the equipment. C01-Cover_B

BUSH HOG

2501 Griffin Ave.

Selma, AL 36703

334-874-2700

www.bushhog.com

OPERATOR'S MANUAL

the

Safety

3008 Series

Models 3008, 3008SH

Important

Operating

and Safety Instructions

are found in the Mower

Safety Video that can

and

be instantly accessed

the

internet

www.algqr.com/bve

ROTARY MOWER

Part No. 50043164C

at:

$0.00

Table of Contents

Summary of Contents for Bush Hog 3008SH

Page 1 3008 Series Models 3008, 3008SH ROTARY MOWER Published 07/12 Part No. 50043164C OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation Important Operating of this machine and must be and Safety Instructions maintained with the unit at all are found in the Mower times.
Page 3 In order to reduce accidents and enhance the safe operation of mowers, Bush Hog, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
Page 4 Bush Hog will provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual Requester Name:_________________________________Phone:___________________________...
Page 5 A Manual canister is provided on the implement where this manual can be properly stored. If you lose or damage this manual a free replacement manual can be obtained from an authorized Bush Hog dealer or by down loading the manual from the Bush Hog website www.bushhog.com...
Page 6 DEALER to CUSTOMER Pre-Delivery / Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable. Dealer should also inform the Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible) and of Purchaser’s responsibility to train his/her operators in safe operation procedures.
Page 7: Table Of Contents
Table of Contents SAFETY SECTION ..................1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES .................1-2 OPERATOR SAFETY ............................1-3 CONNECTION OR DISCONNECTING IMPLEMENT SAFETY ................1-4 CRUSHING HAZARDS ............................1-5 THROWN OBJECTS HAZARDS ........................1-6 RUN OVER HAZARDS ............................1-8 PTO ENTANGLEMENT HAZARDS ........................1-9 MOWER BLADE CONTACT HAZARDS ......................1-10 HIGH PRESSURE OIL LEAK HAZARDS ......................1-11 ELECTRICAL &...
Page 8 GETTING ON AND OFF THE TRACTOR ......................4-7 Boarding the Tractor ............................4-7 Dismounting the Tractor .............................4-8 STARTING THE TRACTOR ..........................4-9 CONNECTING THE MOWER TO THE TRACTOR ...................4-9 Connecting the Mower-Lift Type and Semi-Mount Type ..................4-10 3-Point Quick Hitch ............................4-10 Connecting Mower - Lift Type (Quick Hitch) ....................4-11 Safety Tow Chain .............................4-11 Connecting the Mower-Pull Type ........................4-12 SETTING THE MOWER ..........................4-13...
Page 9 BLADE CARRIER INSTALLATION ......................... 5-12 BLADE PAN TIMING ............................5-12 SLIP CLUTCH ..............................5-13 Slip Clutch Operation Check ..........................5-13 Slip Clutch Adjustment .............................5-13 STORAGE ...............................5-14 PROPER TORQUE FOR FASTENERS ......................5-14...
Page 12: General Safety Instructions And Practices
SAFETY GENERAL SAFETY INSTRUCTIONS AND PRACTICES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.
Page 13: Operator Safety
SAFETY OPERATOR SAFETY TO AVOID SERIOUS INJURY OR DEATH DO THE FOLLOWING: • READ, UNDERSTAND and FOLLOW Operator's Manual instructions, Warnings and Safety Messages. • WEAR SAFETY GLASSES, safety shoes, hard hat, hearing protection and gloves when operating or repairing equipment •...
Page 14: Connection Or Disconnecting Implement Safety
SAFETY CONNECTION OR DISCONNECTING IMPLEMENT SAFETY TO AVOID SERIOUS INJURY OR DEATH FROM BEING CRUSHED BY TRACTOR OR IMPLEMENT: WHEN BACKING tractor to implement hitch: • DO NOT ALLOW BYSTANDERS between tractor and implement BEFORE connecting and disconnecting implement hitch: •...
Page 15: Crushing Hazards
SAFETY CRUSHING HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR, EQUIPMENT RUN OVER, ROLLOVER AND CRUSHING BY FALLING WING OR IMPLEMENT: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS lock in up position. •...
Page 16: Thrown Objects Hazards
