2
Connections
Left
1. Headphone jack
2. Microphone jack
3. USB 2.0 port #1
1 2 3
Right
4. USB 2.0 port #2
5. SD Card Reader
6. Ethernet Port
7. Power Input
4
5
6
7
Replace Battery
1. Unlock static latch
2. Hold spring latch and
lift battery out
3. Snap replacement battery
into slot
4. Lock static latch
© 2008, Intel Corporation. All rights reserved. Intel, and the Intel logo
are trademarks of Intel Corporation in the U.S. and other countries.
* Other marks and brands may be claimed as the property of others.
1208/MG/CMD/PDF
318938-002 US
Intel-powered
clamshell classmate PC
Hardware Quick Start Guide
Part of the Intel® Learning Series
1
Congratulations!
Congratulations on your purchase of an
Intel-powered clamshell classmate PC.
Follow these simple instructions to get
your classmate PC up and running.
What's in the box
Intel-powered clamshell classmate PC
Power adapter
Advertisement
Related Manuals for Intel Learning Series
Summary of Contents for Intel Learning Series
- Page 1 4. Lock static latch © 2008, Intel Corporation. All rights reserved. Intel, and the Intel logo are trademarks of Intel Corporation in the U.S. and other countries. * Other marks and brands may be claimed as the property of others.
- Page 2 Charge Battery System/Power Status Indicators Start The Computer Set Up A Connection Set Up a Wired Connection 1. Connect the AC Power Cord to the Power Adapter. The row of icons located above the keyboard light up with Press and hold the Power Button for three seconds or until the 2.
