multi-Fuel Burn only high quality wood or smokeless solid fuels in use the air control Settings the Intrepid Multi-Fuel, and burn it directly on the grate. that work best for you Do not elevate the fuel. No single air control setting will fit every situation. Set-...
- Page 15 Vermont Castings Intrepid Multi-Fuel Once the draft is established, open the front door and light the rest of the fuel from the bottom. Do not light the main bed of fuel until the chimney begins drawing, and repeat the procedure as often as necessary if the initial attempt is unsuccessful.
-
Page 16: Draft Management
Vermont Castings Intrepid Multi-Fuel draft management A stove is part of a system, which includes the chimney, be a disadvantage. Hot gases cool off through expansion; the operator, the fuel, and the home. The other parts of the if we vent a stove with a 152 mm (6”) flue collar [181 sq system will affect how well the stove works. - Page 17 Dry wood burns readily with a good chimney draft. But with stove. Vermont Castings dealers carry adapters to attach modern stoves, especially catalytic ones, the wood can be to the stove to connect an air duct for outdoor combustion too dry.
-
Page 18: Maintenance
2. Inspect the Gasket. If the window gasket is in good condition, you can leave it in place. If you replace it, use only a Vermont Castings gasket, part no. 1203556. Be sure the channel around the window opening is clean and free of dust. - Page 19 If you need to change a gasket, first obtain an appropri- tighten the damper handle as Needed Door Pawl ate replacement from your Vermont Castings Dealer. The damper handle is attached to the damper rod 11/00 with a set screw bearing against a flat spot on the rod.
- Page 20 Vermont Castings Intrepid Multi-Fuel Wait until the fire is out and the stove has cooled. Be 7. For doors, replace the doors and close them on sure to follow the standard safety procedure for working a piece of waxed paper to keep the cement from...
- Page 21 Vermont Castings Intrepid Multi-Fuel the chimney System annual maintenance Every spring, at the end of the heating season, perform creosote a thorough cleaning, inspection and repair. The stove Your Intrepid Multi-fuel is designed to reduce creosote and chimney system should be inspected and main- buildup significantly.
-
Page 22: Replacement Parts
Vermont Castings Intrepid Multi-Fuel 0970 MHSC reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. intrepid multi-fuel heater model 1695ce 0970 Intrepid Multi-fuel 1695 item description part Number... - Page 23 Vermont Castings Intrepid Multi-Fuel 0970 MHSC reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. intrepid multi-fuel heater 0970 model 1695ce (continued) Intrepid MultiFuel Model 1695 parts item description...
- Page 24 Vermont Castings Intrepid Multi-Fuel intrepid multi-fuel heater model 1695ce (continued) Shell enamel parts - intrepid multi-fuel 1. In the diagrams and throughout this manual, ‘left’ and model 1695ce ‘right’ mean as you face the stove. part Name classic green 2. The glass panels have a heat-reflective coating on the...
- Page 25 Vermont Castings Intrepid Multi-Fuel 2000970...
- Page 26 Vermont Castings Intrepid Multi-Fuel 2000970...
-
Page 27: Warranty
If a defect is noted within the warranty period, the customer should replacement catalyst under the terms of this limited warranty: contact a Vermont Castings Authorized Dealer or MHSC if the purchase 1. Name, address and telephone number. was direct with the following information: 2. - Page 28 mhSc 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