SAFETY THROWN OBJECTS HAZARDS ROTARY MOWERS CAN THROW OBJECTS 300 FEET OR MORE UNDER ADVERSE CONDITIONS. TO AVOID SERIOUS INJURY OR DEATH TO OPERATOR OR BYSTANDERS FROM THROWN OBJECTS: • KEEP bystanders 300 feet away STOP MOWING IF PASSERSBY ARE WITHIN 300 FEET UNLESS: •...
Page 17 SAFETY THROWN OBJECTS HAZARDS (CONTINUED) MOWER OPERATION: • DO NOT exceed mower's rated Cutting Capacity or cut non-vegetative material. • USE ENCLOSED TRACTOR CABS when two or more mowers are operating in mowing area. • ADJUST mower sections or wing close and parallel to ground without exposing blades •...
Page 18: Run Over Hazards
SAFETY RUN OVER HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM FALLING OFF TRACTOR OR EQUIPMENT RUN OVER: • USE ROPS and SEAT BELT equipped tractors for mowing operations. • KEEP ROPS locked in UP position. • ONLY start tractor while seated in tractor seat. •...
Page 19: Pto Entanglement Hazards
SAFETY PTO ENTANGLEMENT HAZARDS KEEP AWAY FROM ROTATING DRIVELINES AND ELEMENTS TO AVOID SERIOUS INJURY OR DEATH: hands, feet and body AWAY from rotating blades, drivelines and parts until all moving STAY AWAY KEEP elements have stopped. • STOP, LOOK and LISTEN before approaching the mower to make sure all rotating motion has stopped. •...
Page 20: Mower Blade Contact Hazards
SAFETY MOWER BLADE CONTACT HAZARDS KEEP AWAY FROM ROTATING BLADES TO AVOID SERIOUS INJURY OR DEATH FROM BLADE CONTACT: • STAY AWAY and KEEP HANDS, FEET and BODY AWAY from rotating blades, drivelines and parts until all moving elements have stopped. •...
Page 21: High Pressure Oil Leak Hazards
SAFETY HIGH PRESSURE OIL LEAK HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM HIGH PRESSURE HYDRAULIC OIL LEAKS PENERATING SKIN: • DO NOT OPERATE equipment with oil or fuel leaks. • KEEP all hydraulic hoses, lines and connections in GOOD CONDITION and TIGHT before applying system pressure.
Page 22: Electrical & Fire Hazards
SAFETY ELECTRICAL & FIRE HAZARDS TO AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL CONTACT WHEN WORKING AROUND ELECTRICAL POWER LINES, GAS LINES AND UTILITY LINES: • INSPECT mowing area for overhead or underground electrical power lines, obstructions, gas lines, cables and Utility, Municipal, or other type structure. •...
Page 23: Transporting Hazards
SAFETY TRANSPORTING HAZARDS TO AVOID SERIOUS INJURY AND DEATH WHEN TOWING OR TRANSPORTING EQUIPMENT: • KEEP transport speed BELOW 20 mph to maintain control of equipment. • REDUCE SPEED on inclines, on turns and in poor towing conditions. • DO NOT TOW with trucks or other vehicles •...
Page 24: Hazards With Maintenance Of Implement
SAFETY HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS; Rotating Parts, Raised Components, Hydraulic Pressure. •...
Page 25: Parts Information
PARTS INFORMATION PARTS INFORMATION Bush Hog mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit”...
Page 26: Decal Location
SAFETY DECAL LOCATION NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 27 SAFETY ITEM PART NO. LEVEL DESCRIPTION D559 WARNING Genuine Bush Hog Parts 91505 NAME 3008 96232 NAME 3008SH D614 DANGER Thrown Object Hazard 50028366 INFORMATION Warranty D546 DANGER Guard Missing-Do Not Operate D547 DANGER Rotating D/L Entanglement D553 WARNING Multi-Hazard...
Page 36: Federal Laws And Regulations
SAFETY Federal Laws and Regulations This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such.
Page 38 INTRODUCTION We are pleased to have you as a Bush Hog customer. Your Rotary Cutter has been carefully designed with care and built with quality materials by skilled workers to give maximum service with minimum down time. This manual is provided to give you the necessary operating and maintenance instructions for keeping your rotary cutter in top operating condition.
Page 39: Equipment Specifications
INTRODUCTION The Bush Hog 3008 Series Rotary Mower is designed for medium duty applications such as weed, grass, corn stalks, and light brush to 2" diameter. These mowers are multi spindle with two free-swinging blades on each spindle. Free swinging blades reduce the shock of impact when a stationary object is hit.
Page 40: Key Operation Points
INTRODUCTION KEY OPERATION POINTS • Cutting performance and distribution are best when cutter is level from side to side and front to rear. • In extra heavy material, rear chains will allow better discharge and better distribution than solid rear bands. •...
Page 41: Limited Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgement of Bush Hog such use affects its performance, stability or reliability.
