Prince Castle 755-HM8 Specifications

The 755 Series Multi-Display Timers includes three
economical, single-function timers in eight, ten and
sixteen channel models.
These easy-to-use timers count down or up in
minutes and seconds, or hours and minutes. Each
channel has its own display, and can be programmed
independently. Slide in replaceable menu strips identify
the product being timed on each channel, and are
replaceable as restaurant menus change.
Prince Castle timers are easy to program and simple
to use. The push of a button activates each channel; an
audible alarm and flashing channel button alert the
operator when timing is complete. Operators also have
the option to program a preliminary alarm to warn the
end of the timing cycle is near.
Prince Castle timers are standard 120V and are
backed by a one-year parts and labor warranty.
755 MD 03/04
355 East Kehoe Blvd. • Carol Stream, IL 60188 • Tel: (630) 462-8800 • Fax: (630) 462-1460 • Toll Free: 1-800-PCASTLE • www.princecastle.com
Model
755-HM10
MULTI-DISPLAY
Model
755-HM8
STANDARD FEATURES
•
Each channel counts down or up in minutes and
seconds, or hours and minutes
•
Each channel has its own display - capable of
displaying both alpha and numeric characters
•
Toggles between countdown (or count-up) time
and duty function
•
Each channel capable of storing two different
programs
•
Features an Alert alarm to warn, "The end is
near"
•
Removable identification strips can be easily
changed to accommodate new menu items
•
Program time and one duty function per channel
•
8 programmable volume levels
•
Transformer built into housing (no fat plug)
•
One-year parts and labor warranty
755 SERIES
TIMERS
Model
755-HM16
