© COPYRIGHT 2004 by HUFFY SPORTS
Portable System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-333 061
Internet Address: http://www.huffysports.com
• Two People
• Wood Board (Scrap)
• Tape Measure
• Step Ladder 8 ft. (2.4 m)
• Tape
• Garden Hose or Sand 360 lb. (163 kg)
• Hammer
• Wrenches: (Two) 1/2" (One) 9/16" or Two Small Adjustable
Wrenches (9/16" Deep Socket w/Extension
Recommended)
• Support Table
• Safety Goggles
1
REQUIRED TOOLS AND
MATERIALS
:
01/05
P/N 211022

Advertisement

Table of Contents
loading

Related Manuals for Huffy Portable System

Summary of Contents for Huffy Portable System

  • Page 1 OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), © COPYRIGHT 2004 by HUFFY SPORTS Portable System Owners Manual Customer Service Center WARNING!

  • Page 2: Before You Start

    BEFORE YOU START! To ensure optimal playability of backboard system, a close tolerance fit between the elevator components and hardware is required. Test-fit large bolts into large holes of elevator tubes, backboard brackets, and triangle plates. Carefully rock them in a circular motion to ream out Pour garantir l'utilisation optimale du panneau, les composants du système élévateur et la visserie doivent être bien ajustés (serrés).
  • Page 3 WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the system. • DO NOT HANG on the rim or any part of the system including backboard, support braces or net.

  • Page 4: Warranty Card

    ALL Huffy Sports Basketball Systems, including those used for DISPLAYS, MUST be assembled and ballasted with sand or water according to the instructions. Failure to follow instructions could result in SERIOUS INJURY. It is NOT acceptable to devise a makeshift weight system.

  • Page 5: Safety Instructions

    • If technical assistance is required, contact Huffy Sports. • Adult supervision is recommended when adjusting height. Most injuries are caused by misuse and/or not following instructions.
  • Page 6 Get to know the basic parts of your basketball system... FRONT BACKBOARD POLE SUPPORT STRUT BASE P/N 211022 01/05...
  • Page 7 ItemQty. Part No. Description 206657 Tank, (Black) 200628 Wheel Axle 226401 Wheel, 4“ (Black) 90021701 Top Pole Section 904840 Middle Pole Section 900136 Bottom Pole Section 202820 Rod, 3/8 O.D. x 4-3/4 Long 202822 Eyebolt, 3/8-16 x 2-1/2 Long 203063 Nylon Insert Lock Nut, 3/8-16 906206 Tank Strut 201625 Bolt, Hex Head, 5/16-18 x 3-3/4 Long 203218 Washer, Flat, 3/8 I.D.
  • Page 8 HARDWARE IDENTIFIER (BOLTS) Item #32 (2) Item #8 (1) Item #43 (5) Item #11 (1) Item #31 (4) Item #15 (2) Item #35 (1) Item #47 (1) Item #34 (1) HARDWARE IDENTIFIER (NUTS & WASHERS) Item #37 (1) Item #39 (5) Item #18 (2) Item #12 (6) Item #38 (1)
  • Page 9 HARDWARE IDENTIFIER (STEEL SPACERS & RODS) Item #7 (1) Item #33 (2) HARDWARE IDENTIFIER (PLASTIC SPACERS & CLIPS) Item #42 (4) Item #20 (12) Item #49 (1) Item #17 (4) HARDWARE IDENTIFIER (OTHER) Item #48 (1) Item #46 (1) Item #45 (1) Item #30 (1) 01/05 P/N 211022...

  • Page 10: Section A: Assemble The Base

    SECTION A: ASSEMBLE THE BASE This is what your system will look like when you’ve finished this section: HARDWARE USED IN THIS SECTION TOOLS REQUIRED FOR THIS SECTION (not actual size) (2) 1/2”, (2) 9/16" AND (2) 3/4" Wrenches Item #35 Item #33 Item #42 Item #34...
  • Page 11 Remove contents from tank (1). Correctly identify each pole section and mark indicated distance from ends with tape as shown. TOP POLE 31” MIDDLE POLE 43” BOTTOM POLE 43” 01/05 P/N 211022...
  • Page 12 IMPORTANT! Center alignment slot of middle pole section (5) in a lower hole of top pole section (4) as shown. While maintaining alignment, bounce pole top (4) and middle section (5) together as shown until they no longer move toward taped reference mark.
  • Page 13 Install rod (7) through holes in bottom pole section (6) and eyebolt (8). Install wheel axle (2) through wheel carriage (19) and install wheels (3) onto wheel axle (2) with spacers (17) as shown. Insert pole assembly into tank assembly as shown. Secure bottom pole (6) section to tank and wheel carriage as shown.
  • Page 14 Secure base struts (10) to pole using bolt (11), washers (12), and nut (13), as shown. Rotate the non-secured ends of base struts (10) as shown. Secure base struts (10) to base using bolt (15), washers (12), and nut (16). P/N 211022 01/05...
  • Page 15 Fit spacer (33) into pawl (27). Then continue to assemble as shown. Tighten completely. Identify elevator tubes (43 & 40). Toward Toward Board Pole Elevator tube 01/05 P/N 211022...
  • Page 16 Assemble elevator tubes (44) to ratchet (28) and backboard brackets (29) using bolts (43), spacers (42. 17, & 49), and nuts (32) as shown. Tighten completely. Secure pawl (27) in place with clevis pin (30) and washers (18) as shown. P/N 211022 01/05 Stretch spring (41) into position with pliers.

  • Page 17: Section B: Attach The Backboard

    SECTION B: ATTACH THE BACKBOARD This is what your system will look like when you’ve finished this section: HARDWARE USED IN THIS SECTION TOOLS REQUIRED FOR THIS SECTION (not actual size) (2) 1/2”, (2) 9/16"” AND (2) 3/4” Wrenches Item #16 Item #31 (4) AND/OR (2) Socket Wrenches and Sockets...
  • Page 18 Bend upper halves of backboard brackets (29) to line up with holes in backboard and secure with bolts (32) and nuts (16). Attach rim (21) and plastic spacer ( ) to board with bolts (31) as shown. Tighten completely. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE.
  • Page 19 Support pole on sawhorse. Attach upper and lower elevator tubes (44) to upper pole section (4) using bolts (43) and nuts (39) as shown. Attach pole cap (22) as shown. WARNING! TWO PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
  • Page 20 Install net clips. WARNING! USE OF THIS PRODUCT WITHOUT PROPER INSTALLATION OF SMART CLIPS ® , OR WHEN ALL SMART CLIPS ® ARE NOT PRESENT COULD RESULT IN BODILY HARM. BE SURE TO FOLLOW DIRECTIONS CAREFULLY. P/N 211022 01/05 Insert one “arm” of clip into ram as shown. Twist “body” of clip slightly so that second “arm”...
  • Page 21 NET INSTALLATION SIDE VIEW NETCLIP Insert net into bottom of clip as shown. SIDE VIEW Twist net until it snaps into position. Net must be centered through clip. NETCLIP 01/05 P/N 211022...
  • Page 22 Roll the completed assembly to the desired playing area. Insert the T-strap (14) through the slot on the back of the base as shown. Secure the unit to ground by twisting the tie down stake (23) into the ground and hooking the T-strap (14) onto the tie down stake (23).