Page 44: Dealer Setup Instructions
ASSEMBLY DEALER SETUP INSTRUCTIONS The mower as received from the factory is partially assembled and requires minimum time to complete assembly and is ready for sale. This mower is shipped vertically with shipping brackets. These shipping brackets are intended for use in transporting the mower from the factory to dealer.
Page 45: Lift Model Assembly
B. With the tractor at idle speed, engage tractor PTO drive pads without turning blades. If clutch pads do not slip, contact the Bush Hog service department. C. Retighten nuts to within 1/64” of original position. Initial spring length is 1.32” (33.6mm).
Page 46: Semi-Mount Model Assembly
ASSEMBLY SEMI-MOUNT MODEL ASSEMBLY 1. Fasten shield to the front of the center gearbox using four M10 x 20mm bolts and lockwashers. 2. Slide clutch end of driveline onto center gearbox. Install the tapered pin and tighten the hex nut to 30 ft/lbs. Pull on driveline to make certain it is securely attached.
Page 47: Swing Hitch Model Assembly
ASSEMBLY SWING HITCH MODEL ASSEMBLY 1. Fasten shield to the front of the center gearbox using four M10 x 20mm bolts and lockwashers. 2. Slide clutch end of driveline onto center gearbox. Install the tapered pin and tighten the hex nut to 30 ft/lbs. Pull on driveline to make certain it is securely attached.
Page 48: Axle Assembly
ASSEMBLY AXLE ASSEMBLY Standard Lift Axles 1. Slide the adjusting collar onto the axle weldment tube. 2. Attach the axle assembly with caster wheel to the lugs located on the deck weldment with a 1/ 2” x 4-1/2” bolt and locknut. 3.
Page 49: Heavy Duty High Flotation Axle (Optional)
ASSEMBLY Heavy Duty High Flotation Axle (Optional) 1. Refer back to #8 under “Lift Model Assembly”. 2. Fasten each Axle Arm Weldment to axle using four 3/4” x 5-1/2” bolts, backup plate, lockwashers and nuts. (Figure Asm-R-0475) 3. Install caster and wheel assembly up through tube in end of axle arm. Slide spacer over shaft, align holes and fasten into place with spirol pin.
Page 50: Pull Model Assembly
ASSEMBLY PULL MODEL ASSEMBLY Models with Pillow Block and Jackshaft 1. Attach tongue to deck assembly using two 1 x 8-1/2” bolts, bushings and locknuts. (Figure Asm-R-0501). Attach hose holder rod to tongue using 1/2 x 2” bolt, flatwasher, lockwasher and nut. 2.
Page 51 ASSEMBLY 5. Slide clutch end of driveline onto center gearbox input shaft. Install the tapered pin and tighten hex nut provided to 30 ft/lbs. 6. Attach pillow block bearing to bearing mount using a 1/2” x 5-1/2” bolt and locknut. 7.
Page 52: Rear Metal Band Installation
ASSEMBLY REAR METAL BAND INSTALLATION 1. Raise cutter off ground and block securely in position. 2. Align holes on center band with those on cutter deck. Install 1/2 x 3-1/4” bolts, flatwashers, lockwasher and locknut. 3. Attach outer bands to center band and cutter side bands with 1/2 x 1-14” bolts, flatwashers, lockwasher and locknut.
Page 53: Rear Chain Installation
ASSEMBLY REAR CHAIN INSTALLATION 1. Compare each chain assembly to Figure Asm-R-0504 to determine location for installation. 2. Align holes on center chain assembly with those on cutter deck. Install 1/2 x 3-1/4” bolts, flatwashers, lockwasher and locknut. 3. Align holes in outer chain assembly with those on cutter deck. Install 1/2 x 1-1/4” bolt, flatwasher, lockwasher and locknut.
Page 56 BUSH HOG 3008 SERIES ROTARY MOWER OPERATION INSTRUCTIONS Bush Hog rotary mowers are manufactured with quality material by skilled workers. These mowers are designed to cut grass, weeds, small brush and other vegetative material up to 2” diameter in areas such as pastures, industrial areas, and roadsides.
Page 57: Operator Requirements
OPERATION 1. OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 58: Tractor Requirements
- Lifting Capacity......Lift - 1683 lbs, Pull - 2118 lbs, Semi-Mount -1845 lbs - 3-Point Hitch - 3008 ....CAT I-II and Quick Hitch, CAT I-II Semi-Mount, center pull 3008SH ... CAT I-II semi-mount offset, center to 13 inches offset -Hydraulics ........ Optional •...
Page 59: Tractor Safety Devices
OPERATION 2.2 Tractor Safety Devices If transporting or operating the tractor and implement near a public roadway, the tractor must be equipped with proper warning lighting and a Slow Moving Vehicle (SMV) emblem which are clearly visible from the rear of the unit.
Page 60: Drawbar - Pull Type Mower
