JVC KD-LX111R Service Manual

Cd receiver
Hide thumbs Also See for KD-LX111R:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
SERVICE MANUAL
Contents
Safety precaution
Preventing static electricity
Disassembly method
Adjustment method
CD RECEIVER
KD-LX111R
ATT
7
8
S
T
D
M
SOURCE
1-2
Flow of functional
1-3
1-4
Maintenance of laser pickup
1-13
Replacement of laser pickup
Description of major ICs
COPYRIGHT
2002 VICTOR COMPANY OF JAPAN, LTD.
KD-LX111R
OFF
9
12
Area suffix
E ----------- Continental Europe
EX --------------- Central Europe
operation unitl TOC read
KD-LX111R
1-14
1-16
1-16
1-17~31
No.49714
Jun. 2002

Advertisement

loading

Related Manuals for JVC KD-LX111R

Summary of Contents for JVC KD-LX111R

  • Page 1 KD-LX111R SERVICE MANUAL CD RECEIVER KD-LX111R KD-LX111R SOURCE Area suffix E ----------- Continental Europe EX --------------- Central Europe Contents Safety precaution Flow of functional Preventing static electricity operation unitl TOC read 1-14 Disassembly method Maintenance of laser pickup 1-16 Adjustment method...

  • Page 2: Safety Precaution

    KD-LX111R Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an...
  • Page 3 KD-LX111R Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as mechanism unit.

  • Page 4: Disassembly Method

    KD-LX111R Disassembly method Bottom cover <Main body> Removing the top chassis (See Fig.1 to 5) Remove the two screws A attaching the bottom cover to the top chassis on the bottom of the body. Remove the two screws B attaching the top chassis on both sides of the body.
  • Page 5 KD-LX111R Removing the front panel assembly (See Fig.6 to 8) Prior to performing the following procedure, remove the top chassis assembly. Disconnect the flexible harness from connector CN701 on the main board assembly. CN701 Remove the four screws H attaching the front panel assembly on both sides of the body.
  • Page 6 KD-LX111R Removing the lifter unit (See Fig.10) Prior to performing the following procedure, remove the top chassis assembly and the front panel assembly. Disconnect the harness from connector CN503and CN504 CN503 CN504 on the main board. Remove the four screws J and detach the lifter unit from the bottom cover.
  • Page 7 KD-LX111R Removing the operation assembly (See Fig.13 to 16) Prior to performing the following procedure, remove the top chassis assembly, the front panel assembly and the lifer unit. Disconnect the card wire from connector CN702 on Bracket (L) the main board and remove the operation assembly.
  • Page 8 KD-LX111R Removing the operation switch board (See Fig.17 and 18) Prior to performing the following procedure, remove the operation assembly. Remove the six screws N attaching the button panel on the operation assembly. Pull out the operation switch board from inside of the Button panel button panel.
  • Page 9 KD-LX111R Removing the main board assembly (See Fig.20 to 22) Prior to performing the following procedure, remove the top chassis. CN504 Disconnect the flexible harness from connector CN503 CN701, the card wire from CN702 on the main board CN701 harness...

  • Page 10: Cd Mechanism Section

    KD-LX111R <CD mechanism section> Damper bracket Pickup cover Removing the CD mechanism control board (See Fig.1 and 2) Remove the screw A and the pickup cover attached to the front bracket with the double-sided tapes. Unsolder the three parts a, b and c on the CD mechanism control board.
  • Page 11 KD-LX111R Loading motor Belt Fig.5 Removing the CD mechanism assembly CD mechanism assembly Damper bracket (See Fig.1, 6 to 9) Prior to performing the following procedure, remove the CD mechanism control board and the front bracket (loading motor). Flame Remove the three screws E...
  • Page 12 KD-LX111R Removing the feed motor assmbly Part j FD screw (See Fig.10) Feed motor assembly Prior to performing the following procedure, remove the CD mechanism control board, the front bracket Part i (loading motor) and the CD mechanism assembly. Remove the two screws G and the feed motor assembly.

