Porter-Cable 1410 Instruction Manual
  1. Manuals
  2. Brands
  3. Porter-Cable Manuals
  4. Saw
  5. 1410
  6. Instruction manual

Porter-Cable 1410 Instruction Manual

14" “dry-cut” metal cutting saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction
Manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2000 Porter-Cable Corporation
14" "Dry-Cut" Metal
Cutting Saw
MODEL 1410
IMPORTANT
Please make certain that the person who is to
use
this
equipment
understands these instructions before starting
operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. _____________________________________
Type __________________________________________
Serial No.______________________________________
ESPAÑOL: PAGINA 11
FRANÇAISE : PAGE 23
carefully
reads
Part No. 896182-009
and

Advertisement

Table of Contents
loading

Related Manuals for Porter-Cable 1410

Summary of Contents for Porter-Cable 1410

  • Page 1 FRANÇAISE : PAGE 23 Instruction 14" “Dry-Cut” Metal Manual Cutting Saw MODEL 1410 IMPORTANT Please make certain that the person who is to To learn more about Porter-Cable this equipment carefully reads visit our website at: understands these instructions before starting http://www.porter-cable.com operations.

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS GROUNDED OUTLET BOX WARNING: THIS TOOL SHOULD CURRENT CARRYING GROUNDED WHILE IN USE TO PROTECT THE PRONGS OPERATOR FROM ELECTRIC SHOCK. The tool is equipped with an approved three-conductor cord and three-prong grounding type plug to fit the proper grounding type receptacle.

  • Page 3: Important Safety Instructions

    NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you. Technical Service Manager...

  • Page 4: Replacement Parts

    25. WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, • crystalline silica from bricks and cement and other masonry products, and •...

  • Page 5: Extension Cord Selection

    MOTOR USE WITH STATIONARY ELECTRIC TOOLS Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate of the tool.

  • Page 6: Cutting Capacities

    Slowly release pressure on the tool handle, allowing the cutting head to move to the UP position, as shown in Fig. 5. OPERATING INSTRUCTIONS FOREWORD Porter-Cable Model 1410 is a 14", “Dry-Cut”, Metal Cutting Saw designed to cut ferrous metals. Cutting capacities (at 90°) are: 5 " Dia. round stock, 4 " x 4 "...
  • Page 7 Fig. 8 Fig. 9 WORK VISE A work vise is provided to securely clamp the workpiece to the saw base. The stationary jaw can be adjusted for angled cuts of from 0° to 45° right. The stationary jaw (of the vise) can also be moved rearward to accommodate larger workpieces.

  • Page 8: Making The Cut

    Fig. 14 Fig. 15 workpiece orientation). Move clamp locknut (A) Fig. 9A, forward to engage threads on clamp screw (C) Fig. 9A. Tighten vise securely by rotating clamp handle (D) Fig. 9A, clockwise. Make sure workpiece is clamped securely before proceeding. WARNING: Failure to securely clamp the workpiece, as recommended above, can cause the workpiece to be thrown violently, resulting in personnel injury or property damage.

  • Page 9: Changing The Blade

    Fig. 18 Fig. 19 Fig. 20 Fig. 21 CHANGING THE BLADE CAUTION: Disconnect the machine from the power source. Use the 2.5mm hex wrench (provided) to remove the three blade cover retaining screws (F) Fig. 16. Rotate the blade cover to expose blade (see Fig. 18). Press in on arbor lock (G) Fig.

  • Page 10: Maintenance

    ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace, at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
  • Page 11 Porter-Cable products should be obtained by contacting any Porter-Cable Distributor, Authorized Service Center, or Porter-Cable Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable Factory Service Center.