OPERATION 2.5 Drawbar - Pull Type Mower For pull type mowers (540 and 1000 RPM) equipped with an equal-angle driveline, the tractor drawbar must be positioned as follows: 540 RPM at 14” Drawbar 1000 RPM, 1-3/8 at 16” Drawbar 1000 RPM, 1-3/4 at 20” Drawbar 2.6 Front End Weight A minimum of 20% total tractor weight must be maintained on the tractor front end at all times.
Page 61: Tire Spacing
OPERATION Never operate the Tractor and Mower if the Implement input driveline is directly connected to the Tractor transmission. Tractor braking distances can be substantially increased by the momentum of the rotating Mower blades driving the Tractor transmission even though the Tractor clutch has been disengaged.
Page 62: Dismounting The Tractor
OPERATION Never allow children to operate, ride on, or come close to the Tractor or Implement. Usually, 16-17 year-old children who are mature and responsible can operate the implement with adult supervision, if they have read and understand the Operator’s Manuals, been trained in proper operation of the tractor and Implement, and are physically large enough to reach and operate the controls easily.
Page 63: Starting The Tractor
OPERATION 4. STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 64: Connecting The Mower-Lift Type And Semi-Mount Type
OPERATION 5.1 Connecting the Mower-Lift Type and Semi-Mount Type 1. Make sure the tractor is equipped with the correct PTO shaft. Change shafts if needed. 2. Shorten or remove the tractor drawbar to avoid interference when raising and lowering the mower.
Page 65: Connecting Mower - Lift Type (Quick Hitch)
OPERATION 5.3 Connecting Mower - Lift Type (Quick Hitch) Crushing Hazard between Quick-Hitch and Implement. Do not allow anyone to stand between the Quick-Hitch and implement during hook-up operations. Never operate the hydraulic 3-point lift controls while someone is directly behind the tractor. 1.
Page 66: Connecting The Mower-Pull Type
OPERATION IMPORTANT: Scan this QR Code with your smart phone to link to the PAMI Safe Implement Hitching Manual for more information on correctly connecting agricultural tractors to implements. Or type in your internet browser the following web address: www.algqr.com/hme Ops-0008-MISC 5.5 Connecting the Mower-Pull Type 1.
Page 67: Setting The Mower
OPERATION 6. SETTING THE MOWER Properly setting the cutting height is essential for efficient and safe operation. A properly set mower will make a more uniform cut, distribute clippings more evenly, require minimal tractor work, and follow the contour of uneven terrain.
Page 68: Setting Mowing Height-Pull Type
OPERATION 6.2 Setting Mowing Height-Pull Type 1. Park the tractor and mower on level ground. 2. Using the tailwheel ratchet jack or hydraulic cylinder, position the mower so the skid shoes are 1” less off the ground than the desired final cut height.
Page 69: Driveline Attachment
OPERATION 7. DRIVELINE ATTACHMENT The driveline yoke and tractor PTO shaft must be dirt free and greased for attachment. To connect the mower driveline to the tractor PTO output shaft, pull the driveline yoke collar back and align the grooves and splines of the yoke with those of the PTO shaft.
Page 70 OPERATION “Bottoming Out” Check Procedure • Disconnect driveline from the tractor and slide the profiles together until fully compressed. • Place a mark on the inner shield 1/8” from the end of the outer shield. • Reattach the driveline to the PTO Shaft. •...
Page 71: Constant Velocity (Cv) Driveline
OPERATION 7.2 Constant Velocity (CV) Driveline Mowers are equipped with a Constant Velocity (CV) driveline, the maximum turning angle between the tractor and mower must be determined to ensure the joint angle does not over-extend which can cause CV joint damage.
Page 72: Pre-Operation Inspection And Service
OPERATION 8. PRE-OPERATION INSPECTION AND SERVICE Before each use, a pre-operation inspection and service of the implement and tractor must be performed. This includes routine maintenance and scheduled lubrication, inspecting that all safety devices are equipped and functional, and performing needed repairs. DO NOT operate the unit if the pre-operation inspection reveals any condition affecting safe operation.
Page 73: Tractor Pre-Operation Inspection/Service