  • Page 13: Adjustment Method

    6. Digital tester FM 87.5MHz ~ 108.0MHz 7. Tracking offset meter MW 144 ~ 279kHz, 520kHz ~ 1620 kHz 8. Test Disc JVC :CTS-1000 Dummy load 9. Extension cable for check Exclusive dummy load should be used for AM,and FM. For...
  • Page 14 KD-LX111R Flow of functional operation until TOC read Power ON When the laser diode correctly Set Function to CD When the pickup correctly moves emits to the inner area of the disc Microprocessor Microprocessor Disc inserted commands commands TC9462 "53"...
  • Page 15 KD-LX111R Feed Section Check CD 9V Is the voltage output at Is the wiring for IC521 Is 5V present at IC581 and 5V. IC521 pin "53" 5V or 0V? (90) ~ (100) correct? pin "11"? Check the vicinity of IC521.
  • Page 16 KD-LX111R Maintenance of laser pickup (1) Cleaning the pick up lens Before you replace the pick up, please try to clean the lens with a alcohol soaked cotton swab. (2) Life of the laser diode When the life of the laser diode has expired, the following symptoms will appear.

  • Page 17: Description Of Major Ics

    KD-LX111R Description of major ICs FAN8037 (IC581) : CD driver 1. Pin layout & Block diagram 42 41 40 39 38 37 48 47 46 45 44 43 STAND BY T.S.D ALL MUTE POWER SAVE 13 14 15 16 17 18 19 20 21 22 23 24 2.
  • Page 18 KD-LX111R UPD784217AGC168 (IC701) : Main micon 1.Pin layout 100 ~ 76 26 ~ 50 2.Pin functions(1/3) Pin No. Symbol Function CD mechanical switch 2 detection signal input CD mechanical switch 3 detection signal input CD mechanical switch 4 detection signal input...
  • Page 19 KD-LX111R 2.Pin functions(2/3) Pin No. Symbol Function LCD-CE1 Chip enable output 1 to LCD driver BUZZER Buzzer output 12C-DAI 12C communication data input 12C-DAO 12C communication data output 12C-CLK 12C communication clock output BUS-I/O J-BUSI/O signal terminal Tray motor negative signal output terminal...
  • Page 20 KD-LX111R 2.Pin functions(3/3) Pin No. Symbol Function BUSO Data communication input and output port 0 with CDLSI BUS1 Data communication input and output port 1 with CDLSI BUS2 Data communication input and output port 2 with CDLSI BUS3 Data communication input and output port 3 with CDLSI...
  • Page 21 KD-LX111R 2.Pin function (1/2) TC9490FA(2/3) Pin No. Symbol Function Bit clock outputpin 32fs, 48fs, or 64fs selectable by command. LRCK L/R channel clock output pin."L" for L channe and "H" for R channel. Output polarity can be inverted by command.
  • Page 22 KD-LX111R 2.Pin function (2/2) TC9490FA(3/3) Pin No. Symbol Function RFGC RF amplitude adjustment control signal output pin. TEBC Tracking balance control signal output pin. APC circuit ON/OFF signal output pin. At laser on,high impedance with UHS="L" ,H output with UHS="H".
  • Page 23 KD-LX111R BD3860K (IC911):E.vol & Loud 1.Terminal layout 2.Block diagram GND FIL VCC SEL1 VIN1 LOUD1 HF1 LF1 DET1 VCA1 MIX1 BBOUT1 TIN1 TNF1 BNF1 BOUT1 POWER FADER SUPPLY MAIN INPUT OUTF1 CH1 FRONT TREBLE BASS VOLUME GAIN 0 -5 dB...
  • Page 24 KD-LX111R TA2147F-X (IC501) : RF amp. 1.Terminal layout 2.Block diagram PEAK GVSW 12 RFDC 20 A TEBC 50 A RFRP BOTTOM RFRPIN PEAK RFGO 1.75k 240k 15pF x0.5 RFGC 240k 15pF x0.5 AGCIN 180k 40pF 1-24...
  • Page 25 KD-LX111R 3.Pin function Pin No. Symbol Function 3.3V Power supply pin Main-beam amp input pin Main-beam amp input pin Sub-beam amp input pin Sub-beam input pin Monitor photo diode amp input pin Laser diode amp output pin APC circuit ON/OFF control signal,laser diode (LDO) control signal input or bottom/peak detection frequency change pin.
  • Page 26 KD-LX111R TA8273H(IC941):Power amp 1.Block diagram 2200 F 0.022 F Vcc 1/2 Vcc 3/4 INRF OUT RF+ 0.22 F OUT RF- AC CONT1 Protective circuit OUTRR+ INRR OUTRR- 0.22 F ST BY Stand by Switch ST ON Mute 10K Ripple Mute...
  • Page 27 KD-LX111R 2.Terminal layout 3.Pin function TA8273H Pin No. Symbol Function Header of IC AC CONT 1 Power GND OUTRR- Outpur(-) for Rear Rch Stand by input STBY OUTRR+ Output (+) for Rear Rch Power input VCC1/2 OUTRF- Output (-) for Front Rch...
  • Page 28 KD-LX111R HA13164A (IC961) : Regulator 1.Terminal layout 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 2.Block diagram 100u 0.1u BATT.DET OUT ANT OUT Surge Protector 0.1u EXT OUT COMPOUT BIAS 0.1u VDD OUT ANT CTRL 0.1u...
  • Page 29 KD-LX111R LC75878W (IC601) : LCD driver 1. Pin layout 100 ~ 76 26 ~ 50 2. Block diagram COMMON GENERAL SEGMENT DRIVER & LATCH PORT DRIVER CLOCK CONTROL GENERATOR REGISTER VLCD CONTRAST SHIFT REGISTER ADJUSTER VLCD0 VLCD1 VLCD2 INTERFACE VLCD3 VLCD4 3.
  • Page 30 KD-LX111R BR24C32F-X (IC703) : EEPROM 1. Pin layout 2. Pin function WPIN Symbol I/O Function Power supply. A0,A1,A2 No use connect to GND. Serial clock input. Serial data I/O of slave and word address. WPIN Write protect terminal. 3. Block diagram...
  • Page 31 KD-LX111R BU1923F (IC51) : RDS decoder 1. Pin layout QUAL RCLK RDATA N.C. Vref VDD1 VDD2 VSS1 VSS2 VSS3 2. Block diagram VSS3 100k 120k 100k 8th Switched capacitor filter comparator Vref anti-aliasing filter RCLK VDD1 Analog Power supply VSS1...
  • Page 32 KD-LX111R VICTOR COMPANY OF JAPAN, LIMITED MOBILE ELECTRONICS DIVISION PERSONAL & MOBILE NETWORK BUSINESS UNIT. 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan 200206 (No.49714)

