UHF/Cable RF Modulator
The UHF/Cable RF Modulator is an agile
mono modulator with digital type channel se-
lection, multi-channel frequency, and RF out-
put. It accepts left and right audio and video
signals from satellite receivers, VCRs, disc
players, and CCTV cameras. It has full chan-
nel memory for power outages and allows
switch-free distribution of audio and video in
UHF and cable TV channels.
Its other features include:
Digital Display — shows modes and chan-
nels selected.
Digital Type Channel Selection — lets you
select clear channels to transmit.
HRC and IRC — cable modes.
Digital PLL Tuning — limits channel drift.
Full Channel Memory for Power Outages
— retains the last channel after the power is
lost.
Wide Selection of Channels — lets you
choose from UHF channels 14 to 69, and
CATV/HRC/IRC channels 65 to 94 and 100
to 125.
THE FCC WANTS YOU
TO KNOW
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules . These limits are designed to provide
reasonable protection against harmful inter-
ference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
OWNER'S MANUAL — Please read before using this equipment.
and used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that interfer-
ence will not occur in a particular installation.
If this equipment does cause harmful inter-
ference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encour-
aged to try to correct the interference by one
or more of the following measures:
• Reorient
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult your local RadioShack store or
an experienced radio/TV technician for
help.
• If you cannot eliminate the interference,
the FCC requires that you stop using
your modulator.
Changes or modifications not expressly ap-
proved by RadioShack may cause interfer-
ence and void the user's authority to operate
the equipment.
FCC DECLARATION OF
CONFORMITY
This device complies with Part 15 of the FCC
Rules . Operation is subject to the following
two conditions: (1) this device may not cause
©
2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
or relocate the receiving