OPERATION 8.1 Tractor Pre-Operation Inspection/Service Refer to the tractor operator’s manual to ensure a complete pre-operation inspection and scheduled service performed according manufacturers recommendations. The following are some of the items that require daily service and inspection: • Tire condition/air pressure •...
Page 74 OPERATION • Perform scheduled lubrication as detailed in the maintenance section. • Ensure all decals are in place and legible. • Ensure the driveline is securely attached to tractor. Make sure the driveline yoke locking collar is securely seated in the grooves of the PTO shaft by pushing and pulling the yoke several times.
Page 75 OPERATION • Lift Type-Ensure the axle clamps and clamps are properly installed and are tight. • Pull and Semi-Mount Type-Ensure that the tailwheel ratchet or hydraulic cylinder is installed and retained correctly to provide the desired cutting height. • Inspect all bolts and screws and tighten to the recommended torque.
Page 76 OPERATION • Inspect blades and blade bolts for looseness and excessive wear. Make sure the mower is securely blocked up before crawling beneath. Replace damaged, worn and missing blades as complete sets to maintain rotary balance during operation. • Ensure carrier hub nut is tightened with the cotter pin inserted and spread.
Page 77: Cutting Component Inspection
OPERATION 8.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 3008 SERIES 07/12 Operation Section 4-23 © 2012 Alamo Group Inc.
Page 78 OPERATION Operating the mower with loose blade hardware will damage the blade holder or blades and can result in blade breakage or blade fastener failure. Broken blades or bolts can be thrown out from under the mower for distances up to 300 feet. When the blades are replaced, the fastening hardware must be replaced.
Page 79: Blade Bolt Inspection
OPERATION 8.4 Blade Bolt Inspection Inspect Blade Bolt Head daily for wear as followed: Inspect the Blade Bolt Heads daily for abnormal wear. REPLACE BOTH BLADE BOLTS on the Blades IMMEDIATELY if either blade bolts has: • Visible cracks or •...
Page 80 OPERATION Tractor PRE-OPERATION Inspection Tractor ID#:________________________Make:________________________ Date:______________________________Shift:________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the implement is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 81 OPERATION Rotary Mower PRE-OPERATION Inspection IMPORTANT: Scan Mower ID#________________ this QR Code for an electronic copy of this Date: ________________ inspection sheet. www.algqr.com/rmi Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged.
Page 82: Driving The Tractor And Implement
OPERATION 9. DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the implement and the tractor operating controls are set for safe transport.
Page 83: Starting The Tractor
OPERATION 9.1 Starting the Tractor The procedure to start the tractor is model specific. Refer to the tractor operator’s manual for starting procedures for your particular tractor. Consult an authorized dealer if the starting procedure is unclear. Ensure the 3-point control lever is in the lowered position and the PTO is disengaged before starting the tractor.
Page 84: Raising The Mower
OPERATION 9.3 Raising the Mower Using the tractor 3-point hitch control lever-lift type or hydraulic remote lever-pull and semi-mount type, raise the mower high enough to clear all ground obstacles. When raising the mower, make sure all connection points are securely attached and at least 1”...
Page 85: Crossing Ditches And Steep Inclines
OPERATION 9.5 Crossing Ditches and Steep Inclines When crossing ditches with steep banks or going up sharp inclines, it is possible that the main driveline inner profile will penetrate into the outer housing to its maximum depth until the assembly becomes solid (driveline is at its extreme shortest length).
Page 86: Operating The Tractor And Implement
OPERATION Inclines and ditches should be approached along a line which is at an angle as shown. This type of path will reduce the possibility of over-collapse of the driveline and resulting damage. If the gradient is so steep that such an approach increases the possibility of a tractor roll-over, select an alternate crossing path.
Page 87: Foreign Debris Hazards
OPERATION Many varied objects, such as wire, cable, rope, or chains, can become entangled in the operating parts of the mower head. These items could then swing outside the housing at greater velocities than the blades. Such a situation is extremely hazardous and could result in serious injury or even death.