  • Page 33: Schematic Diagrams

    KD-LX111R SCHEMATIC DIAGRAMS CD RECEIVER KD-LX111R CD-ROM No.SML200206 Area suffix E ----------- Continental Europe EX --------------- Central Europe KD-LX111R SOURCE Contents Block diagram Standard schematic diagrams Printed circuit boards No.49714 COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD. Jun. 2002...
  • Page 34 < M E M O >...

  • Page 35: Block Diagram

    KD-LX111R Block diagram Front speaker IC941 IC361 LOUTF INFL OUTFL ,OUTFR L-CH POWER AMP LOUTR INFR OUTFL ,OUTFR R-CH Rear speaker TUNER PACK IC911 FM/AM FMDET.ADJ E.VOLUME BATT CD-L S.METER LOUTF IC461 INFL CD-R IC51 SEEK/STOP LOUTR INFR SD/ST PLLCE...

  • Page 36: Standard Schematic Diagrams

    KD-LX111R KD-LX111R Standard schematic diagrams Main amp section Parts are safety assurance parts. When replacing those parts make sure to use the specified one. TUNER SIGNAL CD SIGNAL CD CHANGER SIGNAL FRONT SIGNAL REAR SIGNAL...
  • Page 37 KD-LX111R LCD&key cntrol section...
  • Page 38 KD-LX111R KD-LX111R Printed circuit boards Main board(Forward side) Main board(Reverse side) C961 D962 IC961 D701 R975 R988 R136 R962 C852 R981 C965 A M- A N T R218 CN301 Q981 R118 A M- V C C R963 C116 C216 C966...
  • Page 39 < M E M O >...
  • Page 40 KD-LX111R VICTOR COMPANY OF JAPAN, LIMITED MOBILE ELECTRONICS DIVISION PERSONAL & MOBILE NETWORK BUSINESS UNIT. 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan 200206 (No.49714)