Page 88: Engaging The Power Take Off (Pto)
OPERATION Rotary Mowers are capable under adverse conditions of throwing objects for great distances (300 ft (100 m) or more) and causing serious injury or death. Follow safety messages carefully. STOP MOWING IF PASSERSBY ARE WITHIN 300 Feet (100 m) UNLESS: -Front and Rear Deflectors, Chain Guards, or Bands are installed and in good, workable condition;...
Page 89: Pto Rpm And Ground Speed
OPERATION 10.4 PTO RPM and Ground Speed Ground speed for mowing will depend upon the height, type, and density of vegetation to be cut. Recommended speed for efficient mower performance is between 2 and 5 mph(3-8 kph). Operate the mower at its full rated PTO speed to maintain blade speed for a clean cut.
Page 90 OPERATION Do not mow with two machines in the same area except with Cab tractors with the windows closed. (SGM-11) Mow only in conditions where you have clear visibility in daylight or with adequate artificial lighting. Never mow in darkness or foggy conditions where you cannot clearly see at least 300 feet (90 m) in front and to the sides of the tractor and mower.
Page 91 OPERATION Do not let the Blades turn when the Mower Deck is raised for any reason, including clearance or for turning. Raising the Mower deck exposes the Cutting Blades which creates a potentially serious hazard and could cause serious injury or even death from objects thrown from the Blades.
Page 92: Right Of Way (Highway) Mowing
OPERATION 10.6 Right of Way (Highway) Mowing • USE DOUBLE CHAIN GUARDS for highway, right-of-way, parks, greenbelt mowing, or all other mowing where human dwellings, vehicles, or livestock could be within 300 feet of the mower. • No shielding is 100% effective in preventing thrown objects. To Reduce Possibility of Injury: 1.
Page 93: Shutting Down The Implement
OPERATION 10.7 Shutting Down the Implement To shut down attached mower head, first bring the tractor to a complete stop. Decrease engine RPM to idle then disengage cutterhead. The mower head will come to a complete stop within a suitable amount of time.
Page 94 OPERATION Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) Never unhitch without using the Tongue Jack. The Tongue is very heavy. Attempting to lift the Tongue without using the Tongue Jack could cause strains or other injury.
Page 95: Mower Storage
OPERATION 12. MOWER STORAGE Properly preparing and storing the mower at the end of the season is critical to maintaining its appearance and to help ensure years of dependable service. The following are suggested storage procedures: • Thoroughly clean all debris off the mower to prevent damage from rotting grass and standing water.
Page 96: Tire And Wheels
OPERATION Before transporting the tractor and mower, idle the tractor engine, disengage the PTO and wait for all mower moving parts to come to a complete stop. Once all mower parts are completely stopped, raise the mower to transport height. NOTE: When raising the mower, maintain 1”...
Page 97: Transporting On Public Roadways
OPERATION 13.2 Transporting on Public Roadways Extreme caution should be used when transporting the tractor and implement on public roadways. The tractor must be equipped with all required safety warning features including a SMV emblem and flashing warning lights to alert drivers of the tractor’s presence. Remember that roadways are primarily designed for automotive drivers and most drivers will not be looking out for you, therefore, you must look out for them.
Page 98: Hauling The Tractor And Implement
OPERATION When operating public roads, have consideration for other road users. Pull to the side of the road occasionally to allow all following traffic to pass. Do not exceed the legal speed limit set in your country for agricultural tractors. Always stay alert when transporting the tractor and implement on public roads.
Page 99: Troubleshooting Guide
OPERATION 14. TROUBLESHOOTING GUIDE Problem Possible Cause Remedy Uneven Cut Excessive ground speed. Reduce ground speed. Blades worn, dull, or bent. Replace blades. (Refer to “Maintenance” section). Mower not level side to side. Adjust. (Refer to “Assembly” section) Improper height adjustment. Adjust Mower height.
Page 100 OPERATION Blade Bolts Working Loose Bolts not tightened. Tighten Bolts to 600 ft./lbs. Bolt hole elongated or oversized. Replace Blade Carrier. Gearbox Noisy Low Lubricant. Check lubricant level. Rough gears. Run in or change Gears. Worn Bearing. Replace Bearing. Gearbox Leaking Damaged Oil Seal.