  • Page 41: Parts List

    KD-LX111R PARTS LIST [ KD-LX111R ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix E ----------- Continental Europe EX --------------- Central Europe - Contents - 3- 3 Exploded view of general assembly and parts list (Block No.M1) 3- 5 CD mechanism assembly and parts list (Block No.MB)
  • Page 42 LD-LX111R < M E M O >...
  • Page 43 KD-LX111R Exploded view of general assembly and parts list Block No. 80 88 82 86 80 89 LCD1...
  • Page 44 KD-LX111R KD-LX111R Parts list (General assembly) Parts list (General assembly) Block No. M1MM Block No. M1MM Item Parts number Parts name Q'ty Description Area Item Parts number Parts name Q'ty Description Area SHEET (WIRE) KA2502011 2P CONECTOR ASS DG4152010 DG3070010 REG.IC BRACET...
  • Page 45 KD-LX111R CD mechanism assembly and parts list Block No. Grease G-31SA G-31SA(Bottom side) TN-CCD1001Z-150S CFD-005H 133 22...
  • Page 46 LD-LX111R Parts list (CD mechanism) Block No. MBMM Item Parts number Parts name Q'ty Description Area 30310101T FRAME 30310103T DANPER PIN 303101073T UPPER PL(3) 30310108T SEL STOP PLATE 30310164T SEL ARM (L8)L 30310143T SEL ARM (R)L 30310154T S ARM SPRING(L8 30310112T TRIG LEVER TRIG PL(Z)
  • Page 47 KD-LX111R Parts list (CD mechanism) Block No. MBMM Item Parts number Parts name Q'ty Description Area 64180402T DET SWITCH 2 ESE22MH1 DET SWITCH 2 ESE22MH3 64180403T 68150232T CONNECTOR 1 TKC-W26X-C1 30311105T SOPPORT PLATE 30311138T GR MT BLK(N) 30311109T LDG GEAR (2)
  • Page 48 LD-LX111R Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area BZ791 000393760 BUZZER CD11PA-XZ C306 CE4754468 E.CAPACITOR 4.7 MF/25 V CN301 KN2503297 CONN.TERMINAL 3P BASE POST C351 CY104423J C.CAPACITOR 0.1 MF...
  • Page 49 KD-LX111R Block No. 01 Electrical parts list (Main board) Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area C545 CY473623J C.CAPACITOR 0.047 MF C965 CE2263468 E.CAPACITOR MF/16 V C546 CY473623J C.CAPACITOR 0.047 MF C966 CY103623J C.CAPACITOR...
  • Page 50 LD-LX111R Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area L961 000125560 CHOKE COIL R211 RK224JA0J COMP.RESISTOR 1/10W 220 K TRC4081(QRS)L TRANSISTOR 2SC4081/QR/-X R213 RK472JA0J C.RESISTOR 1/10W 4.7 K TRB1197(QR)L TRANSISTOR 2SB1197K/QR/-X...
  • Page 51 KD-LX111R Block No. 01 Electrical parts list (Main board) Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area R515 RK823JA0J COMP.RESISTOR 1/10W 82 K R719 RK104JA0J COMP.RESISTOR 1/10W 100 K R516 RK101JA0J UNF.C.RESISTOR 1/10W 100...
  • Page 52 LD-LX111R Block No. 01 Electrical parts list (Main board) Item Parts number Parts name Remarks Area R981 RK183JA0J COMP.RESISTOR 1/10W 18 K R984 RK473JA0J COMP.RESISTOR 1/10W 47 K R985 RK472JA0J C.RESISTOR 1/10W 4.7 K R986 RK102JA0J C.RESISTOR 1/10W 1K R987 RK473JA0J COMP.RESISTOR 1/10W 47 K...
  • Page 53 KD-LX111R Electrical parts list (Front board) Block No. 02 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area CN601 KZ040160L CONN.TERMINAL 16P FPC CONNECT R611 RK472JA0J C.RESISTOR 1/10W 4.7 K R612 RK472JA0J C.RESISTOR 1/10W 4.7 K...
  • Page 54 LD-LX111R Packing materials and accessories parts list Block No. Block No. A11,A18,A21 A6,A7,A8, A9,A10 A12,A13,A14,A15, A16,A17,A20 3-14...
  • Page 55 KD-LX111R Parts list (Packing) Block No. M3MM Item Parts number Parts name Q'ty Description Area PPB022000 POLLY BAG 1 QPC03004315P POLLY BAG 1 QPA00801205 PPB022200 PPB022100 POLLY BAG 2 FSPG4002-001A DG2153010 CUSHION PDB450198 GIFT BOX Parts list (Accessories) Block No. M5MM...