Page 102: Hazards With Maintenance Of Implement
MAINTENANCE HAZARDS WITH MAINTENANCE OF IMPLEMENT AVOID SERIOUS INJURY OR DEATH FROM COMPONENT FAILURE BY KEEPING IMPLEMENT IN GOOD OPERATING CONDITION PERFORMING PROPER SERVICE, REPAIRS MAINTENANCE. BEFORE PERFORMING SERVICE, REPAIRS AND MAINTENANCE ON THE IMPLEMENT: SECURE EQUIPMENT FOR SERVICE BLOCK OUT POTENTIAL ENERGY HAZARDS; Rotating Parts, Raised Components, Hydraulic Pressure. STOP ENGINE AND PTO •...
Page 103: Lubrication
MAINTENANCE PARTS INFORMATION Bush Hog mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit”...
Page 105: Gearbox
MAINTENANCE GEARBOX The gearbox should not require additional lubricant unless the box is cracked or a seal is leaking. It is recommended that the oil level plug be removed after every 8 to 10 hours of operation and oil added until it runs out Test Plug hole.
Page 106 MAINTENANCE The Driveline Integral Shields should not become dented or otherwise damaged. The Integral Shield Assembly has a Nylon Bearing at each end and should turn freely. This nylon bearing should require lubrication every 40 hours. To remove the Integral Shields for replacement or repair, turn the three Nylon Nuts 1/4 turn in the Shield Slots of the Cone and Tube and remove them.
Page 107: Main & Jackshaft Driveline Shields
MAINTENANCE MAIN & JACKSHAFT DRIVELINE SHIELDS To remove the main inner driveline shield, Remove the locking screws. Align the bearing tabs with the cone pockets. FIGURE Mnt-0026. Remove the half-guard and remove the bearing ring. FIGURE Mnt-R-0012. Inspect the driveline shield for worn areas or cracks. If the shield has any dents or cracks, replace the Shield. While the Shields are off, examine the Driveline for signs of abnormal wear, bent or twisted shafts, or cracks in the shafts or tubes.
Page 108: Main Cv Driveline Safety Shield
MAINTENANCE MAIN CV DRIVELINE SAFETY SHIELD To remove the outer CV cone, remove the locking screws from shield cone. Remove cone over yoke. Figure Mnt-R-0038 Remove bearing ring and remove the locking screws from inner shield cone. Figure Mnt-R-0038. Turn inner cone to assembly position and remove half shield. Remove bearing ring. FIGURE MNT-R-0038. To assemble outer CV driveline, grease yoke groove and inner profile tube.
Page 109: Blade Servicing
MAINTENANCE IMPORTANT: Scan this QR Code with your smart phone to link to the ADMA Driveline Safety Manual for more information on the safe use of a driveline during normal operation and maintenance. Or type in your internet browser the following web address: www.algqr.com/dme Ops-0009-MISC BLADE SERVICING...
Page 110: Blade Sharpening
MAINTENANCE BLADE SHARPENING Always sharpen both blades at same time to maintain balance. Follow original sharpening pattern as shown in Mnt-R-0008. Always sharpen blades by grinding. DO NOT heat and pound out edge. Do not sharpen blade to a razor edge, but leave a 1/16” blunt edge. Do not sharpen back side of blade. Avoid personal injury.
Page 111: Blade Bolt Inspection
MAINTENANCE Blade Bolt Inspection Inspect Blade Bolt Head daily for wear as followed: Inspect the Blade Bolt Heads daily for abnormal wear. REPLACE BOTH BLADE BOLTS on the Blades IMMEDIATELY if either blade bolts has: • Visible cracks or • If the recessed area on blade bolt is worn off or •...
Page 112: Blade Carrier Installation
MAINTENANCE BLADE CARRIER INSTALLATION Clean the splines on both the blade carrier and output shaft. Position carrier on the gearbox output shaft and install special washer, and nut. Tighten nut holding blade carrier to minimum 450 ft. pounds, strike the carrier near the hub several times with a heavy hammer to seat the hub.
Page 113: Slip Clutch
1/3 of a turn (2 flats on a nut) and check clutch slippage. If further adjustment is necessary, do so in 1/3 turn increments or consult your Bush Hog dealer. Adjust only to provide sufficient torque to prevent slippage under normal conditions.
Page 114: Storage
MAINTENANCE STORAGE Your rotary cutter represents an investment from which you should get the greatest possible benefit. Therefore, when the season is over, the cutter should be thoroughly checked and prepared for storage so that a minimum amount of work will be required to put it back into operation for the next season.
